Model No.: | CSCMTT003 |
Milk Tank Volume: | 3CBM |
Overall Dimensions(LxWxH): | 6,980×2,160×2,830mm |
Chassis Brand: | ISUZU 600P |
Drive Type: | 4X2 |
Wheelbase: | 3,360mm |
Engine Model: | 4KH1CN5HS |
Engine Power: | 96kW/130HP |
Emission Standard: | EURO 5 |
Tank Body Material: | 304 Stainless steel |
Categories: Milk Tank Truck, Stainless Steel Tank Truck
Description
BRIEF
The ISUZU 3CBM milk tank truck, manufactured by CSCTRUCK China Tank Truck, is a robust and reliable vehicle designed for the safe and efficient transportation of milk. Built on the durable ISUZU 600P chassis, it features a 4×2 drive type and is powered by the 4KH1CN5HS engine model. This engine delivers 96 kW (130 HP) of power and meets the EURO 5 emission standard, ensuring reduced environmental impact and compliance with modern regulations.
The milk truck‘s milk tank is constructed from 304 stainless steel, known for its excellent corrosion resistance and food safety, making it ideal for transporting dairy products. With a capacity of 3 cubic meters (3CBM), the tank is designed to maintain the freshness and quality of the milk during transit. This ISUZU milk tanker is a perfect blend of performance, reliability, and safety, catering to the dairy industry’s stringent transportation needs.
FEATURES
1. ISUZU 600P Chassis: The truck is built on the reliable ISUZU 600P chassis, known for its durability and stability, ensuring a solid foundation for milk transportation.
2. 4KH1CN5HS Engine Model: Equipped with the 4KH1CN5HS engine, which offers a balance of performance and fuel efficiency, suitable for handling various terrains and loads.
3. 4×2 Drive Type: The 4×2 drive configuration provides efficient power distribution to the rear wheels, making it suitable for urban and highway driving.
4. EURO 5 Emission Standard: The engine complies with EURO 5 emission standards, ensuring reduced environmental impact and meeting stringent emission regulations.
5. 304 Stainless Steel Milk Tank: The 3 cubic meter (CBM) milk tank is constructed using 304 stainless steel, providing excellent corrosion resistance, hygiene, and maintaining the quality of transported milk.
SPECIFICATION
Overall Parameter |
|
Brand
|
ISUZU 600P
|
Overall Dimension(mm)(LxWxH)
|
6,980×2,160×2,830
|
Wheelbase(mm)
|
3,360
|
Front Axle Load(T)
|
2
|
Rear Axle Load(T)
|
4.8
|
Payload(T)
|
5
|
Tire
|
700R16
|
LHD/RHD
|
LHD
|
Driving type
|
4×2
|
Engine |
|
Model
|
4KH1CN5HS
|
Max. Output Power(KW)
|
96
|
Max. Torque
|
290N·m
|
Max. Horsepower(HP)
|
130
|
Displacement(L)
|
2.999
|
Emission Standard
|
EURO 5
|
Gearbox |
|
Forward & Rear Gear
|
MSB 5+1
|
Upper Body |
|
Capacity(m³)
|
3
|
Material
|
304 Stainless steel
|
