BRIEF
The HOWO 27 CBM LNG transport truck produced by CSCTRUCK China Tank Truck is a high-capacity, heavy-duty solution engineered for the safe and efficient transportation of liquefied natural gas (LNG). Built on a robust HOWO 8×4 left-hand drive chassis, this vehicle combines strong load-bearing capability with advanced cryogenic tank technology, making it ideal for long-distance LNG distribution and industrial fuel supply.
With overall dimensions of 11,890 × 2,520 × 3,720 mm and a gross vehicle weight of 32,000 kg, the truck offers excellent stability and payload efficiency. The chassis, model ZZ1327N466GF1LK, is powered by a YCA07220N-60 engine compliant with Euro 5 emission standards, delivering 220 horsepower and 216 kW output. Paired with a HW90510C gearbox featuring 10 forward and 2 reverse gears, the vehicle ensures smooth operation across various road conditions. Its reinforced axle configuration and leaf spring suspension system enhance durability and load distribution.

The LNG tank has a capacity of 27 cubic meters, with a 90% filling ratio and a maximum filling weight of 10,350 kg. Designed with high-vacuum multi-layer insulation, it ensures minimal thermal loss and maintains LNG at cryogenic temperatures. The inner tank is constructed from S30408 stainless steel, with a thickness of 10 mm and a design pressure of 1.0 MPa. The outer tank, in contrast, utilizes Q345R material with a thickness of 6 mm, providing structural strength and safety.
For operational efficiency, the truck is equipped with an LNG pump, dispenser, liquid level meter, pressure gauge, and thermometer. Safety features include a safety valve, an emergency shut-off valve, and dedicated inlet and outlet systems. Additional components, such as double toolboxes and valve boxes, enhance convenience and maintenance accessibility, making this LNG transport truck a reliable and comprehensive solution for modern energy logistics.
FEATURES
- High-capacity LNG transport system
Equipped with a 27 m³ cryogenic tank and a 90% filling ratio (max 10,350 kg), it is designed for efficient large-volume LNG distribution over long distances. - Robust HOWO 8×4 heavy-duty chassis
Built on a HOWO ZZ1327N series chassis, the 8×4 drivetrain ensures strong load-bearing performance, excellent traction, and stable operation under demanding road conditions. - Powerful and efficient Euro 5 engine system
Powered by a 220 hp YCA07220N-60 engine with Euro 5 emissions compliance and paired with a 10-speed gearbox, it delivers reliable performance and optimized fuel efficiency for long-haul operations. - Advanced cryogenic insulation technology
The LNG tank uses high-vacuum multi-layer insulation with S30408 stainless steel inner construction, minimizing thermal loss and maintaining LNG at stable cryogenic temperatures during transport. - Comprehensive safety and control systems
Integrated with safety valves, emergency shut-off systems, pressure gauges, liquid level meters, and LNG pumping equipment, ensuring secure handling and precise operational control. Built by CSCTRUCK China Tank Truck, it emphasizes reliability and operational safety.
SPECIFICATION
| Vehicle Description | ||
| Overall dimensions(LxWxH) | 11,890*2,520*3,720mm | |
| GVW | 32,000kg | |
| Curb weight | 19,715kg | |
| Chassis brand | HOWO | |
| Traction type | 8×4, Left-hand drive | |
| Chassis Description | ||
| Chassis model | ZZ1327N466GF1LK | |
| wheelbase | 1,800+4,575+1,400mm | |
| Tire specification | 295/80R22.5 18PR | |
| Tire quantity | 12+1units | |
| Engine | Engine model | YCA07220N-60 |
| Emission standard | Euro 5 | |
| Exhaust/output | 6.87L/216kW | |
| Horse power | 220hp | |
| Gear box | Model | HW90510C |
| Type | 10 forward gears & 2 reverse | |
| Axle | Front | 6,500/7,000kg |
| Rear | 18,500kg | |
| Suspension | Front | Leaf spring |
| Rear | Leaf spring | |
| LNG Gas Cylinder | Capacity | 375L |
| Up-part Description | ||
| Tank | Filling medium | LNG |
| Capacity | 27 CBM | |
| Filling percent | 90% | |
| Filling weight | 10,350kg | |
| Insulation form | High vacuum multi-layer insulation | |
| Inner tank | Dimension | φ2,050*8,569 |
| Material | S30408 | |
| Thickness | 10mm | |
| Design pressure | 1.0Mpa | |
| Working pressure | 1.0Mpa | |
| Outter tank | Dimension | φ2,210*8,827 mm |
| Material | Q345R | |
| Thickness | 6mm | |
| Standard configuration | Equipped with an LNG dispenser, LNG pump, liquid level meter, pressure meter, and thermometer. Equipped with a safe valve, an emergency cut-off valve, an inlet, and an outlet. Equipped with a double toolbox and valve box. |
|
