Model No.: | CSCMTT009 |
Milk Tank Volume: | 9,000 Liters |
Overall Dimensions(LxWxH): | 6,900×2,350×2,800mm |
Chassis brand: | Dongfeng |
Drive Type: | 4×2 |
Wheelbase: | 3,800mm |
Engine Power: | 121kW |
Milk Tank Material: | SUS304-2B food grade |
Categories: Milk Tank Truck, Stainless Steel Tank Truck
Description
BRIEF
The 6-wheeler, 9 CBM (9000 liters) milk tank truck produced by CSCTRUCK China Tank Truck is a robust and reliable solution for the safe transport of liquid dairy products. Built on a Dongfeng chassis, the truck features a 4×2 drive type, offering strong road performance and maneuverability. Its engine provides 121kW of power, ensuring efficient transport even with full loads.
The milk truck is equipped with a food-grade SUS304-2B stainless steel milk tank, which guarantees hygiene and corrosion resistance, crucial for preserving milk quality during transport. The 9 CBM capacity makes it ideal for medium-scale dairy transport needs. With a well-engineered design for both urban and rural deliveries, this milk truck combines durability, efficiency, and safety to meet the demands of dairy logistics, contributing to smooth and hygienic transportation of perishable liquids.
FEATURES
1. Milk Tank Capacity: The milk truck is equipped with a 9 CBM (9,000 liters) food-grade stainless steel tank (SUS304-2B), designed to safely transport milk while maintaining hygiene standards.
2. Chassis: It uses a Dongfeng chassis, which provides durability, reliability, and efficient performance for heavy-duty transport applications.
3. Drive Type: The truck features a 4×2 drive configuration, meaning it has 2 powered wheels, which is common in many medium-duty commercial vehicles.
4. Engine Power: The truck is powered by an engine with 121 kW (about 162 horsepower), offering sufficient power for long-distance milk transportation, even on challenging terrain.
5. Stainless Steel Construction: The tank is made of SUS304-2B stainless steel, which is corrosion-resistant and food-safe, ensuring the milk stays fresh and uncontaminated during transport.
SPECIFICATION
Milk Vehicle Technical Parameters | |
Curb Weight(Kg) | 5,200 |
Boundary Dimension(mm)(LxWxH) |
6,900*2,350*2,800 |
Tank size(mm)(LxWxH) | 4,750×2,100×1,400 |
Tank Volume(m³) | 8.5 |
Tank Body Material | SUS304-2B food grade |
Operating Ambient Temperature(°C) | -20~45 |
Milk outlet diameter(mm) | 51 |
Inner tank thickness(mm) | δ3.0 |
Outer thickness(mm) | δ1.0 |
Heat insulating materials | 70 mm polyurethane spraying +10mm rubber and plastic insulation cotton |
Heat retention performance | The use of polyurethane spray foam, the heat preservation performance for 24 hours does not exceed 2 °C |
Cleaning method | CIP automatic cleaning, each warehouse is equipped with cleaning balls, to meet the requirements of 360° cleaning |
Split positions | 1 |
Chassis Technical Parameters | |
Trade Name | Dongfeng |
Brake | Automatically Air-Cut Brake |
Type of fuel | Diesel Oil |
Engine Power(kW) | 121 |
Front Axle/Rear Axle(t) | 5/8 |
Gearbox | 6 Speed Manual Transmission |
Number of Axes | 2 |
Wheelbase(mm) |
3,800 |
Number of Tires | 6 |
Tyre Specification |
245/70R19.5 |
