| Model No.: | CSCMFT020 |
| Fuel Tank Volume: | 20 CBM |
| Overall Dimensions(LxWxH): | 11,000×4,000×3,400mm |
| Chassis Brand: | Beiben |
| Drive Type: | 8×4 |
| Wheelbase: | 1,995+4,000+1,350mm |
| Engine Model: | WP7.300E30 |
| Engine Power: | 300HP |
| Emission Standard: | Euro 3 |
| Loading Capacity: | 16,000KG |
| Tank Material: | Aluminum Alloy |
| Max. Speed: | 100km/h |
BRIEF
The Beiben 20 CBM mobile fuel truck is a robust and efficient solution for fuel transportation, produced by CSCTRUCK China Tank Truck, a leading manufacturer in the industry. This vehicle combines a high-capacity fuel tank with reliable performance features, making it ideal for fuel distribution needs.
The tank truck boasts a 20 CBM (20,000 liters) aluminum alloy fuel tank, ensuring lightweight construction while maintaining strength and durability. The material choice enhances corrosion resistance and extends the tank’s lifespan, making it suitable for transporting various fuel types. Its 16,000 KG loading capacity provides ample room for significant payloads, increasing operational efficiency.
Built on the reliable Beiben chassis with an 8×4 drive type, the truck offers superior stability and maneuverability, especially under heavy loads or challenging road conditions. The powertrain is driven by the WP7.300E30 engine, which delivers 300 horsepower of robust performance, ensuring efficient hauling capabilities. Adhering to the Euro 3 emission standard, the engine balances power and environmental considerations, meeting regulatory requirements in numerous markets.
This fuel truck is designed for practicality and speed, achieving a maximum driving speed of 100 km/h, which supports timely deliveries across distances. Its engineering emphasizes reliability, efficiency, and safety, critical for fuel transportation.
In summary, the Beiben 20 CBM mobile fuel truck combines a durable chassis, powerful engine, and lightweight tank design, offering a highly capable and cost-effective solution for bulk fuel distribution. It reflects CSCTRUCK China Tank Truck’s commitment to quality, innovation, and meeting the demands of the fuel transport industry.
FEATURES
- Large Fuel Tank Capacity: Equipped with a 20 CBM (cubic meter) aluminum alloy fuel tank, ensuring lightweight durability and a substantial volume for fuel transportation.
- High-Performance Engine: Powered by the WP7.300E30 engine model, delivering 300 horsepower with Euro 3 emission standards, suitable for efficient and eco-compliant operations.
- Robust Chassis and Drive Type: Built on a reliable Beiben chassis with an 8×4 drive configuration, offering enhanced stability and traction for heavy-duty transport.
- Impressive Loading and Speed Capabilities: Supports a maximum loading capacity of 16,000 kg and achieves a top driving speed of 100 km/h, making it efficient for long-distance fuel delivery.
- Durable and Efficient Design: Incorporates an aluminum alloy fuel tank for reduced weight and corrosion resistance, coupled with advanced engineering for robust performance and operational efficiency.
SPECIFICATION
| Vehicle Description | Brand | CSCTRUCK China Tank Truck |
| GVW(kg) | 31,000 | |
| Curb Weight(kg) | 13,500 | |
| Loading Weight(kg) | 16,000 | |
| Overall Dimension(mm) | 11,000*4,000*3,400 | |
| Wheelbase(mm) | 1,995+4,000+1,350 | |
| Top Speed(km/h) | 100 |
| Chassis Brand | BEIBEN | |
| Chassis Model | ND13100D44J | |
| Cabin | Single, LHD, with A/C | |
| Engine | Model | WP7.300E30 |
| HP | 300 | |
| Emission Standard | Euro 3 | |
| Displacement/Output(ml/kW) | 7,140/220 | |
| Fuel Type | Diesel | |
| Rate Speed(rpm) | 2,300 | |
| Maximum Torque(N·m) | 1,160 | |
| Maximum Torque Speed(rpm) | 1,200-1,600 | |
| Gearbox Brand | BEIBEN | |
| Gearbox | 9Forward/1Reverse Gear | |
| Tyre | 11.00R20 | |
| Fuel Tank | Capacity(m³) | 20 |
| Tank Material | Aluminium Alloy | |
| Compartments | 8 Units(2,000L/2,000L/2,000L/4,000L/4,000L/4,000L/6,000L/6,000L)(can be customized) | |
| Manhole | 3 Units-16″Aluminium Alloy | |
| 5 Units-20″Aluminium Alloy | ||
| Foot Valves | 8 Units-4″Aluminium Alloy, Pneumatic Operate | |
| Discharge Ball Valves | 8 Units-2.5″Aluminium Alloy |
