Model No.:	CSCFDT005
Fuel Tank Volume:	5,000 Liters
Overall Dimensions(LxWxH):	5,990×1,950×2,450mm
Chassis Brand:	JAC
Drive Type:	4×2
Wheelbase:	3,308mm
Engine Power:	130HP
Emission standard:	EURO V
Loading Weight:	3,360(kg)
Maximum speed:	80(km/h)
Fuel Tank Material:	Q235B Carbon Steel
Optional API standard system:	Anti-overflow probe
Optional API standard system:	Oil Vapor Recovery System

Truck Enquiry

Categories: Carbon Steel Tank Truck, Fuel Tank Truck

Description

BRIEF

The JAC 5CBM fuel delivery truck by CSCTRUCK China Tank Truck is a highly efficient and reliable fuel transport solution designed for medium-scale operations. Built on a robust JAC chassis with a 4×2 drive type, it is optimized for stability and durability in various road conditions.

The vehicle features a 5,000-liter fuel tank, constructed from Q235B carbon steel, which ensures superior strength and corrosion resistance, making it suitable for safely transporting fuels over long distances. Powered by a 130HP engine compliant with EURO V emission standards, the truck provides an environmentally friendly performance while maintaining efficient fuel consumption.

With a maximum loading weight of 3,360 kilograms, this fuel delivery truck balances payload capacity and operational efficiency. It achieves a top speed of 80 km/h, making it ideal for urban and semi-urban fuel delivery requirements. The truck’s dimensions and specifications are tailored to provide flexibility in navigating narrow streets and tight spaces while maintaining a high standard of operational safety.

The JAC 5CBM fuel delivery truck is a versatile and practical solution for businesses requiring reliable fuel transport. Its adherence to modern emission standards, combined with durable construction and efficient performance, underscores its value in logistics and distribution. This truck is a testament to CSCTRUCK China Tank Truck’s commitment to engineering excellence and innovation in commercial vehicle manufacturing.

FEATURES

1. Fuel Tank Capacity and Material:

– 5,000 liters capacity.

– Made of Q235B carbon steel, ensuring durability and resistance to corrosion.

2. Chassis and Drive Type:

– Built on a JAC chassis for reliability.

– 4×2 drive type, suitable for urban and short-haul fuel transportation.

3. Engine and Performance:

– 130HP engine power, providing adequate strength for fuel delivery tasks.

– EURO V emission standard for eco-friendly operation.

4. Load and Speed Specifications:

– 3,360kg maximum loading weight.

– Top speed of 80km/h, balancing safety and efficiency.

5. Design and Manufacturer:

– Manufactured by CSCTRUCK China Tank Truck, a trusted name in specialized commercial vehicles.

– Compact and efficient design tailored for local fuel distribution.

SPECIFICATION

General Technical Parameters
Overall Dimensions(LxWxH)	5,990×1,950×2,450 (mm)		Gross Vehicle Weight	7,360(kg)
Curb Weight	4,030(kg)		Loading Weight	3,360(kg)
Chassis Specification
Chassis parameters	Chassis Brand		JAC
	Cabin		Single, Left-Hand Driving
	Engine	Power	130HP
		Emission standard	EURO V
		Displacement	3L
		Fuel type	Diesel
	Gearbox		6 Forward & 1 Reverse Gear
	Front and Rear Axle load		5T rear axle
	Wheel Base		3,308(mm)
	Overhang( Front/Rear)		1,040/1,647(mm)
	Angle(Approach/departure)		16/14(°)
	Brake System		Pneumatic
	Steering Gear		Power Assistant
	Tire		7.00R16, 6 Pieces
	Maximum speed		80(km/h)
Superstructure
Fuel Tanker	Tank Volume		5,000 Liters / 5m3
	Tank Material		Q235B Carbon Steel
	Tank Shape		Square Round
	Transport oil type		Diesel/Petrol
Refueling system	Oil Pump		1pc, Chinese famous brand
	Oil dispenser		1pc, a Chinese famous brand, Digital Screen Display with Keyboard, Oil Filling Display in Liter, Price & Amount.
	Hose Reel with Filling Gun		6 Meters (Length can be longer as per request), Corrosion Resistant.
Equipment	Lifting fence, ladder, Manhole 1 Unit, Emergency cut-off valve 1 Unit.
Optional API standard system	Anti-overflow probe Oil Vapor Recovery System.
