Model No.:	CSCFDT021
Fuel Tank Volume:	21 CBM
Overall Dimensions(LxWxH):	8,321×2,480×2,900mm
Chassis Brand:	Dongfeng
Drive Type:	4×2
Wheelbase:	4,700mm
Max. driving speed(km/h):	80
Engine Model:	ISDe210 30
Engine Power:	210HP
Emission standard:	Euro III
Tank Material:	Q235/Q345/610L/Q700 carbon steel

Truck Enquiry

Categories: Carbon Steel Tank Truck, Fuel Tank Truck

Description

BRIEF

CSCTRUCK China Tank Truck manufactures high-performance 6-wheeler fuel delivery trucks designed for efficient fuel transport. These trucks feature a robust 21 CBM fuel tank capacity, catering to bulk fuel distribution needs. Built on a Dongfeng chassis, the trucks have a 4×2 drive configuration, ensuring excellent maneuverability and reliable performance, even in challenging environments.

The tank trucks are powered by the ISDe210 30 engine, delivering a robust 210 HP output. This engine adheres to the Euro III emission standards, striking a balance between power and environmental compliance. With a maximum driving speed of 80 km/h, the trucks are optimized for safe and timely fuel delivery over moderate distances.

The tanks are constructed from high-quality materials such as Q235, Q345, 610L, or Q700 carbon steel, ensuring durability and resistance to wear and tear, even under demanding conditions. The carbon steel material also provides excellent protection against corrosion, safeguarding fuel quality and maintaining operational efficiency.

These fuel delivery trucks are designed with practicality and efficiency in mind, making them ideal for commercial fuel transport operations. With their high-capacity tanks, reliable chassis, and powerful engines, they offer an optimal solution for bulk fuel transportation, meeting industry demands while maintaining safety and regulatory standards. CSCTRUCK China Tank Truck‘s dedication to quality and performance ensures these vehicles are a dependable choice for fuel logistics.

FEATURES

Large Fuel Tank Volume: The truck has a tank capacity of 21 cubic meters (CBM), making it suitable for bulk fuel transportation.
Dongfeng Chassis & Robust Build: Built on a Dongfeng chassis with a 4×2 drive type, it offers reliable performance and versatility for various terrain conditions.
Powerful Engine: Equipped with the ISDe210 30 engine, this truck delivers 210 horsepower and complies with Euro III emission standards for improved efficiency and environmental compliance.
Durable Tank Material: The fuel tank is made of Q235, Q345, 610L, or Q700 carbon steel, ensuring durability and safety during transportation.
Efficient Speed and Performance: The truck boasts a maximum driving speed of 80 km/h, offering an optimal balance of speed and control for long-distance fuel delivery.

SPECIFICATION

Cabin	Dongfeng
Drive Model	4×2
Vehicle Main Dimensions	(LxWxH)mm			8,3212,4802,900
	Wheelbase(mm)			4,700
	Wheel track(front/rear)(mm)			1,400/2,500
Weight in KGS	Curb Weight			7,805
	G.V.W.			16,000
Max. driving speed(km/h)				80
Engine	Brand			DONGFENG
	Model			ISDe210 30
	Type		4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging and inter-cooling.
	Horse Power(HP)			210
	Max. Output Power			155kW
	Displacement			6.7L
	Emission standard			Euro III
Gearbox	7forwards& 1 reverse
Clutch	Reinforced diaphragm clutch, diameter 430mm.
Tire	11R22.5,295/80R22.5 All steel radial tire, 1pc including 1 spare tire.
Brakes	Service brake: Dual circuit compressed air brake Parking brake: (Emergency brake): Spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake.
Steering Gear	Z F 8098, power steering, hydraulic steering with power assistance.
Fuel tank (L)	350
Tank body
Loading media		Fuel and Chemical Liquid Tank Truck
Length		5.2-6.4m
Material		Q235/Q345/610L/Q700 carbon steel, stainless steel, alloy steel.
Thickness		16mm
Volume		21CBM
