| Model No.: | CSCWT012 |
| Water Tank Volume: | 12 CBM |
| Overall Dimensions(LxWxH): | 8,900X2,500X3,100mm |
| Chassis Brand: | ISUZU FTR |
| Drive Type: | 4X2 |
| Wheelbase: | 5,000mm |
| Max. Speed: | 90km/h |
| Engine Model: | Cummins ISB180 50 |
| Horse Power: | 180HP |
| Emission Standard: | Euro V |
| Water Tank Material: | Stainless steel |
BRIEF
The ISUZU FTR 12 CBM water truck, manufactured by CSCTRUCK China Tank Truck, is a versatile and robust vehicle for efficient water transportation and distribution. It features a stainless steel water tank with a generous capacity of 12 cubic meters, ensuring durability and resistance to corrosion, even under rigorous operating conditions.
Built on the reliable ISUZU FTR chassis, this truck operates with a 4×2 drive configuration, making it suitable for urban and intercity routes. Its powertrain includes the Cummins ISB180 50 engine, which delivers an impressive 180 horsepower. The engine adheres to the Euro V emission standards, ensuring environmental compliance and reduced carbon footprint.
With a maximum driving speed of 90 km/h, the truck provides optimal performance while balancing fuel efficiency. This makes it an excellent choice for applications such as water supply for construction sites, municipal services, irrigation, and emergency response for firefighting.
The water truck‘s design emphasizes functionality, with features such as easy access to the tank for maintenance and versatile spray systems for effective water distribution. The stainless steel construction of the tank adds longevity and ensures the water’s purity, making it suitable for diverse uses, including potable water delivery.
In summary, the ISUZU FTR 12 CBM water truck combines ISUZU‘s reliable engineering with CSCTRUCK China Tank Truck‘s expertise in tank truck manufacturing. Its powerful Cummins engine, high-capacity tank, and Euro V compliance make it a sustainable and efficient solution for water transport and distribution needs.
FEATURES
- Large Water Tank Capacity: The truck is equipped with a 12 CBM stainless steel water tank, ensuring durability and resistance to corrosion.
- Reliable Chassis: Built on the ISUZU FTR chassis, the vehicle ensures structural integrity and performance suitable for demanding operations.
- Efficient Engine: Powered by the Cummins ISB180 50 engine delivering 180HP with a Euro V emission standard, it combines power and eco-friendliness.
- Optimal Drive and Speed: Features a 4×2 drive type and a maximum driving speed of 90 km/h, balancing agility and stability.
- Durable Build for Industrial Use: Designed for heavy-duty tasks, the truck offers robust construction and a long-lasting stainless steel water tank ideal for water transport and spraying tasks.
SPECIFICATION
| Chassis Model | ISUZU FTR 4×2 Water Truck | ||
| Vehicle main dimensions | Overall dimensions(LxWxH)mm | 8,900*2,500*3,100 | |
| Wheelbase(mm) | 5,000 | ||
| Weight | GVW | 16,000kg | |
| Curb weight | 7,550kg(TBD) | ||
| Loading capacity | 12 CBM | ||
| Front axle loading capacity | 45T | ||
| Rear axle loading capacity | 9Tx1 | ||
| Max driving speed(km/h) | 90 | ||
| Engine | Brand | Cummins | |
| Model | ISB180 50 | ||
| (CC)KW | 5,900/180HP | ||
| Emission standard | Euro V | ||
| Transmission | 6 gearboxes 6 forward,1 reserve | ||
| Drive system | LHD | ||
| Tire | 9.00R20 | ||
| Brake | Air brake | ||
| Steering | Power steering | ||
| Body | Capacity | 12 CBM | |
| Structure | TANK MATERIAL | 4mm, Q304/2B Stainless steel, food grade | |
| Pipe | Galvanized pipe | ||
| Discharge nozzle | SS, at the side bottom of the tank, quick coupling | ||
| Discharge nozzle option | Stainless steel faucet. | ||
