Model No.: | ISUZU 15 CBM Milk Tank Truck |
Milk Tank Volume: | 15 CBM |
Overall Dimensions(LxWxH): | 8,500×2,490×3,050mm |
Chassis Brand: | ISUZU |
Drive Type: | 4×2 |
Wheelbase: | 5,000mm |
Engine Model: | 4HK1-TC50 |
Engine Power: | 205HP |
Emission Standard: | Euro 5 |
Milk Tank Material: | Stainless steel 304 |
Categories: Milk Tank Truck, Stainless Steel Tank Truck
Description
BRIEF
The ISUZU 15 CBM Milk Tank Truck, manufactured by CSCTRUCK China Tank Truck, is a robust and reliable vehicle designed for efficient milk transportation. This truck features a high-quality ISUZU chassis, renowned for its durability and performance. It operates with a 4×2 drive type, ensuring stability and maneuverability in various road conditions.
Under the hood, the milk tank truck is powered by the 4HK1-TC50 engine model, delivering a potent 205 horsepower. This engine adheres to the Euro 5 emission standard, reflecting its environmentally friendly design that reduces harmful emissions and supports cleaner transportation solutions.
The milk tank, with a capacity of 15 cubic meters (CBM), is crafted from stainless steel 304. This material is chosen for its exceptional corrosion resistance, ensuring the purity and safety of the milk during transit. The stainless steel construction also contributes to the tank’s longevity and ease of maintenance, crucial for food-grade transportation.
The ISUZU 15 CBM Milk Tank Truck is designed with the needs of dairy transportation in mind, combining reliable performance, environmental consciousness, and high standards of hygiene. Its construction from durable materials and compliance with stringent emission standards make it a practical choice for businesses looking to transport milk efficiently and safely.
FEATURES
1. Large Capacity Milk Tank: The truck boasts a 15 cubic meter (CBM) stainless steel 304 tank specifically designed for transporting milk. The high-quality stainless steel ensures the milk remains uncontaminated and at the desired temperature.
2. Powerful ISUZU Chassis: Built on a robust ISUZU chassis, this truck benefits from the renowned durability and reliability of the ISUZU brand. The chassis is engineered to support heavy loads, making it ideal for long-distance milk transportation.
3. Efficient 4HK1-TC50 Engine: Equipped with the ISUZU 4HK1-TC50 engine model, the truck delivers a strong performance with 205 horsepower. This engine is designed for efficiency and reliability, ensuring the truck can handle demanding transport tasks.
4. Eco-Friendly Euro 5 Emission Standard: The truck meets the Euro 5 emission standard, making it an environmentally friendly choice. This standard ensures the vehicle produces lower emissions, contributing to a reduction in environmental impact.
5. 4×2 Drive Type: With a 4×2 drive configuration, the truck is optimized for road use, providing a balance of traction and fuel efficiency. This drive type is suitable for highways and urban environments, where milk delivery trucks typically operate.
SPECIFICATION
Vehicle Description |
||
Name and Purpose | ISUZU 15 CBM Milk Tank Truck | |
Overall dimensions(LxWxH) | 8,500×2,490×3,050mm | |
GVW | 18,000kg | |
Curb weight | 6,450kg | |
Traction type | 4×2, Left-hand drive | |
Chassis Description |
||
Chassis model | QL1180, ISUZU brand | |
Wheelbase | 5,000mm | |
Tire specification | 10.00R20, 6+1 units | |
Engine | Engine model | 4HK1-TC50, ISUZU brand |
Emission level | Euro 5 | |
Displacement/output | 5,193ml/151kW/205HP | |
Gearbox | Type | MLD-6 |
Number of gears | 6 forward gears& 1 reverse, | |
Brake system | Full air brake system split pneumatic circuit; parking spring brake acting on rear axles, exhaust brake | |
Axle | Front | 6.3T, I beam section |
Rear | 13T | |
Suspension | Front | 7/7- Leaf spring |
Rear | 5-Leaf spring | |
Fuel tanker | Type | Steel fuel tank, with lockable cap |
Capacity | 200L | |
Up-part Description |
||
Tanker | Capacity | 15CBM, 4,000Gallon |
Material | Stainless steel 304 | |
Thickness | 5mm | |
Standard configuration | Equipped with 2 pcs of water hose as the length of the tanker, with aluminum ball valve as inlet and outlet system and stainless toolbox. Equipped with Stainless steel pump for water inlet and outlet system Optional: Stainless steel Flow meter(Cost 600USD) |
