Model No.:	6 Wheelers 10 CBM Milk Tank Truck
Milk Tank Volume:	10 CBM
Overall Dimensions(LxWxH):	6,900×2,200×2,800mm
Drive Type:	4×2
Chassis Brand:	Dongfeng
Payload:	5,200kg
Engine Model:	YUCHAI
Wheelbase:	3,300mm
Engine Power:	135HP
Emission Standard:	EURO 5
Milk Tank Material:	304/2B food grade stainless steel with 4mm thickness

Truck Enquiry

Categories: Milk Tank Truck, Stainless Steel Tank Truck

Description

BRIEF

The 6-wheeler 10 CBM milk tank truck, produced by CSCTRUCK China Tank Truck, is a robust and efficient vehicle designed specifically for the transportation of milk and other liquid food products. This truck is built on the reliable Dongfeng chassis, known for its durability and performance in various driving conditions. It features a 4×2 drive type, providing a balance of maneuverability and stability, essential for safe and efficient transport.

The truck is equipped with a YUCHAI engine, delivering a substantial 135 horsepower, which ensures adequate power for carrying heavy loads while maintaining fuel efficiency. Adhering to the EURO 5 emission standard, this engine reduces environmental impact by minimizing harmful emissions, aligning with modern sustainability practices.

One of the standout features of this milk tank truck is its 5,200kg payload capacity, making it capable of handling significant volumes of milk. The 10 cubic meters (CBM) food-grade stainless steel milk tanker is designed to meet the highest hygiene standards, ensuring that the milk remains uncontaminated during transit. The 04/2B food-grade stainless steel construction not only ensures durability but also maintains the quality and safety of the transported milk.

Overall, the 6-wheeler milk tank truck offers a reliable, efficient, and environmentally friendly solution for dairy transportation. Its combination of a strong chassis, powerful and eco-friendly engine, and high-quality tanker construction makes it an ideal choice for businesses in the dairy industry looking to transport milk safely and efficiently.

FEATURES

1. Chassis and Drive Type: The truck is built on a Dongfeng chassis, known for its durability and reliability, and features a 4×2 drive type, making it suitable for various road conditions and ensuring stability and control.

2. Engine Specifications: Equipped with a YUCHAI engine that delivers 135 horsepower, this truck provides ample power for the efficient transportation of milk. The engine complies with the EURO 5 emission standard, ensuring reduced environmental impact and adherence to modern emission regulations.

3. Payload Capacity: The truck has a substantial payload capacity of 5,200 kg, making it capable of transporting large quantities of milk in a single trip, optimizing logistics and reducing transportation costs.

4. Milk Tanker Construction: The milk tanker is made from 304/2B food-grade stainless steel, ensuring that the milk remains uncontaminated and safe for consumption. This high-quality material is resistant to corrosion and easy to clean, maintaining hygiene standards.

5. Tank Volume: With a tank volume of 10 cubic meters (10 CBM), the truck is designed to carry a significant volume of milk, catering to the needs of large dairy farms and processing facilities, enhancing efficiency in the dairy supply chain.

SPECIFICATION

Product Name	6 Wheelers 10 CBM Milk Tank Truck
Tank volume	10 CBM
Overall dimension(LxWxH)(mm)	6,900×2,200×2,800
Gross weight(Kg)	11,995
Payload(Kg)	5,200
Curb weight(Kg)	6,600
Axle No.	2
Cab seats(person)	2,3
Approach/departure angle(°)	19/15
Axle load (Kg)	2,920/4,380
Front/rear hang(mm)	1,032/1,663
Front/Rear track(mm)	1,506/1,466
Engine Parameters
Engine model	Engine manufacturer
CY4102-CE4F	Dongfeng YUCHAI engine power co., LTD
Chassis Description	1. Dongfeng 4×2 chassis, single row and A/C, left/right hand drive optional.
	2. 3,300mm wheelbase,135HP engine, 6-speed gearbox, front bridge 2.7T/rear bridge 5.5T, 7.50R16.
	3. Air brake.
Standard Equipment	1. Tank volume: 10CBM. Tank material has 3 layers. The inner tank is made of 304/2B food grade stainless steel with 4mm thickness, the outer layer is 2mm stainless steel skin, and the middle layer is 8cm foaming thermal insulating material.
	2. Equipped with a tank, self-motion cleaning system(such as cleaning pole, cleaning pipe, and Rotary cleaning nozzle )in every warehouse, manhole, breather valve, pipeline, switch points storehouse, pipe joint,self-flowing valve, water box, operation control system, etc.
	3. The heat preservation effect can keep <1 ºC in 24 hours.
	4. The interior of the milk tank is very smooth and highly polished, so it does have not any sharp angles.
Optional Equipment	We can make the milk tank truck according to the customer’s requests with the optional equipment below:
	1. Pump in and pump out
	2. Tank can be independent or separate for many mediums at the same time
	3. Flow meter
	4. Liquid level meter
	5. Safety lock device
	6. Spill prevention device
	Please advise us in advance if you have any special requests for the milk tank truck, we can equip various kinds of optional equipment for you.
Purposes	A milk tank truck is also called a milk transport truck, milk transport trailer, milk tanker trailer, milk tanker, milk truck tank, liquid food truck, selling food truck, etc. It is mainly used for loading and transporting liquid food, milk, water, etc.
Product advantage	1. Safe and economical, there are a variety of configurations and choices to meet market demands.
	2. Best Quality at a competitive price.
