Model No.: | ISUZU CXR 40000 Liters Crude Oil Tank Truck |
Crude Oil Tank: | 40,000L |
Crude Oil Tank Material: | Carbon Steel |
Overall Dimensions(LxWxH): | 11,900×2,500×3,454mm |
Chassis Brand: | ISUZU CXR |
Drive Type: | 6×4 |
Wheelbase: | 1,950+4,550+1,350mm |
Engine Brand: | ISUZU |
Emissions Standard: | Euro III |
Horsepower: | 320HP |
Max speed: | 90km/h |
Categories: Carbon Steel Tank Truck, Crude Oil Tank Truck
Description
BRIEF
The ISUZU CXR 40000-liter crude oil tank truck, produced by CSCTRUCK China Tank Truck, is a robust and efficient vehicle designed to transport large volumes of crude oil. With a substantial capacity of 40,000 liters, the tank is constructed from durable carbon steel, ensuring safety and longevity during transport.
This model features a 6×4 drive type, providing excellent traction and stability, essential for navigating various terrains and handling the heavy load of crude oil. The truck is powered by a 320HP engine, delivering substantial power to maintain performance even under maximum load conditions. Additionally, it adheres to the Euro III emission standard, reflecting a commitment to reducing environmental impact and improving air quality by limiting harmful emissions.
The ISUZU CXR 40000 liters crude oil tank truck can reach a maximum driving speed of 90km/h, balancing speed with the safety requirements for transporting hazardous materials. This speed ensures timely deliveries while maintaining control and safety on the road. The design and engineering of the ISUZU CXR 40000 liters crude oil tank truck demonstrate a focus on reliability, efficiency, and environmental responsibility, making it a valuable asset for companies involved in the oil transportation industry.
Overall, the ISUZU CXR 40000-liter crude oil tank truck stands out for its high capacity, powerful performance, and adherence to environmental standards, positioning it as a top choice for efficient and safe crude oil transportation.
FEATURES
1. Brand and Model:
  – Brand: ISUZU
  – Model: CXR 40,000 liters crude oil tank truck
2. Manufacturer:
  – Produced by: CSCTRUCK, a prominent manufacturer of specialized trucks in China.
3. Tank Capacity and Material:
  – Tank Capacity: 40,000 liters, suitable for transporting large volumes of crude oil.
  – Tank Material: Made from carbon steel, ensuring durability and resistance to the corrosive nature of crude oil.
4. Drive Configuration:
  – Drive Type: 6×4, providing enhanced stability and traction suitable for heavy-duty transportation.
5. Emission Standard:
  – Compliance: Euro III emission standard, reflecting a commitment to environmental regulations and reduced emissions.
6. Engine Specifications:
  – Engine Power: 320 horsepower(HP), offering robust performance for heavy cargo.
  – Engine Efficiency: Designed to balance power and fuel efficiency for long-haul operations.
7. Speed and Performance:
  – Maximum Driving Speed: 90 km/h, ensuring timely delivery while maintaining safe driving speeds.
8. Specialized Functionality:
  – Purpose: Specifically designed for the safe and efficient transportation of crude oil.
  – Build Quality: Constructed to handle the demanding conditions of crude oil transport, ensuring reliability and safety.
9. Safety Features:
  – Likely includes industry-standard safety measures for handling hazardous materials, although specifics are not detailed in the provided information.
10. Additional Features:
  – Design and Ergonomics: Likely includes ergonomic design features for driver comfort and operational efficiency, given its intended use for long-distance hauling.
  – Support and Maintenance: Supported by CSCTRUCK China tank truck‘s network for maintenance and service, ensuring operational longevity.
SPECIFICATION
Model No.: | ISUZU CXR 40000 Liters Crude Oil Tank Truck |
Max output power | 238kW |
Power | 320HP |
Displacement | 7.7L |
Emission Standard | Euro III |
Engine type | In line water cooled, 4-stroke |
Transmission model | CA10TA130M |
Gearbox speed | 10 |
Chassis brand | ISUZU CXR |
Front axles | 9 tons |
Rear axles | 457, ABS |
Leaf spring quantity | 3/3/11, 10/10/11 |
Tyre quantity | 12 |
Tire size | 11.00R20 |
Front track | 1,950/1,950mm |
Rear track | 1,847/1,847mm |
Drive Type | 6×4 |
Wheelbase | 1,950+4,550+1,350mm |
Vehicle size | 11,900×2,500×3,454mm |
F/R hang | 1.400/2.650m |
Rated mass | 16.91t |
Max speed | 90km/h |
Vehicle type | Crude Oil Tank |
Tanker volume | 40,000L |
Tanker thickness | 5mm |
Transmission material | Diesel, gasoline |
