| Model No.: | CSCFDT016 |
| Tank Volume: | 16 CBM |
| Overall Dimensions(LxWxH): | 8,500×2,480×3,050mm |
| Chassis Brand: | FOTON |
| Drive Type: | 4×2 |
| Wheelbase: | 4,700mm |
| Rated payload: | 8,700kg |
| Engine Model/Power: | ISB170 30/170HP |
| Emission Standard: | EURO III |
| Maximum speed: | 80(km/h) |
| Tank Material: | Carbon Steel |
Description
BRIEF
The FOTON 16 CBM fuel delivery truck, manufactured by CSCTRUCK China Tank Truck, is a robust and efficient solution for fuel transportation. Designed with a 16-cubic-meter fuel tank capacity, this vehicle caters to medium-scale fuel delivery operations with precision and reliability. Built on the reliable FOTON chassis, the truck features a 4×2 drive type, ensuring stability and maneuverability for various road conditions.
The tank truck is powered by a Cummins ISB170 30 engine, offering a solid 170 horsepower and adhering to EURO III emission standards. This makes it an environmentally conscious choice for fuel transport while providing a maximum speed of 80 km/h, balancing efficiency and safety during operations.
The tank is constructed from durable carbon steel, ensuring longevity and resistance to wear and corrosion. With an impressive payload capacity of 8,700 kilograms, the FOTON fuel truck is optimized for high-performance fuel distribution while maintaining structural integrity under load.
This fuel delivery truck is an excellent choice for businesses requiring reliable and efficient fuel delivery. Its combination of advanced engineering, sturdy construction, and adherence to international standards highlights its quality and suitability for the fuel transport industry.
FEATURES
1. Tank Capacity and Material
  – The truck features a 16 CBM (16,000 liters) fuel tank made of carbon steel, ensuring durability and resistance to fuel corrosion.
2. Chassis and Drive Type
  – Built on a FOTON chassis with a 4×2 drive type, providing reliability and efficient performance for fuel transport.
3. Engine and Emissions
  – Powered by the ISB170 30 engine model with 170 HP engine power, meeting EURO III emission standards for reduced environmental impact.
4. Payload and Speed
  – It boasts an 8,700 kg payload capacity and a maximum speed of 80 km/h, ideal for safe and efficient fuel distribution.
5. Design and Build Quality
  – Designed for durability and efficiency, this fuel delivery truck integrates robust engineering with advanced safety and operational features for professional-grade fuel transportation.
SPECIFICATION
Product Details |
|
| Chassis brand | FOTON |
| Drive form | LHD or RHD optional |
| Emission standard | Euro 2/3/4/5 optional |
| Drive model | 4×2 |
| Drive form | LHD or RHD Â optional |
| Cab type | One-and-a-half cabin, with a sleeper |
| Overall dimensions(LxWxH) | 8,500×2,480×3,050mm |
| Tanker dimensions(LxWxH) | 5,800×2,250×1,480mm |
| Tanker capacity | 16 CBM |
| Tanker material | Carbon steel |
| Engine brand | CUMMINS engine |
| Engine model | ISB170 30/33/40 optional |
| Horsepower | 170hp |
| Displacement | 5,900ml |
| Emission standard | Euro 2/3/4/5 |
| Total weight | 16,000kg |
| Tare weight | 7,105kg |
| Rated payload | 8,700kg |
| Wheelbase | 4,700mm |
| Max speed | 80km/h |
| Tyre type | 10.00R20 steel wire tire |
| Tire number | 6+1 (with a spare tire ) |
| Transport medium | Gasoline, diesel, kerosene |
| Braking system | Air brake |
| Electrical system | 24 voltage,7 wire harnesses, LED lights. |
| Painting | With shot blasting and 4 layers of paint, color is optional. |
| Packing | Nude, polish with wax before shipment. |
| Remark | The above-mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
