Model No.: | CSCMTT013 |
Overall Dimensions(LxWxH): | 8,560×2,500×3,200mm |
Chassis Brand: | FAW |
Drive Type: | 4×2 |
Wheelbase: | 4,700mm |
Curb Weight(Kg): | 7,370 |
Engine Power(kW): | 179 |
Gearbox: | 8 Speed Manual Transmission |
Tank Volume(m³): | 13 |
Milk Tank Body Material: | SUS304-2B food grade |
Categories: Milk Tank Truck, Stainless Steel Tank Truck
Description
BRIEF
The 13000 liters milk truck manufactured by CSCTRUCK China Tank Truck, featuring a robust FAW chassis, exemplifies excellence in dairy transportation. Equipped with a 179kW engine and employing a 4×2 drive configuration ensures optimal performance across varied terrains. The tank, crafted from SUS304-2B food-grade material, guarantees hygiene and durability critical for milk transportation. Its δ3.0mm inner tank and δ1.0mm outer tank thickness enhance structural integrity while accommodating the stringent operational conditions of -20~45°C ambient temperatures.
Innovatively designed for efficiency, the milk truck incorporates CIP automatic cleaning systems, complemented by strategically placed cleaning balls in each compartment, facilitating comprehensive 360° cleaning. This feature meets and exceeds hygiene standards, which is essential for maintaining the purity of transported milk. CSCTRUCK China Tank Truck‘s commitment to quality is further underscored by the meticulous engineering of this vehicle, ensuring reliability and safety throughout its operational lifespan.
Ideal for dairy farms and milk distribution networks, this 6-wheeled milk truck from CSCTRUCK China Tank Truck emerges as a pinnacle of modern milk transportation technology, marrying advanced engineering with practical functionality. With its ample 13000-liter capacity and state-of-the-art cleaning mechanisms, it stands poised to elevate efficiency and hygiene standards in the dairy logistics industry, embodying CSCTRUCK China Tank Truck‘s dedication to delivering superior vehicles tailored to the specialized needs of milk transportation.
FEATURES
1. High Capacity Milk Tank: The truck features a 13,000-liter capacity milk tank made of SUS304-2B food-grade stainless steel, ensuring safe transportation of liquid dairy products.
2. FAW Chassis with 4×2 Drive Type: Built on an FAW chassis, the truck has a 4×2 drive type, providing reliable performance and maneuverability for various road conditions.
3. Powerful Engine: The truck is powered by a 179kW engine, delivering the strength needed for transporting heavy loads efficiently.
4. Temperature Control and Insulation: The milk tank can operate in ambient temperatures ranging from -20°C to 45°C, thanks to its well-insulated design with δ3.0mm inner and δ1.0mm outer tank thickness.
5. Advanced Cleaning System: The truck is equipped with a CIP (Clean-In-Place) automatic cleaning system, featuring cleaning balls in each compartment to meet the requirements of 360° cleaning for optimal hygiene standards.
SPECIFICATION
[General Technical Parameters ] |
|
Product Name
|
6 Wheelers 13000 Liters Milk Truck
|
Curb Weight(Kg)
|
7,370
|
Boundary Dimension(mm)
|
8,560×2,500×3,200
|
Tank Size(mm)
|
5,700×2,400×1,600
|
Tank Volume(m³)
|
13
|
Tank Body Material
|
SUS304-2B food grade
|
Operating Ambient Temperature(°C)
|
-20~45
|
Milk Outlet Diameter(mm)
|
51
|
Inner Tank Thickness(mm)
|
δ3.0
|
Outer Tank Thickness(mm)
|
δ1.0
|
Heat Insulating Materials
|
70 mm Polyurethane Spraying
+10mm Rubber and Plastic Insulation Cotton |
Heat Retention Performance
|
The use of polyurethane spray foam, the heat preservation performance for 24 hours does not exceed 2 °C.
|
Cleaning Method
|
CIP automatic cleaning, each warehouse is equipped with cleaning balls, to meet the requirements of 360° cleaning.
|
Compartment
|
As Required
|
[Chassis Technical Parameters] |
|
Chassis Brand
|
FAW
|
Brake
|
Automatically Air-Cut Brake
|
Type of Fuel
|
Diesel Oil
|
Engine Power(kW)
|
179
|
Front Axle/Rear Axle(t)
|
7/12
|
Gearbox
|
8 Speed Manual Transmission
|
Number of Axes
|
2
|
Wheelbase (mm)
|
4,700
|
Number of Tires
|
6
|
Tyre Specification
|
275/80R22.5
|
