| Model No.: | CSCOTRT025 |
| Fuel Tank Volume: | 25,000 Liters |
| Overall Dimensions(LxWxH): | 11,990X2,500X3,400mm |
| Chassis Brand: | Benz |
| Drive Type: | 6×4 |
| Wheelbase: | 4,600+1,350mm |
| Engine Model: | MC07.34-50 |
| Engine Power: | 340HP |
| Emission Standard: | Euro 5 |
| Tanker material: | Carbon steel |
| Max. driving speed: | 95km/h |
Description
BRIEF
The Benz 25,000-liter oil tank refueling truck, manufactured by CSCTRUCK China Tank Truck, is a robust and efficient vehicle designed for the transportation and refueling of large quantities of oil. Built on a reliable Benz chassis, it features a 6×4 drive configuration, ensuring excellent traction and stability on various terrains. The truck is powered by the MC07.34-50 engine model, delivering a formidable 340 horsepower while complying with the Euro 5 emission standard, making it environmentally friendly and fuel-efficient.
The truck’s tank has a 25,000-liter capacity and is constructed from durable carbon steel, offering long-term resistance to corrosion and mechanical wear. This makes it suitable for carrying flammable liquids like oil and fuel safely and securely. The tank design and materials meet industry safety standards, providing peace of mind during operation.
Capable of reaching a maximum driving speed of 95 km/h, this tank truck combines speed with stability, making it suitable for long-distance transportation. Its engineering supports high performance even under heavy loads, ensuring reliable functionality in demanding operations.
Overall, the Benz 25,000-liter oil tank refueling truck represents a perfect blend of power, efficiency, and safety, tailored for large-scale oil distribution. It is an ideal choice for fuel transport companies, logistics providers, and industrial operations seeking a dependable solution for their fuel delivery needs.
FEATURES
1. Large Tank Capacity: Equipped with a 25,000-liter fuel tank, suitable for large-scale refueling operations.
2. Benz Chassis with 6×4 Drive: Built on a reliable Benz chassis with a 6×4 drive type, ensuring robust performance and excellent off-road capabilities.
3. Powerful Engine: Powered by an MC07.34-50 engine with 340HP, adhering to the Euro 5 emission standard for reduced environmental impact.
4. Durable Tank Material: The fuel tank is made of carbon steel, offering strength and resistance to wear and tear.
5. Optimal Speed and Efficiency: Capable of achieving a maximum driving speed of 95 km/h, balancing speed and safety for long-distance refueling tasks.
SPECIFICATION
| Condition | New condition/RHD hand drive or left-hand drive/6×4 | ||
| Chassis | Brand | ||
| Curb weight(kg) | 11,450 kg | ||
| Wheelbase(mm) | 4,600+1,350 mm | ||
| Dimensions(mm) | 11,990X2,500X3,400 mm | ||
| Front/Rear Axle loading(kg) | 6,500/7,000/18,500 kg | ||
| Wheel track (front/rear) (mm) | 2,015/2,035 mm | ||
| Front/Rear overhang(mm) | 1,430/2,465 mm | ||
| Approach/Departure angle(°) | 19/19 | ||
| Max. driving speed(km/h) | 95 km/h | ||
| Clutch | Reinforced diaphragm clutch | ||
| Brakes | Service brake: Dual circuit compressed air brake                              Parking brake: (Emergency brake): Spring energy, compressed air operating on rear wheels Auxiliary brake: Engine exhaust valve brake |
||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Tire | Quantity | 10Â pcs with one spare tire | |
| Specifications | 12.00r20 | ||
| Transmission | Manual type, 6 Forwards and 1 reverse. | ||
| Cab | It can accommodate three people. With Air Conditioner. | ||
| Engine | Brand | Sinotruk | |
| Model | MC07.34-50 | ||
| Fuel type | Diesel | ||
| Displacement(ml) | 6,870 ml | ||
| Power(kW) | 248kW | ||
| Horsepower(HP) | 340HP | ||
| Cylinder number | 4 | ||
| Emission standard | Euro 5 | ||
Fuel Tank |
|||
| Fuel tank | Capacity(CBM/liters) | 25 CBM/25,000 liters | |
| Tank material | Tank material: Q235 high tensile strength steel. | ||
| Thickness(mm) | 6mm of the tank and 7mm of the end plate. | ||
| Compartment No. | 2 | ||
| Baffle | 1 No, 4 mm carbon steel | ||
| Manhole cover | 2 manhole covers, ∮500mm 2 sets with 2 breather valves | ||
| Bottom Valve | 2 sets of API Pneumatic Bottom Valves | ||
| Discharging valve | 2 sets ∮ discharging valves | ||
| Handrail | 2 sides | ||
| Ladder | At the rear of the tank | ||
| Painting | Color and design as customer’s requirement. | ||
