| Model No.: | CSCLTT015 |
| LPG tank volume: | 15 CBM |
| Overall Dimensions(LxWxH): | 8,500×2,495×3,250mm |
| Chassis Brand: | HOWO |
| Drive Type: | 4X2 |
| Wheelbase: | 4,700mm |
| Payload: | 5,660kg |
| Engine Model: | YC4E160-33 |
| Engine Power: | 160HP |
| Emission Standard: | EURO III |
| Max Driving Speed: | 95 km/h |
| LPG tank material: | Q345R |
BRIEF
The HOWO 15 CBM LPG transport truck by CSCTRUCK China Tank Truck is a specialized vehicle designed for the efficient and safe transportation of liquefied petroleum gas (LPG). Built on the robust HOWO chassis platform, this truck combines functionality with reliability.
The tank truck features a 15 cubic meter LPG tank made from Q345R material, renowned for its durability and resistance to high pressures. This ensures the safety and integrity of the LPG cargo during transit. Powered by a YC4E160-33 engine, the vehicle delivers 160 horsepower and adheres to the EURO III emission standard, making it both powerful and environmentally compliant.
The truck operates with a 4×2 drive type, providing optimal handling and maneuverability. It has a payload capacity of 5,660 kilograms, making it suitable for medium-scale LPG transport needs. The vehicle’s design supports a maximum driving speed of 95 km/h, allowing for efficient long-haul transportation.
The HOWO chassis provides a strong and reliable foundation, while the tank’s construction and the truck’s performance specifications make it ideal for businesses involved in the LPG distribution industry. This transport truck is a cost-effective solution tailored for durability, safety, and compliance with industry standards. Whether used for urban delivery or inter-city transport, the HOWO 15 CBM LPG transport truck is a reliable choice for modern logistics operations.
FEATURES
- Tank Capacity & Material:
- 15 CBM LPG tank volume, made from durable Q345R material, ensuring high strength and safety for gas transport.
- Chassis & Drive Type:
- Built on the trusted HOWO chassis with a 4X2 drive type, offering reliable performance and maneuverability.
- Engine Specifications:
- Equipped with the YC4E160-33 engine producing 160 HP, compliant with the EURO III emission standard for reduced environmental impact.
- Payload & Speed:
- Capable of carrying a payload of 5,660 kg with a maximum driving speed of 95 km/h, ideal for efficient and timely delivery.
- Safety & Design:
- Designed specifically for LPG transport with stringent safety measures, including robust construction and advanced engineering for secure operations.
SPECIFICATION
| Item No. | Parameters |
| Overall Dimensions(LxWxH) | 8,500×2,495×3,250mm |
| Driving Model | Right-hand drive |
| Gross Vehicle Weight | 15,795kg |
| Curb Weight | 9,940kg |
| Payload | 5,660kg |
| Wheel Base | 4,700mm |
| Front/rear Tread | 1,886/1,845 mm |
| Approach/Departure Angle | 27/20Â degree |
| Engine | Yuchai 4110, YC4E160-33 |
| Engine horsepower | 160 HP, EURO III |
| Displacement | 4,260ml(Diesel) |
| Max Driving Speed | 95km/h |
| Cabin | 2~3 Passenger allowed, with A/C |
| Tire | 9R20Â (6 pc with 1 spare) |
| LPG tank | |
| Volume: | 15 CBM |
| Tank material: | Q345R |
| Tank diameter: | 2,000mm |
| Tank thickness: | 10mm |
| End plate | 10mm |
| Tank length: | 5,140mm |
| Gas phase | DN50 |
| Liquid Phase | DN50 |
| Filling gas | Propane(LPG) |
| Design Pressure: | 1.61Mpa |
| Accessory | |
| Level Gauge | Manual rotation type, at the rear of the tank |
| Safety Valve | 1, DN80 |
| Tool and Valve Box | 1 |
| Thermometer | 1 |
| Pressure Gauge | 1 |
| Emergency Valve | 1 |
| Fender | Steel |
| Fire Extinguisher | 2 |
| Exhaust shaft | At the front of the truck for safety. |
| Tank Mounted on Chassis Brand |
|---|
