Model No.:	CSCSMT006
Fuel Tank Volume:	6CBM
Overall Dimensions(LxWxH):	5,990×2,050×2,500mm
Chassis Brand:	FAW
Drive Type:	4X2
Wheelbase:	3,300mm
Max. driving speed(km/h):	90
Engine Power:	110HP
Emission Standard:	EURO 2
Tank material:	Carbon steel

Truck Enquiry

Categories: Carbon Steel Tank Truck, Fuel Tank Truck

Description

BRIEF

The 6-wheel 6CBM small fuel truck produced by CSCTRUCK China Tank Truck is a versatile and efficient fuel transportation solution designed for urban and short-distance logistics. Built on a durable FAW chassis with a 4×2 drive configuration, this fuel truck offers reliable performance and ease of maneuverability, making it ideal for narrow city streets or regional delivery routes.

The fuel tank, with a capacity of 6 cubic meters (6CBM), is constructed from high-quality carbon steel, ensuring durability and resistance to wear, corrosion, and leakage. This makes it well-suited for safely transporting various types of fuel.

Powered by a 110HP engine, the truck delivers sufficient power for efficient operation, even when fully loaded. Its engine complies with the EURO 2 emission standard, balancing performance with environmental considerations, although it represents a relatively basic level of emissions compliance compared to modern standards. With a maximum speed of 90 km/h, it provides a balanced combination of speed and fuel efficiency for fuel distribution tasks.

Designed to meet the demands of fuel delivery businesses, this small fuel truck is a reliable and economical choice for small-scale fuel transportation needs. Its compact size, robust construction, and efficient engine make it an attractive option for operators looking to optimize logistics within urban or semi-urban areas.

FEATURES

Tank Capacity and Material: Equipped with a 6 cubic meter (CBM) fuel tank made of durable carbon steel, ensuring strength and resistance to corrosion.
Chassis and Drive Type: Built on a reliable FAW chassis with a 4×2 drive type, providing solid support and efficient performance.
Engine Performance: Powered by a 110HP engine compliant with EURO 2 emission standards, offering environmentally conscious operations and moderate power output.
Speed Capability: Designed with a maximum driving speed of 90 km/h, making it suitable for urban and short-haul fuel transport.
Durability and Design: Features a robust 6-wheeler configuration that ensures stability and a compact design optimized for maneuverability.

SPECIFICATION

General Technical Parameters
Overall Dimensions(LxWxH)			5,990×2,050×2,500(mm)
Gross Vehicle Weight			7,360(Kg)
Curb Weight			3,760(Kg)
Chassis Specification
Chassis Brand		FAW
Drive model		4X2
Cabin		Single, LHD, with air conditioner
Number of Passengers		2
Engine	Model	4-stroke direct injection, 4-cylinder in-line, intercooled supercharging, with ABS.
	Power	81kW/110HP
	Emission standard	EURO 2
	Fuel type	Diesel
Gearbox		5 Forwards & 1 Reverse, manual operation. With power steering.
Brake System		Oil break
Wheel Base		3,300mm
Front/Rear Axle Loading		2,000/5,000(Kg)
Tire		7.00-16, 6pcs with 1 spare tire
Max Driving Speed		90(km/h)

Upper Structure Specification
Oil Tank	Effective Volume	6CBM
	Transport Oil Type	Diesel
	Tank dimensions(LxWxH)	4,000×1,700×1,100mm
	Tank Thickness	4mm
	Tank Material	Q235, carbon steel( also can choose stainless steel, aluminum )
Refueling System	1. Oil pump; 2. Oil dispenser machine; 3. Hose reel with filling gun.
Equipment	1. Manhole 1 Unit 2. Ladder handrail 3. Electrostatic Wire Reel 4. Loading, Discharge 5. Emergency cut-off valve 1 Unit
Options	Compartments, unloading valve, flow meter, API standard manhole, oil vapor recovery, anti-overflow probe.
