| Model No.: | CSCPTT024 |
| Propane Tank Volume: | 24CBM |
| Overall Dimensions(LxWxH): | 10,200×2,500×3,450mm |
| Chassis Brand: | HOWO |
| Drive Type: | 6X4 |
| Wheelbase: | 4,600+1,350mm |
| Engine Model: | WD615.69 |
| Engine Power: | 336HP |
| Emission Standard: | EURO III |
| Tank Material: | Carbon steel Q345R |
BRIEF
The HOWO 24 CBM propane tank truck is a robust and efficient vehicle designed for the safe and reliable transport of liquefied petroleum gas (LPG) and propane. Manufactured by CSCTRUCK China Tank Truck, a leading Chinese tank truck producer, this vehicle combines advanced engineering with durable materials to meet the demands of heavy-duty operations.
The propane tank truck is built on the HOWO 6X4 chassis, renowned for its strength and reliability. It features a WD615.69 engine with a power output of 336 horsepower, ensuring excellent performance even in challenging terrains. The engine complies with the EURO III emission standards, balancing power efficiency with environmental considerations.
The tank is constructed from carbon steel Q345R, a high-strength material that enhances durability and safety. With a capacity of 24 cubic meters (CBM), the tank is designed to handle significant volumes of propane while adhering to stringent safety and quality standards. Its robust construction ensures resistance to pressure and potential impacts during transit.
The 6X4 drive configuration provides excellent traction and stability, making it suitable for various road conditions. This configuration, paired with HOWO’s engineering expertise, delivers a seamless balance between power, fuel efficiency, and operational versatility.
In summary, the HOWO 24 CBM propane tank truck by CSCTRUCK China Tank Truck is an ideal solution for bulk propane transportation, offering a blend of high capacity, durable construction, and reliable performance tailored for industrial and commercial applications.
FEATURES
- Large Tank Capacity: Equipped with a 24 CBM (cubic meters) propane tank, offering ample storage for transporting liquefied petroleum gas (LPG).
- High-Performance Engine: Powered by the WD615.69 engine model, delivering 336 HP and compliant with the EURO III emission standard, ensuring a balance of power and environmental compliance.
- Reliable Chassis: Built on a HOWO chassis, renowned for its durability and suitability for heavy-duty applications, ensuring stability and safety on the road.
- Drive Configuration: Features a 6X4 drive type, providing excellent traction and maneuverability, particularly useful for navigating challenging terrains.
- Robust Tank Material: Constructed from carbon steel Q345R, known for its high strength and resilience, ensuring safety and durability for transporting pressurized gases.
SPECIFICATION
| Vehicle | HOWO 24 CBM Propane Tank Truck | ||
| Overall dimensions(LxWxH) | mm | 10,200×2,500×3,450 | |
| Chassis Brand | HOWO | ||
| Tank volume | m3 | 24 | |
| GVW | kg | Appro×24,420 | |
| Curb weight | kg | Appro×14,210 | |
| Payload | kg | Appro×10,080 | |
| Wheelbase | mm | 4,600+1,350 | |
| Axle Load | kg | 7,000/18,000 | |
| Drive system | 6×4 | Steel | Power, Sino |
| Tire specification | 12.00-20 16PR | Number of axles | 3 |
| Engine model | Manufacturer | China National Heavy Duty Truck Group Co ., Ltd | |
| Model | WD615.69 | ||
| Emission/kw | 9,726ml/247kW, 336HP | ||
| Gearbox | 10F&2R | ||
LPG tank performance |
|||
| Designing pressure | Mpa | 1.77 | |
| Working pressure | ≤1.6 | ||
| Hydraulic test pressure | 2.22 | ||
| Air test pressure | 1.77 | ||
| Working temperature | ºC | ≤50 | |
| Tank material | Carbon steel Q345R,16MnIII | ||
