FAW 7 Ton LPG Bobtail Truck

BRIEF

The FAW 7-Ton LPG Bobtail Truck is a comprehensive solution designed for the efficient and safe transportation of LPG (Liquid Petroleum Gas). This versatile vehicle comprises a FAW truck chassis, an LPG tank, an LPG vane pump, and a PLG filling system that includes essential instruments like a flow meter, temperature meter, a 15-meter filling hose, and a filling gun. The LPG tank is optimized for transporting LPG, specifically when it comprises a butane-propane mixture, with a maximum limit on the weight of propane, set at 30%.

FEATURES

Chassis and Performance
- Equipped with a FAW truck chassis, boasting a 160hp engine.
- Adheres to Euro 3 emission standards.
- Fitted with an 8-speed manual transmission (8 front gears and 1 reverse).
- Tire specifications: 10.00R20, including 6 regular tires and 1 spare tire.
Vane Pump
- Features the reliable USA Corken vane pump, specifically the Z2000 model, ensuring efficient and secure LPG transfer.
LPG Tank
- The LPG tank holds a substantial 15,000 liters of content and is constructed from durable Q345R material, featuring a 10mm thickness.
- It offers a substantial loading capacity of 7 tons, making it versatile for a variety of LPG transportation needs.
Instrumentation
- The vehicle comes equipped with standard instruments, including a pressure meter, temperature meter, and liquid gauge, for accurate monitoring and control.
Optional Electronic Scale
- For precision and accuracy in LPG measurements, an electronic scale is available as an optional feature.

SPECIFICATIONS

Chassis
Size	8,350 x 2,400 x 3,250 (mm)
GVW/Curb Weight	16,000/8,500 kg
Wheelbase	4,700 mm
Tire	10.00R20, 6 regular tires + 1 spare tire
Engine
Type	Diesel
Make/Model	Weichai / WP4.165E32 / 160hp / Euro 2
Transmission
Model	Fannxi FAST/8JS85TE
Gears	8F + 1R
Operation	Manual
Cabin
Driving	Tiger V, 4×2, LHD / RHD
Type	Seats, radio, MP3
Passenger No.	3
LPG TANK
Filling Medium	LPG
Capacity	7 tons / 15,000 Liters
Working Temperature	-40 ~ 50°C
Tank Material	Q345
Tank Diameter	1,800 mm
Tank Thickness	10 mm
End Plate Thickness	10 mm
Tank Length	5,070 mm
Gas Phase	Flange Type, DN50/2”, other sizes optional
Liquid Phase	Flange Type, DN50/2”, other sizes optional
Working Pressure	1.61 Mpa
Design Pressure	1.71 Mpa
Testing Pressure	2.21 Mpa
Corrosion Allowances	1.0 mm
