Model No.:	CSCMFT018
Fuel Tank Volume:	18,000 Liters
Overall Dimensions(LxWxH):	10,200×2,500×3,210mm
Chassis Brand:	HOWO
Drive Type:	6×4
Wheelbase:	4,625+1,350mm
Engine Model:	WD615.69
Engine Power:	336HP
Emission Standard:	Euro II
Loading Capacity:	29,000KG
Tank Material:	Carbon Steel
Max. Speed:	90km/h
Nos of Compartment:	3-6

Truck Enquiry

Categories: Carbon Steel Tank Truck, Fuel Tank Truck

Description

BRIEF

The HOWO 18,000-liter mobile fuel truck, manufactured by CSCTRUCK China Tank Truck, is a robust and versatile solution for fuel transportation. Built on a HOWO 6×4 chassis, the vehicle ensures stability and durability in demanding operations. It is powered by the reliable WD615.69 engine, which delivers 336 horsepower. The truck adheres to the Euro II emission standard, making it suitable for regions with less stringent emission requirements.

The truck features a carbon steel fuel tank with an impressive 18,000-liter capacity. It is segmented into 3 to 6 compartments for carrying different fuel types simultaneously, ensuring operational flexibility. The tank’s construction prioritizes safety and durability, which are essential for transporting hazardous materials.

With a loading capacity of 29,000 kilograms, the tank truck is optimized for high-volume fuel delivery. It is designed to operate efficiently at a maximum speed of 90 km/h, balancing performance and safety during long hauls.

This fuel tanker is an excellent choice for fuel distribution in various industries, including logistics, mining, and construction, thanks to its rugged build and advanced features. Its combination of high capacity, reliable performance, and compliance with essential standards makes it a dependable and cost-effective solution for bulk fuel transport needs.

FEATURES

Large Fuel Tank Capacity
- The truck features an 18,000-liter carbon steel fuel tank, divided into 3-6 compartments for efficient storage and transportation of fuel.
Powerful Engine
- It is equipped with the HOWO WD615.69 engine, delivering 336 HP of power and meeting Euro II emission standards.
High Payload Capability
- The truck has an impressive loading capacity of 29,000 kg, making it ideal for large-scale fuel distribution.
Robust Chassis and Drive Configuration
- Built on a HOWO chassis with a 6×4 drive type, it provides durability and traction suitable for long-distance and varied terrain operations.
Good Speed Performance
- The truck can reach a maximum speed of 90 km/h, ensuring timely delivery of fuel.

SPECIFICATION

Model No.		*CSCMFT018*
Cabin		HW76 Long Cabin, with 2 seats and 1 bed, with Air Conditioner and electric window.
Engine	Model	WD615.69
	Horse Power (HP/rpm)	336/2,200, Euro II Emission Standard
	Max.Torque(Nm/rpm)	1,350/1,100-1,600
	Displacement	9.726L
	Type	6-cylinder in-line with water cooling, turbocharger, and intercooler, 4-stroke direct injection diesel engine.
Transmission		HW19710, 10 speeds forward and 2 speeds reverse.
Front Axle		HF9, Steering with double T-cross section beam, Loading Capacity: 9,000kgs.
Driving Axle		HC16, Pressed axle housing, central reduction with hub reduction, with differential locks between wheels and axles. Ratio: 4.8. Option: 4.42.
Suspension		Front suspension: Hydraulic telescopic double-action shock absorbers and stabilizer; Rear suspension: Leaf semi-elliptic springs, bogie springs, and stabilizer.
Steering System		ZF8118, Hydraulic steering with power assistance.
Brake System		Service brake: Dual circuit compressed air brake; Parking brake (emergency brake): Spring energy, compressed air operating; Auxiliary brake: Engine exhaust brake.
Tire		12.00R20
Fuel Tank Capacity (L)		400L Diesel Tank
Kurb Weight(kg)		12,000
Loading Capacity(kg)		29,000
Gross Vehicle Weight(kg)		41,000
Overall Dimension(LxWxH)(mm)		10,200×2,500×3,210
Tank Capacity(L)		18,000
Tank Material		Carbon Steel
Nos of Compartment		3-6
Wheelbase(mm)		4,625+1,350
Max. Speed (km/h)		90
