| Model No.: | CSCFDT030 |
| Fuel Tank Volume: | 30,000 liters |
| Overall Dimensions(LxWxH): | 11,990×2,500×3,450mm |
| Chassis Brand: | SHACMAN F3000 |
| Drive Type: | 8×4 |
| Wheelbase: | 1,800+4,600+1,350mm |
| Max. driving speed(km/h): | 95 |
| Engine Model: | WD615.47 |
| Engine Power: | 371HP |
| Emission Standard: | Euro II |
| Tank material: | Q235 carbon steel |
BRIEF
The SHACMAN F3000 30,000 Liters Fuel Delivery Truck, manufactured by CSCTRUCK China Tank Truck, is a robust and efficient vehicle designed for large-scale fuel transportation. This truck features a SHACMAN F3000 chassis with an 8×4 drive configuration, ensuring excellent stability and traction for heavy loads. With a maximum driving speed of 95 km/h, it combines speed and reliability, meeting the demands of modern logistics.
The heart of the fuel delivery truck is the WD615.47 engine, delivering 371 horsepower and complying with the Euro II emission standard. This powerful engine ensures efficient performance and durability, suitable for long-haul operations. The fuel tank, with a 30,000-liter capacity, is constructed from Q235 carbon steel, renowned for its strength and resistance to corrosion, making it ideal for safely transporting large quantities of fuel.
This tank truck is engineered for versatility and reliability, making it a popular choice in industries requiring bulk fuel delivery, such as petroleum distribution and logistics. Its design reflects a balance of performance, capacity, and durability, tailored to withstand the challenges of heavy-duty fuel transportation while adhering to environmental standards.
The SHACMAN F3000 fuel truck is a testament to advanced engineering and manufacturing expertise, offering a cost-effective solution for fuel transport needs.
FEATURES
- High Fuel Tank Capacity
- Equipped with a 30,000-liter fuel tank, suitable for large-scale fuel transportation.
- Robust Chassis and Drive Type
- Built on the SHACMAN F3000 chassis with an 8×4 drive configuration for enhanced stability and heavy-duty performance.
- Powerful Engine
- Features the WD615.47 engine model with 371 horsepower, delivering strong performance.
- Euro II Emission Standard Compliance
- Adheres to the Euro II emission standard, balancing power with environmental considerations.
- Durable Tank Material
- Constructed using Q235 carbon steel, ensuring durability and resistance to wear for transporting fuel safely.
SPECIFICATION
Truck Chassis |
|||
| Condition | NEW | ||
| Chassis | Brand | SHACMAN F3000 | |
| Curb weight(kg) | 14,300 kg | ||
| Wheelbase(mm) | 1,800+4,600+1,350 mm | ||
| Dimensions(mm)(LxWxH) | 11,990X2,500X3,450 mm | ||
| Front/Rear Axle loading(kg) | HF9 front axle/9,000kgX2; HC16 rear axle/16,000kgX2; |
||
| Wheel track (front/rear) (mm) | 2,022/2,022/2,041/2,041 mm | ||
| Front/Rear overhang(mm) | 1,500/2,740 mm | ||
| Approach/Departure angle(°) | 26/20 | ||
| Max. driving speed(km/h) | 95 | ||
| Clutch | Reinforced diaphragm clutch | ||
| Brakes | Service brake: Dual circuit compressed air brake Parking brake: (Emergency brake): Spring energy, compressed air operating on rear wheels Auxiliary brake: Engine exhaust valve brake. |
||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Tire | Quantity | 12Â pcs with one spare tire | |
| Specifications | 12R22.5 | ||
| Fuel box | 400L with lockable cap | ||
| Transmission | Manual type HW19710, 10 Forwards, and 2 reverse. | ||
| Cab | It can accommodate 3 people. With Air Conditioner. | ||
| Engine | Brand | SINOTRUK | |
| Model | WD615.47 | ||
| Fuel type | Diesel | ||
| Displacement(ml) | 9,726 ml | ||
| Power(kW) | 273kW | ||
| Horsepower(HP) | 371HP | ||
| Max. Torque(N·m) | 1,160 | ||
| Fuel consumption at full load(g/kw.h) | 193 | ||
| Cylinder number | In-line 6 cylinders, water cooling, four-stroke, super-charge, and middle cooling, direct-injection. | ||
| Emission standard | Euro II | ||
Fuel Tank |
|||
| Fuel tank | Capacity(CBM/liters) | 30 CBM/30,000 liters | |
| Tank material | Tank material: Q235 high tensile strength steel | ||
| Thickness(mm) | 5mm of the tank and 5mm of the end plate | ||
| Shape | Square or as request | ||
| Compartment No. | 3 | ||
| Baffle | 4 mm carbon steel | ||
| Manhole cover | 3 pcs of European Aluminum alloy manhole covers, ∮500mm 3 sets with 3 breather valves | ||
| Bottom Valve | 3 sets of Aluminum alloy Pneumatic Bottom Valves | ||
| Discharging valve | 3 set ∮ 4 inches API discharging valves | ||
| Oil pump | Chinese brand, 80-60 carbon steel pump with flow meter 60m3/h | ||
| Pump system pipeline | 2.5 inches | ||
| Flow meter | Chinese brand DN50 flow meter | ||
| Walkway at the top of the tanker | Anti-slip | ||
| Painting | Color and design as customer’s requirement | ||
| Others | Overflow; 3 sets of vapor recovery; Fire Cap(1 pc); Fire extinguisher(2 pcs); Anti-static wire; The truck will be waxed before shipment; |
||
| Handrail | Pneumatic control at 2 sides of the truck. | ||
| Ladder | At the rear of the tank. | ||
| Tank Mounted on Chassis Brand |
|---|
