Model No.: | 6 Wheelers 12000 Liters Fuel Tank Truck |
Fuel Tank Volume: | 12,000 Liters |
Overall Dimensions(LxWxH): | 7,800×2,500×3,200mm |
Chassis Brand: | FAW |
Wheelbase: | 4,250mm |
Drive Type: | 4×2 |
Engine Brand: | Da Chai |
Engine Power: | 132kW |
Emission Standard: | Euro 3 |
Fuel Tank Material: | 304 Stainless Steel/Q235 Carbon Steel |
Categories: Carbon Steel Tank Truck, Fuel Tank Truck, Stainless Steel Tank Truck
Description
BRIEF
The 6 wheeler 12,000 liters fuel tank truck manufactured by CSCTRUCK China Tank Truck is a robust and reliable vehicle designed to meet the demands of fuel transportation with efficiency and durability. Equipped with an FAW chassis and boasting a 4×2 drive type, this fuel tanker ensures stability and maneuverability on various road conditions, making it ideal for both urban and rural environments.
Under the hood, it features a powerful Da Chai engine brand, delivering 132kW of engine power to propel the truck forward with ease. Despite its impressive performance, it adheres to Euro 3 emission standards, reflecting its commitment to environmental sustainability.
The fuel tank itself is constructed from high-quality materials, offering the choice between 304 stainless steel or Q235 carbon steel, ensuring the safe and secure transportation of liquids. With a capacity of 12,000 liters, it provides ample storage space for fuel while maintaining structural integrity and preventing leakage.
With a maximum speed of 80km/h, this fuel tank truck ensures timely delivery of fuel while adhering to road safety regulations. Whether for commercial or industrial use, the 6 wheeler fuel tank truck combines efficiency, reliability, and performance, making it a preferred choice for businesses and operators in the fuel transportation industry.
FEATURES
1. Capacity: The tank truck boasts a generous 12,000-liter fuel capacity, ensuring efficient transportation of fuel or other liquids.
2. Chassis: Built on a sturdy FAW chassis, renowned for its reliability and durability in various road conditions.
3. Drive Type: With a 4×2 drive configuration, it offers excellent maneuverability and control, making it suitable for navigating diverse terrains and tight spaces.
4. Engine Brand and Power: Equipped with a robust Da Chai engine, delivering 132kW of power, ensuring optimal performance even when fully loaded.
5. Emission Standard: Compliant with Euro 3 emission standards, reflecting its commitment to environmental sustainability by reducing harmful exhaust emissions.
6. Tank Material: The fuel tank is constructed using high-quality materials, offering the choice between 304 stainless steel for enhanced corrosion resistance or Q235 carbon steel for durability, ensuring safe and secure transportation of fuel.
7. Maximum Speed: Capable of reaching speeds of up to 80km/h, enabling swift and efficient transportation of fuel to its destination while adhering to safety regulations and road limits.
SPECIFICATION
Vehicle Technical Parameters |
|
Curb Weight(Kg) | 7,000 |
Boundary Dimension(mm) | 7,800×2,500×3,200 |
Tank Volume(m³) | 12 |
Tank Thickness(mm) | 5 |
Tank Body Material | 304 Stainless Steel/Q235 Carbon Steel |
Anti wave plate | yes |
Operating Ambient Temperature(°C) | -20~45 |
Mouth of tank | European standard |
Emergency shutoff valve | yes |
Oil gas recovery unit | yes |
Anti-overflow alarm device | yes |
Fuel loading method | Bottom filling |
Gear oil pump flow(m³/h) | 60 |
Toolbox | Customized to your needs |
Maximum Speed(km/h) | 80 |
Chassis Technical Parameters |
|
Trade Name | FAW |
Type of fuel | Diesel Oil |
Engine Power(KW) | Da Chai 132kW |
Front-wheel braking | Disc brake |
Front Axle/Rear Axle(t) | 3.6/8 |
Gearbox | 6 Speed Manual Transmission |
Brake | Air brake |
Front-wheel braking | Disc brake |
Number of Axles | 4 |
Wheelbase (mm) | 4,250 |
Number of Tires | 6 |
Tyre Specification | 9.00R20 |
