| Model No.: | CSCFRT030 |
| Fuel Tank Volume: | 30,000 liters |
| Overall Dimensions(LxWxH): | 11,925×2,500×3,500mm |
| Chassis Brand: | FOTON Auman5 |
| Drive Type: | 8×4 |
| Wheelbase: | 1,860+4,700+1,350mm |
| Max. driving speed(km/h): | 95 |
| Engine Model: | Cummins ISD245 50 |
| Engine Power: | 245HP |
| Emission Standard: | Euro 5 |
| Tank material: | Q235 carbon steel |
BRIEF
The FOTON Auman5 30,000-liter fuel refueling truck, produced by CSCTRUCK China Tank Truck, is a robust and efficient tanker designed for large-scale fuel transportation. It features a 30,000-liter fuel tank made from Q235 carbon steel, ensuring durability and resistance to corrosion. Built on the FOTON Auman5 chassis, the truck boasts an 8×4 drive configuration, providing exceptional stability and traction for heavy-duty operations.
Under the hood, the tank truck is powered by the Cummins ISD245 50 engine, delivering 245 horsepower with adherence to the Euro 5 emission standard, making it both powerful and environmentally conscious. This engine ensures reliable performance while meeting stringent global emission regulations. The truck can achieve a maximum driving speed of 95 km/h, making it suitable for both urban and highway operations.
The advanced design of this tanker truck makes it ideal for long-haul fuel transport, distribution, and refueling applications. Its sturdy Q235 carbon steel tank is well-suited for carrying various types of fuel securely. The FOTON Auman5 chassis and Cummins engine provide a blend of performance, efficiency, and durability, making it a preferred choice in the fuel logistics industry.
The FOTON Auman5 30,000-liter fuel refueling truck is a high-performance vehicle tailored to meet the needs of large-scale fuel distribution, combining innovative engineering with a reliable and efficient powertrain.
FEATURES
- Large Fuel Capacity
- The truck is equipped with a 30,000-liter Q235 carbon steel fuel tank, designed for efficient fuel transportation.
- Robust Chassis and Drive Configuration
- Built on the FOTON Auman5 chassis with an 8×4 drive type, ensuring durability and stability for heavy-duty operations.
- High-Performance Engine
- Powered by a Cummins ISD245 50 engine, delivering 245 HP and complying with Euro 5 emission standards for cleaner operations.
- Optimal Speed for Long-Distance Hauling
- Capable of reaching a maximum driving speed of 95 km/h, making it suitable for highway transportation.
- Durable and Corrosion-Resistant Materials
- The tank is constructed from Q235 carbon steel, offering excellent strength and resistance to wear and tear during fuel transportation.
SPECIFICATION
| Condition | NEW | ||
| Chassis | Brand | FOTON Auman5 | |
| Curb weight(kg) | 10,700 kg | ||
| Wheelbase(mm) | 1,860+4,700+1,350 mm | ||
| Dimensions(mm) | 11,925×2,500×3,500 mm | ||
| Front/Rear Axle loading(kg) | 6,500/7,000/18,500 kg | ||
| Wheel track (front/rear) (mm) | 1,960/1,955 mm | ||
| Front/Rear overhang(mm) | 1,555/2,410 mm | ||
| Approach/Departure angle(°) | 19/19 | ||
| Max. driving speed(km/h) | 95 km/h | ||
| Clutch | Reinforced diaphragm clutch | ||
| Brakes | Service brake: Dual circuit compressed air brake                                 Parking brake: (Emergency brake): Spring energy, compressed air operating on rear wheels Auxiliary brake: Engine exhaust valve brake |
||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Tire | Quantity | 10 pcs with 1 spare tire | |
| Specifications | 12R22.5 | ||
| Transmission | Manual type, 6 Forwards and 1 reverse. | ||
| Cab | It can accommodate 3 people. With Air Conditioner. | ||
| Engine | Brand | Cummins | |
| Model | ISD245 50Â | ||
| Fuel type | Diesel | ||
| Displacement(ml) | 6,700 ml | ||
| Power(kW) | 180kW | ||
| Horsepower(HP) | 245HP | ||
| Cylinder number | 4 | ||
| Emission standard | Euro 5 | ||
Fuel Tank |
|||
| Fuel tank | Capacity(CBM/liters) | 30CBM/30,000 liters | |
| Tank material | Tank material: Q235 high tensile strength steel. | ||
| Thickness(mm) | 6mm of the tank and 7mm of the end plate. | ||
| Compartment No. | 2 | ||
| Baffle | 1 No, 4 mm carbon steel | ||
| Manhole cover | 2 manhole covers ∮500mm 2 sets with 2 breather valves | ||
| Bottom Valve | 2 sets of API Pneumatic Bottom Valves | ||
| Discharging valve | 2 set ∮ discharging valves | ||
| Handrail | Two sides | ||
| Ladder | At the rear of the tank | ||
| Painting | Color and design as customer’s requirement. | ||
