| Model No.: | CSCWTT020 |
| Water Tank Volume: | 20,000 Liters |
| Overall Dimensions(LxWxH): | 10,350×2,496×3,050mm |
| Chassis Brand: | HOWO |
| Drive Type: | 6X4 |
| Wheelbase: | 3,425+1,350mm |
| Engine Model: | WD615.47 |
| Horse Power: | 371HP |
| Emission Standard: | Euro 2 |
| Water Tank Material: | Carbon steel |
BRIEF
The HOWO 20,000-liter water tanker truck, produced by CSCTRUCK China Tank Truck, is a robust and versatile vehicle designed for water transportation and distribution in various industrial, agricultural, and municipal applications. Featuring a 20,000-liter carbon steel water tank, the tanker provides a large capacity for efficient water delivery.
The truck is built on the reliable HOWO chassis, known for its durability and performance, with a 6×4 drive configuration that ensures stability and adaptability across different terrains. It is powered by the WD615.47 engine model, delivering an impressive 371 horsepower to handle heavy loads with ease. This engine complies with the Euro 2 emission standard, balancing power and environmental considerations for regions with developing emission regulations.
Constructed with a carbon steel tank, the vehicle is durable and resistant to wear and tear, making it suitable for long-term use in demanding environments. The tank is equipped with a high-performance pump system for efficient water discharge and can be customized with spray nozzles or firefighting attachments to extend its functionality.
The HOWO water tanker truck’s design emphasizes reliability and efficiency, combining robust engineering with practical features tailored to user needs. Its 6×4 drive type offers enhanced traction, making it suitable for rural, urban, and off-road operations. The truck is particularly useful for tasks such as irrigation, firefighting support, and road cleaning.
Produced by CSCTRUCK China Tank Truck, a reputable manufacturer in China, this water tanker is an economical and high-performing solution for water transport challenges, ensuring efficiency, durability, and reliability in various operational settings.
FEATURES
- Large Tank Capacity: Equipped with a 20,000-liter carbon steel water tank, ideal for transporting significant volumes of water.
- Durable Chassis: Built on a reliable HOWO chassis, ensuring strength and durability for various operational environments.
- Powerful Engine: Features a WD615.47 engine model with 371HP engine power, providing robust performance for heavy-duty tasks.
- 6×4 Drive Type: Designed with a 6×4 drive configuration, offering enhanced traction and stability on challenging terrains.
- Emission Standard Compliance: Meets the Euro 2 emission standard, balancing power output with environmental considerations.
SPECIFICATION
Overview |
|
| Driving type | 6×4 LHD Driving form |
| Horsepower | 371HP |
| Transmission Type | Manual |
| Fuel Type | Diesel |
| Gross Vehicle Weight(kg) | 25,000kg |
| Brand Name | SINOTRUKÂ -HOWO |
| Truck type | ZZ1257N4641W |
| Condition | New |
| Emission Standard | EURO 2 |
| Horse Power | 371HP |
| Engine Capacity | 247L |
| Water tank capacity | 20L |
| Place of Origin | China(Mainland) |
| vehicle size | 10,350mmx2,496mmx3,050mm |
| Driving type | Left hand driving |
1. Basic Vehicle Information |
|
| Color | White, green, orange, and red, colors can be selected |
| Approaching angle/Departure angle(°) | 19/23 |
| Wheelbase (mm) | 3,425+1,350 |
| Axle number | 3 |
| Driveshaft | 2nd and 3rd axes |
| Gross Vehicle Weight(kg) | 25,000 |
2. Engine |
|
| Engine type | WD615.47 |
| Horse Power | 371HP |
| Vehicle torque(N-m) | 1350N·m |
| Maximum Torque and Speed | 1,100-1,600rpm |
| Rated speed | 2,200rpm |
| Engine type | Inline 6-cylinder, water-cooled, four-stroke, supercharged intercooler, high-pressure common rail, SCR. |
| Emission Standard | EURO 2 |
| Engine power(kW) | 247kW |
| Engine weight(kg) | 850kg |
| Number of engine cylinders | 4 |
3. Transmission |
|
| Transmission | HW19710 |
4. Vehicle Chassis |
|
| Allowable Load of Front Bridge(kg) | 9,000 |
| Allowable Load of Rear Bridge(kg) | 16,000 |
| Fuel tanker capacity(L) | 300 |
| ABS | Optional |
| Tyre type | 12.00R20 |
| Tire number | 10+1, Plus a spare tire |
| Types of lifting transportation | Hydraulic front support |
| Front axle type | HF9 |
| Rear axle type | HC16 |
| Rear axle ratio | 5.7 |
| Cab Passenger Number | 3 |
| Cab type | HW76 |
| Air conditioning | YES |
| Frame type | 8+8/300 |
| ABS | NO |
5. Water Tank Parameters |
|
| Water tank capacity | 20m³ |
| Tank thickness | 5mm |
| Tanker dimensions(LxWxH) | 7,650×2,326×1,450mm |
| Remarks | Sprinkling equipment both in front and in rear; Special anti-corrosion treatment. |
