BRIEF

CSCTRUCK China Tank Truck, based in China, manufactures Liquid Ammonia pressure vessels ranging from 10 to 100 cubic meters. These vessels adhere to the GB150 execution standard and are designed for rigorous industrial use. With a design pressure of 21.6 MPa and a design temperature of 50°C, they ensure safe handling of liquid ammonia. The vessels feature a filling ratio 0.52, optimizing capacity while maintaining operational safety. Constructed from 2 mm thick Q345R pressure vessel steel, they offer robust durability and reliability in ammonia transport and storage applications, meeting stringent quality and safety standards.

FEATURES

1. Capacity Range

– The pressure vessel has a versatile capacity range of **10-100 cubic meters (CBM)**, catering to various industrial needs for storing and transporting liquid ammonia.

2. Compliance with GB150 Execution Standard

– Designed and manufactured according to the **GB150 execution standard**, ensuring high safety and quality in line with China‘s national pressure vessel standards.

3. High Design Pressure

– The vessel is built to withstand a **design pressure of 21.6 MPa**, making it suitable for safely containing and transporting liquid ammonia under high-pressure conditions.

4. Optimized Design Temperature

– It is engineered for a **design temperature of 50°C**, ensuring the vessel’s integrity and reliability across various operating conditions.

5. Filling Ratio

– The vessel has a **filling ratio of 0.52**, optimizing the balance between the amount of liquid ammonia stored and the safety of the pressure vessel.

6. High-Quality Material

– Constructed from **2 mm thick Q345R** steel, a specialized pressure vessel material known for its high strength and excellent weldability, ensuring durability and safety under pressure.

7. Precision Engineering

– The vessel is designed precisely to ensure maximum efficiency, safety, and longevity in liquid ammonia storage and transportation, making it a reliable choice for industrial applications.

8. Produced by CSCTRUCK

– Manufactured by **CSCTRUCK, a reputable Chinese company** known for its expertise in producing high-quality tank trucks and pressure vessels, ensuring dependable performance and adherence to international standards.

SPECIFICATION

	Tank	Volume (m3)	Loading mass (ton)	standard and configuration
1	Liquid ammonia tank	10	5.2	Execution standard: GB150 “pressure vessel” and “fixed pressure vessel safety technology and supervision code” design pressure: 21.6 design temperature: 50 ° c filling ratio: 0.52 corrosion allowance: material: 2 mm subject Q345R
2		20	10.4
3		25	13
4		32	16.64
5		50	26
6		60	32.2
7		80	41.6
8		100	46.8
