BRIEF
The 62 CBM 30 Ton LPG Semi Trailer is purpose-built for the extensive and long-distance transportation of LPG from major gas stations or terminal gas stations to smaller ones within various cities. This trailer is equipped for efficient loading and unloading of both liquid and vapor phases, catering to the needs of diverse gas transport companies. Its design complies with rigorous industry standards, including GB-150, ASME U STAMP, CCC, and ISO.
FEATURES
- Tank and Capacity
- Tank Material: High-strength Q345 with a 12mm thickness
- Tank Volume: 61.9CBM
- Axles and Tires
- Axles: Three robust 12T axles
- Tires: Equipped with durable 12R22.5 tubeless tires, including a spare tire
- Support and Stability
- Supporting Legs: JOST brand two-speed, manually operated heavy-duty supporting legs
- Measurement and Control
- Gauges: Includes essential instruments such as a ROCHESTER level gauge, flow meter, and optional sun shelter
- King Pin Options
- Choose between 50 or 90 kingpins to suit your needs
SPECIFICATION
| Tank | |
| Filling Medium | Transporting LPG (flammable Propane) |
| Volume | 61.9CBM |
| Overall Dimensions (LxWxH) | 13,350 x 2,550 x 3,995mm |
| Wheelbase | 7230+1310+1310mm |
| Tank Dimensions (Diameter x length) | 2,500 x 13,070mm |
| Material of Tank | Q345 |
| Thickness of Tank | 12mm |
| Material of Main Frame | 16Mn |
| Manhole | 1pc DN450 on top of the tank |
| Safety Valve | 2pcs DN80 on top of the tank |
| Designed Temperature | 50°C |
| Designed Pressure | 1.61Mpa |
| Corrosion Allowance | 1.00 |
| Weld Joint Factor | 1 |
| Painting | Sandblasting, two layers of anti-corrosion painting, color & logo customized |
| Weight | |
| G.V.W. | 42,250kg |
| Curb Weight | 16,250kg |
| Capacity | 26,000kg |
| Testing | |
| Heat Treatment | Overall treatment in a furnace, 600°C to 640°C |
| Flaw Detection | 100% flat detection |
| Test Pressure | 1.61Mpa |
| Hydraulic Test | 2.1Mpa |
| Magnaflux Inspection | Aim at the welding line where flaw detection can’t reach |
| Gauges | |
| Emergency Cut-off Valves | 2pcs,1pc for liquid phase and 1pc for vapor phase |
| Ball Valves | 4pcs for loading and discharging at two sides of the tank |
| Liquid Gauge | 1pc |
| Pressure Indicating Thermometer | 1pc |
| Pressure Gauge | 1pc |
| Running System | |
| Axles | 3 pcs 12-ton axles, brands optional |
| Tires | 12R 22.5 Tubeless tires, 12 pcs +1 spare tire |
| Rims | Steel rims are standard, and aluminum alloy rims are optional |
| Supporting Legs | 2pcs JOST brand two-speed, manual operating, heavy-duty supporting legs |
| Suspension | Mechanical suspension, air suspension optional |
| Braking System | Pneumatic braking system |
| King Pin | #50 or #90 |
| Accessories | |
| Toolbox | 2pcs |
| Wheel Carrier | 1pc |
| Fire Extinguisher | 2pcs |
| Fender | 2pcs |
