Model No.:	6×6 10 CBM Crude Oil Tank Truck
Crude oil tank volume:	10 CBM
Overall dimensions(LxWxH):	8,000×2,500×3,200mm
Chassis Brand:	Dongfeng
Drive Type:	6×6
Wheelbase:	3,500+1,250mm
Engine Model:	EQB190 20
Engine Power:	190HP
Emission Standard:	Euro 2
Crude Oil Tank Material:	Carbon steel

Truck Enquiry

Categories: Carbon Steel Tank Truck, Crude Oil Tank Truck

Description

BRIEF

The 6×6 10 CBM crude oil tank truck produced by CSCTRUCK China Tank Truck is a robust and reliable vehicle designed for the efficient transportation of crude oil. Built on the durable Dongfeng chassis, this tank truck is well-suited for various challenging terrains and demanding operational environments.

Powering this tank truck is the EQB190 20 engine model, a formidable unit that delivers 190 horsepower. This engine is built to comply with the Euro 2 emission standard, making it a relatively environmentally friendly option compared to older engines. Despite its high power output, the EQB190 20 engine balances performance with fuel efficiency, ensuring that the truck can handle long-distance hauls with ease.

The centerpiece of this crude oil tank truck is its 10 CBM (cubic meters) carbon steel tank. This sizable tank is specifically designed for carrying crude oil, with robust construction that ensures durability and safety. The use of carbon steel in the tank’s construction provides excellent strength and resistance to the corrosive nature of crude oil, ensuring a long service life and reducing maintenance needs.

This 6×6 configuration enhances the truck’s off-road capabilities, providing superior traction and stability across a variety of surfaces. This makes it an ideal choice for operations in remote or undeveloped areas where road conditions can be unpredictable.

Overall, the 6×6 10 CBM crude oil tank truck by CSCTRUCK China Tank Truck combines strong performance, durability, and reliability. Its powerful engine, substantial tank capacity, and rugged design make it a valuable asset for companies involved in the transportation of crude oil.

FEATURES

1. Chassis Manufacturer: The truck is built on a Dongfeng chassis, known for its reliability and robustness, making it suitable for heavy-duty applications.

2. Engine Specifications: It is equipped with an EQB190 20 engine model, delivering 190 horsepower, and providing sufficient power for transporting heavy loads over long distances.

3. Emission Standard: The engine complies with the Euro 2 emission standard, ensuring a balance between performance and environmental impact.

4. Tank Capacity: The truck has a 10 cubic meter(CBM) carbon steel tank designed for transporting crude oil, offering a large capacity for industrial and commercial needs.

5. Drive Configuration: The 6×6 drive configuration provides enhanced traction and stability, making it suitable for various terrains and challenging driving conditions often encountered in oil transportation.

SPECIFICATION

Vehicle Description
Overall dimensions(LxWxH)	8,000×2,500×3,200mm
GVW	15,800kg
Curb weight	7,805kg
Chassis brand	DONGFENG KR
Traction type	6×6, left-hand drive
Chassis Description
Chassis model	EQ2102
Cab	Flat-roof, half row
Wheelbase	3,500+1,250mm
Tire specification	12.5R20
Tire quantity	6+1 units
Engine	Engine model		EQB190 20
	Emission level		Euro 2
	Displacement/output		6,700ml/140kW
	Horsepower		190HP
Gearbox	Type		6MT
	Number of gears		6 forward gears& 1 reverse
Brake system	Full air brake system
Axle	Front		4T- Elliot type, I beam section
	Rear		4.4Tx2
Suspension	Front		7- Leaf spring with shock absorber
	Rear		9+6-Leaf spring
Fuel tanker	Type		Steel fuel tank, with lockable cap
	Capacity		160L
Up-part Description
Tanker	Capacity	10 CBM
	Material	Carbon steel
	Thickness	5mm
Standard configuration	Equipped with 2 sets of manholes. Equipped with a double discharge valve and valve box. Equipped with refueling dispenser, and flow meter. Equipped with surge baffles, ladder, roof coaming, skid-resistant walkway, and toolbox. Equipped with electrostatic conducting tape and double fire extinguishers.
Optional configuration	Tanker material: Aluminum alloy; stainless steel Chinese standard configuration is available, or other world-famous fuel configuration. The whole set of European configurations for each compartment: European type manhole, overflow probe system, vapor recovery system, bottom valve, API adaptors. Emergency bottom valve and foldable aluminum handrail. Others: Fuel pump, refueling dispenser, flow meter, dipstick, etc.
