| Model No.: | CSCOTRT022 |
| Tank Volume: | 22 CBM |
| Overall Dimensions(LxWxH): | 9,910×2,500×3,360mm |
| Chassis Brand: | SHACMAN H3000 |
| Chassis Model: | SX5250GYYMB |
| Drive Type: | 6X4 |
| Wheelbase: | 4,375+1,350mm |
| Gross Weight: | 25,000kgs |
| Engine Model: | WP9H336E |
| Emission Standard: | EURO 5 |
| Net Power: | Min 247kW |
| Tank Material: | Carbon Steel Q235 |
Description
BRIEF
The SHACMAN H3000 22 CBM oil tank refueling truck is a robust and versatile fuel transportation solution manufactured by CSCTRUCK China Tank Truck, a leading Chinese tank truck producer. Designed for efficiency and durability, the truck is built on the SHACMAN H3000 SX5250GYYMB chassis, which offers a sturdy and reliable foundation for heavy-duty operations.
This refueling truck features a 22 CBM (22,000 liters) tank, constructed from Q235 carbon steel, ensuring long-lasting performance and resistance to wear and tear. The 6×4 drive configuration provides enhanced traction and stability, making it suitable for varied terrains and demanding environments.
Powering the vehicle is the WP9H336E engine, delivering a minimum engine power of 247kW (336hp). Meeting the EURO 5 emission standards, this engine balances performance with environmental responsibility, ensuring compliance with international regulations.
The SHACMAN H3000 oil tank truck is engineered for fuel distribution, refueling stations, or industrial applications. Its modern design and advanced features make it a preferred choice for efficient fuel transport. Its durability, coupled with the high-capacity tank, ensures maximum operational efficiency while minimizing downtime.
With its rugged build, high-capacity tank, and compliance with strict emission standards, the SHACMAN H3000 22 CBM oil tank refueling truck is a reliable partner for businesses needing safe and efficient fuel transport solutions.
FEATURES
1. Large Tank Capacity: Equipped with a 22 CBM (22,000 liters) carbon steel Q235 tank, ideal for transporting and refueling large volumes of fuel efficiently.
2. Robust Chassis: Built on the SHACMAN H3000 SX5250GYYMB chassis, ensuring durability and high performance under demanding conditions.
3. Powerful Engine: Powered by a WP9H336E engine with a minimum output of 247 kW (336 HP), meeting the EURO 5 emission standards for eco-friendly and efficient operation.
4. 6×4 Drive Configuration: Features a 6×4 drive type, providing excellent traction and stability for various terrains and heavy loads.
5. Emission Compliance: Conforms to EURO 5 emission standards, combining environmental compliance with high fuel efficiency.
SPECIFICATION
| Subject | SHACMAN H3000 22 CBM Oil Tank Refueling Truck for transportation |
| Overall Dimensions(LxWxH) | 9,910X2,500X3,360mm |
| Tank Capacity | 22 cubic meters |
| Chassis Model | SX5250GYYMB |
| Wheelbase | 4,375+1,350mm |
| Gross Weight | 25,000kgs |
| Curb Weight | 10,100kgs |
Engine |
|
| Engine Brand | SHACMAN |
| Model | WP9H336E |
| Type | In-line, 6-cylinder, water cooling, 4-stroke, supercharging intermediate cooler, high-pressure common rail. |
| Displacement Volume(ml) | 8,800 |
| Net Power(kW) | Min 247KW at rated RPM |
| Fuel Type | Diesel |
| Emission Standard | From Euro 3 to Euro 5 |
| Clutch System | Model | Single plate, dry friction |
| Steering System | Power Steering | Left-hand driving, Rhd is available |
| Transmission System | Manually operated | 9-forwards and 1- reverse |
| Brake System | Service Brake | Hydraulic disk brakes |
| Park Brake | Air Brake & Hand Brake, | |
| Suspension System
(Front & Rear) |
Semi-elliptical leaf spring with telescopic shock absorber (both front & rear) | |
| Tyre | Tyre Quantity | 10 pcs |
| Tyre Specification | 11.00R20 18PR | |
| Cabin | Folding driver’s cabin of 3 persons (including driver), ABS, electric glass, air conditioner, adjustable headlights, USB, RUPD, etc. | |
| Tank Body | Capacity | 22 cubic meters |
| Material | 1. The tank is made of 5mm high-quality carbon steel Q235;
2. The tank material of 304 stainless steel or aluminum alloy is optional. |
|
| Filling Medium | Liquid Fuel: Gasoline or diesel. | |
| Equipment | a. It can be equipped with a tax-controlled computer refueling machine (mass flow), equipped with a 10-15 meters automatic retractable reel, with a refueling gun.
b. Bottle loading system. c. There is a container indicator that can indicate the tank volume when filling or discharging. d. To ensure the pressure in the tank is the same as the atmospheric pressure during the working process. A breathing valve is installed on the large cover of the tank. When the internal pressure of the tank is higher than 8KPa, the value plate on the breathing valve is open, and when the internal pressure is lower than 3Kpa, the valve under the breathing valve is open. |
|
| Coating | a. The inside of the tank is made of epoxy resin with a thickness of 120 microns (3-pass process), which not only has an anti-corrosion effect but also has anti-seepage and plugging effects.
b. The outer part of the tank is sprayed with iron red alkyd antirust paint, which has good adhesion and strong anti-rust ability. c. Tank color is customized if necessary. |
|
Additional information
| Tank Mounted on Chassis Brand |
|---|
