| Model No.: | CSCWTT040 |
| Water Tank Capacity: | 40 CBM |
| Water tank size(LxWxH): | 8,000×3,200×1,880mm |
| Chassis Brand: | XCMG |
| Wheelbase: | 5,300+1,560mm |
| Rated loading capacity: | 40,000kg |
| Max. travel speed: | 50km/h |
| Max. grade ability: | 40% |
| Engine Model: | WD12G375E211 |
| Engine Power: | 375HP |
| Electric System Operating Voltage: | 24V |
| Alternator: | 70A/28V |
| Batteries: | 6-QAW-180DMF |
BRIEF
The XCMG 40 CBM off-road water tanker truck, produced by CSCTRUCK China Tank Truck, is a robust and high-capacity solution for water transportation in demanding off-road environments. Built on the durable XCMG chassis, this tanker boasts a 40 CBM (cubic meters) water tank volume and a loading capacity of up to 40,000 kilograms, making it suitable for heavy-duty applications such as mining, construction, and remote area water supply.
Powered by the WD12G375E211 engine, the water truck delivers an impressive 375 horsepower, ensuring reliable performance even in challenging terrains. With a maximum driving speed of 50 km/h and a gradability of 40%, it can effectively navigate steep inclines and rugged landscapes. The engine’s robust design is complemented by a 24V electric system, featuring a 70A/28V alternator and 6-QAW-180DMF batteries, which provide reliable electrical performance and support the truck’s operational demands.
Designed with practicality and reliability in mind, the XCMG 40 CBM water tanker is engineered to handle tough conditions while maintaining efficiency. Its off-road capabilities and high water capacity make it an essential vehicle for industries requiring large-scale water transport. With CSCTRUCK China Tank Truck‘s expertise in manufacturing specialized vehicles, this tanker truck ensures high performance, durability, and safety, making it a preferred choice for heavy-duty applications.
FEATURES
- Impressive Tank Capacity: Equipped with a 40 CBM (cubic meter) water tank, suitable for large-scale water transport needs in rugged terrains.
- Powerful Performance: Powered by the WD12G375E211 engine delivering 375HP, ensuring efficient and reliable operation in demanding off-road environments.
- Robust Chassis and Load Capacity: Built on an XCMG chassis with a 40,000kg loading capacity, designed for durability and heavy-duty performance.
- Enhanced Mobility and Gradeability: Achieves a maximum driving speed of 50 km/h and supports a 40% maximum grade ability, making it highly capable on steep inclines.
- Advanced Electric System: Features a 24V electric system with a 70A/28V alternator and 6-QAW-180DMF batteries, ensuring dependable operation of all electronic components.
SPECIFICATION
|
Overall Dimensions
|
|
|
Water tank body size (length×width×height)
|
8,000×3,200×1,880mm
|
|
Cargo thickness
|
8mm
|
|
Tank
|
40m³
|
|
Wheelbase
|
5,300+1,560mm
|
|
Min. ground clearance
|
380mm
|
|
Weight
|
|
|
Curb mass
|
25,000kg
|
|
Rated loading capacity
|
40,000kg
|
|
Gross vehicle weight
|
65,000kg
|
|
Performance
|
|
|
Max. travel speed
|
50 km/h
|
|
Min. turning Radius
|
12m
|
|
Max. gradability
|
40%
|
|
Engine
|
WD12G375E211
6 in-line, four-stroke, water-cooled, omega-type combustion chamber, waste gas turbocharged and intercooled. |
|
Rated output power
|
375HP
|
|
Displacement
|
11,596ml
|
|
Transmission
|
|
|
Type
|
Fast 9JSD180, 9 forward 1 reverse
|
|
Steering
|
Power-steering system + aided steering
|
|
Front axle
|
Pengxiang 13T
|
|
Rear axle
|
Pengxiang 25T
|
|
Brakes
|
|
|
Service brake
|
Dual circuit compressed air brake
|
|
Parking brake
|
Spring energy operating on rear wheels
|
|
Tires
|
14.00-24
|
|
Electric System
|
|
|
Operating voltage
|
24V
|
|
Alternator
|
70A/28V
|
|
Batteries
|
6-QAW-180DMF
|
|
Fuel tank Capacity
|
400L
|
