| Model No.: | CSCWTT035 |
| Water Tank Volume: | 9,000 Liters |
| Overall Dimensions(LxWxH): | 7,050×2,100×2,700mm |
| Chassis Brand: | FOTON |
| Drive Type: | 4X2 |
| Wheelbase: | 3,800mm |
| Engine Model: | YC4E120-33 |
| Emission Standard: | Euro 3 |
| Max Speed: | 103km/h |
| Water Tank Material: | Carbon steel |
BRIEF
The FOTON 9000-liter water tanker truck, manufactured by CSCTRUCK China Tank Truck, is a robust and efficient vehicle designed for various water transportation needs. This model combines a reliable FOTON chassis with high-quality engineering to meet demanding operational requirements.
Key features of the truck include a 9,000-liter water tank capacity constructed from durable carbon steel, ensuring strength and longevity in harsh conditions. The truck operates on a 4×2 drive type, making it suitable for urban and suburban environments with paved roads and moderate off-road capability.
Under the hood, the vehicle is powered by the YC4E120-33 engine, which complies with the Euro 3 emission standard. This engine delivers a balance of performance and efficiency, with the maximum driving speed rated at 103 km/h, allowing for timely water delivery operations.
The design and functionality of the FOTON 9000-liter water tanker truck make it versatile for multiple applications, such as municipal water supply, construction site support, and dust suppression. The use of carbon steel for the tank ensures resistance to corrosion and external impact, while the FOTON chassis provides a stable and reliable platform for long-term use.
With its combination of durability, performance, and compliance with international emission standards, the FOTON 9000-liter water tanker truck is a valuable solution for businesses and municipalities in need of an efficient water transport system.
FEATURES
- Tank Capacity and Material: Equipped with a 9,000-liter carbon steel water tank for reliable water transportation and durability.
- Chassis and Drive Type: Built on a FOTON chassis with a 4×2 drive type for efficient handling and maneuverability.
- Engine and Emission Standard: Powered by a YC4E120-33 engine model with a Euro 3 emission standard, ensuring an environmentally compliant and powerful performance.
- Maximum Speed: Capable of achieving a maximum driving speed of 103 km/h for swift and efficient water delivery.
- Manufacturer and Build: Designed and manufactured by CSCTRUCK China Tank Truck, a reputed Chinese manufacturer specializing in high-quality tank trucks.
SPECIFICATION
| FOTON 9000 Liters Water Tanker Truck | ||
| Vehicle Parameters | ||
| General | Vehicle Model | CSCWTT035 |
| Vehicle Brand | CSCTRUCK | |
| Chassis Brand | Foton | |
| Overall Dimension(mm)(LxWxH) | 7,050×2,100×2,700 | |
| GVW/Curb Weight(kg) | 11,450/4,695 | |
| Chassis Parameters | ||
| Cab | Cab Seat | 2 |
| Air Conditioner | Optional | |
| Engine | Fuel Type | Diesel |
| Engine Model | YC4E120-33 | |
| Engine Brand | Yuchai | |
| Emission Standard | Euro 3 | |
| Chassis | Drive Type | 4×2 |
| Wheelbase(mm) | 3,800 | |
| Tyre Specification | 7.50R16 | |
| Tyre No.(pcs) | 6 | |
| Max Speed(km/h) | 103 | |
| Leaf  Spring |  8/10+7 | |
| Axle Load | 4,360/7,090kg | |
| F/RÂ Tread | 1,745/1,620kg | |
| F/RÂ Overhang | 1,130/2,120mm | |
| Superstructure | ||
| Tank | Tank capacity | 9,000 Liters |
| Tank material | Carbon steel | |
| Equipment | Equipped with front(rear, side) sprinkler(sprinkling width>14m) | |
| Equipped with a rear working platform with a water cannon(range>28m) | ||
| Equipped with CS pump(suction lift>6m) | ||
| Equipped with a fire valve, water valve, and filter gauze. | ||
| Tank Mounted on Chassis Brand |
|---|
