Model No.: | CSCFDTT020 |
Fuel Tank Volume: | 20,000L |
Overall Dimensions(LxWxH): | 9,900×2,500×3,300mm |
Chassis Brand/Model: | SINOTRUK HOWO/ZZ1257N4641W |
Drive Type: | 6×4 |
Wheelbase: | 4,600+1,350mm |
Engine Model: | WD615.69 |
Engine Power: | 336HP |
Emission Standard: | Euro 2 |
Tanker material: | Carbon steel |
Tanker compartment: | 3 |
Categories: Carbon Steel Tank Truck, Fuel Tank Truck
Description
BRIEF
The HOWO 20,000-liter fuel delivery tank truck, produced by CSCTRUCK China Tank Truck, is a versatile and robust vehicle designed for the efficient transportation of fuel. Built on the SINOTRUK HOWO/ZZ1257N4641W chassis, this truck features a durable 6×4 drive configuration, making it suitable for demanding terrains and heavy-duty operations.
The tank truck is powered by the reliable WD615.69 engine, delivering 336 horsepower. This engine complies with the Euro 2 emission standard, balancing power and environmental considerations. The truck’s 20,000-liter tank is constructed from high-quality carbon steel, ensuring durability and resistance to wear and tear. Divided into 3 separate compartments, the tank enhances operational flexibility, allowing the transportation of multiple fuel types or grades simultaneously.
The truck’s design emphasizes functionality and safety. The multi-compartment system reduces fuel sloshing during transit, improving vehicle stability and safety. The carbon steel construction offers superior protection against potential damage, ensuring the tank’s longevity even in harsh operating environments.
HOWO fuel delivery tank truck is ideal for industries requiring reliable fuel transportation, including logistics, oil distribution, and construction. With its robust chassis, powerful engine, and high-capacity tank, this model combines performance, reliability, and efficiency. It is a cost-effective solution for businesses looking to streamline fuel delivery operations, making it a preferred choice in the heavy-duty fuel transport sector.
FEATURES
1. High Capacity Fuel Tank: Equipped with a 20,000-liter tank made of durable carbon steel, divided into 3 compartments for efficient fuel transportation and separation.
2. Robust Chassis: Built on the SINOTRUK HOWO/ZZ1257N4641W chassis, ensuring a strong foundation for heavy-duty fuel delivery tasks.
3. Powerful Engine: Powered by the WD615.69 engine model, delivering 336HP, meeting Euro 2 emission standards, which provides a balance between performance and regulatory compliance.
4. 6×4 Drive Configuration: Offers enhanced traction and stability, making it ideal for both urban and off-road fuel delivery operations.
5. Specialized Design for Fuel Transportation: Features multi-compartment storage to transport different types of fuel safely, with a focus on durability and operational efficiency.
SPECIFICATION
Vehicle Description |
||
Overall dimensions(LxWxH) | 9,900X2,500X3,300mm | |
GVW | 25,000kg | |
Curb weight | 10,805kg | |
Chassis brand | SINOTRUK HOWO | |
Traction type | 6X4 | |
Tanker Description |
||
Tank capacity | 20,000 Liters | |
Tanker material | Carbon steel | |
Thickness | Tanker body | 5mm |
End cover | 5mm | |
Tanker shape | Square | |
Tanker compartment | 3 compartments (Optional: Several compartments). | |
Standard configuration | 3 set manhole (3 sets manhole for a capacity of more than 7,000L+7,500L+7,500L). | |
Equipped with a double discharge valve and valve box. | ||
Equipped with surge baffles, ladder, roof coaming, skid-resistant walkway, and toolbox. | ||
Electrostatic conducting tape and double fire extinguishers. | ||
Optional | Tanker material: Aluminum alloy; stainless steel. | |
Chinese standard configuration is available, or other world-famous fuel configuration. | ||
Overflow probe system, vapor recovery system, bottom valve, and API adaptors. | ||
Emergency bottom valve and foldable aluminum handrail. | ||
Others: Fuel pump, refueling dispenser, flow meter, dipstick, etc. | ||
Chassis Description |
||
Chassis model | ZZ1257N4641W | |
Cab | HW76-extended cab, single berth, adjustable steering wheel, VDO instrument and control module, safety belt with double locking mechanism, exterior sunroof, and air-conditioner. | |
Wheelbase | 4,600+1,350mm | |
Tire specification | 12.00R20 | |
Tire quantity | 10+1 units | |
Engine | Engine model | WD615.69 |
Emission level | Euro 2 | |
Displacement/output | 9,726ml/247kW | |
Horsepower | 336HP | |
Gearbox | Model | HW19710 |
Number of gears | 10 forward gears& 2Â reverse, planetary reducer | |
Brake system | Service brake: Dual-circuit pneumatic brake; | |
Parking brake: Energy storage spring air cutoff brake; | ||
Auxiliary brake: Engine exhaust brake. | ||
Axle | Front | HF-9T |
Rear | ST-16T*2 | |
Suspension | Front | Leaf springs |
Rear | Leaf springs | |
Fuel tanker | Type | Steel tanker, with lockable cap |
Capacity | 400L |
