| Model No.: | CSCOTRT008 |
| Tank Volume: | 8,000 Liters/8m3 |
| Overall Dimensions(LxWxH): | 7,200×2,320×3,120(mm) |
| Chassis Brand: | FORLAND |
| Drive Type: | 4×2 |
| Wheelbase: | 3,900(mm) |
| Loading Weight: | 7,035(kg) |
| Engine Power: | 130HP |
| Emission Standard: | EURO III |
| Maximum speed: | 90(km/h) |
| Tank Material: | Q235B Carbon Steel |
Description
BRIEF
The 8,000-liter oil tank refueling truck by CSCTRUCK China Tank Truck is a reliable and efficient solution for fuel transportation and refueling operations. Built on the robust FORLAND chassis, this truck is designed for optimal performance and durability. With a 4×2 drive configuration, it is well-suited for urban and regional operations, ensuring stability and maneuverability.
The tank truck’s Q235B carbon steel tank has a capacity of 8,000 liters. It offers durability and resistance to corrosion, making it ideal for safe fuel transport. Its gross loading weight of 7,035 kg ensures efficient payload handling. Powered by a 130HP engine, the truck delivers a balance of power and fuel economy, adhering to the EURO III emission standards for reduced environmental impact.
The refueling truck boasts a top speed of 90 km/h, enabling timely deliveries across various distances. Its sturdy design and advanced engineering make it a dependable choice for industries such as logistics, construction, and fuel supply services.
This tanker is a testament to quality and performance. It is engineered with precision and manufactured by CSCTRUCK China Tank Truck, a trusted name in heavy vehicle production. Its advanced specifications ensure compliance with international standards, making it a competitive choice in the global market.
FEATURES
1. Tank Capacity and Material:
  – The truck is equipped with an 8,000-liter tank made of Q235B carbon steel, ensuring durability and resistance to wear and corrosion.
2. Chassis and Drive Configuration:
  – Built on a FORLAND chassis with a 4×2 drive type, offering reliable performance and maneuverability for various terrains.
3. Engine Power and Emission Compliance:
  – Powered by a 130HP engine that meets the EURO III emission standard, balancing performance with environmental considerations.
4. Payload Capacity:
  – Designed to handle a loading weight of 7,035 kg, making it suitable for large-scale refueling operations.
5. Performance and Speed:
  – Capable of reaching a maximum speed of 90 km/h, providing efficient transportation and delivery times.
SPECIFICATION
General Technical Parameters |
||||
| Overall Dimensions(LxWxH) | 7,200*2,320*3,120 (mm) | Gross Vehicle Weight | 12,000(kg) | |
| Curb Weight | 5,170(kg) | Loading Weight | 7,035(kg) | |
Chassis Specification |
||||
| Chassis parameters | Chassis Brand | FORLAND | ||
| Cabin | Single, Left-Hand Driving | |||
| Engine | Power | 130HP | ||
| Emission standard | EURO III | |||
| Displacement | 3.7L | |||
| Fuel type | Diesel | |||
| Gearbox | 6Â Forward & 1 Reverse Gear | |||
| Front and Rear Axle load | 3.5T rear axle | |||
| Wheel Base | 3,900(mm) | |||
| Overhang(Â Front/Rear) | 1,040/1,647(mm) | |||
| Angle(Approach/departure) | 16/14(°) | |||
| Brake System | Pneumatic | |||
| Steering Gear | Power Assistant | |||
| Tire | 8.25-15, 6 Pieces | |||
| Maximum speed | 90(km/h) | |||
Superstructure |
||||
| Fuel Tanker | Tank Volume | 8,000 Liters / 8m3 | ||
| Tank Material | Q235B Carbon Steel | |||
| Tank Shape | Square Round | |||
| Transport oil type | Diesel/Petrol | |||
| Refueling system | Oil Pump | 1pc, Chinese famous brand | ||
| Oil dispenser | 1pc, a Chinese famous brand, Digital Screen Display with Keyboard, Oil Filling Display in Liter, Price & Amount. | |||
| Hose Reel with Filling Gun | 6 Meters (Length can be longer as per request), Corrosion Resistant. | |||
| Equipment | Lifting fence, ladder, Manhole 1 Unit, Emergency cut-off valve 1 Unit. | |||
| Optional API standard system | Anti-overflow probe Oil Vapor Recovery System. |
|||
Additional information
| Tank Mounted on Chassis Brand |
|---|
