Model No.: | 6 Wheelers 10 CBM Chemical Tank Truck |
Chemical Tanker Volume: | 10 CBM |
Overall Dimensions(LxWxH): | 8,415×2,500×3,200(mm) |
Chassis Brand: | Dongfeng |
Drive Type: | 4×2 |
Wheelbase: | 5,800mm |
Engine Model: | B6.2NS6B210 |
Engine Power: | 154kW |
Emission Standard: | EURO 2 |
Max Driving Speed: | 80km/h |
Chemical Tanker Material: | Carbon Steel |
Categories: Carbon Steel Tank Truck, Chemical Tank Truck
Description
BRIEF
The 6-wheel, 10 cubic meters (CBM) chemical tank truck produced by CSCTRUCK China Tank Truck represents a robust solution for transporting chemicals. Built on the reliable Dongfeng chassis, this vehicle features a 4×2 drive type, providing a stable and efficient drive system suitable for various road conditions.
At its heart is the B6.2NS6B210 engine model, delivering a substantial 154kW of engine power. This power ensures the truck can handle demanding transport tasks while maintaining efficiency and reliability. The engine adheres to the EURO 2 emission standard, making it a more environmentally friendly option compared to older models, though it may not meet the latest emission standards in some regions.
The chemical tanker itself is crafted from carbon steel, known for its durability and resistance to corrosion, ensuring the safe and secure transport of chemical substances. With a maximum driving speed of 80km/h, this chemical tank truck balances speed and safety, making it suitable for medium-distance transportation needs.
The 10 CBM capacity of the tanker allows for the transport of substantial quantities of chemicals, making it ideal for industries requiring regular and voluminous chemical shipments. This capacity, combined with the truck’s robust construction and reliable performance, positions it as a valuable asset in the logistics and transportation sector.
Overall, the 6-wheeler chemical tank truck, with its Dongfeng chassis and powerful engine, offers a reliable and efficient solution for the transportation of chemicals, balancing capacity, power, and safety.
FEATURES
1. Chassis and Drive Type: The truck is built on a Dongfeng chassis and features a 4×2 drive type, providing a robust and reliable base for the chemical tanker.
2. Engine Specifications: It is equipped with a B6.2NS6B210 engine model, which delivers an engine power of 154kW, ensuring sufficient power for transporting chemical goods.
3. Tank Capacity and Material: The truck has a 10 CBM(cubic meter) capacity chemical tanker made from carbon steel, which is suitable for transporting various chemicals safely.
4. Emission Standard and Speed: The vehicle complies with the EURO 2 emission standard, making it relatively environmentally friendly. It has a maximum driving speed of 80 km/h, suitable for efficient and timely delivery.
5. Special Features: The truck is specifically designed for chemical transportation, with features tailored to ensure the safe and secure handling of hazardous materials.
SPECIFICATION
[Vehicle Technical Parameters] |
|||
Product trademark
|
CSCTRUCK China Tank Truck |
Announcement batch
|
370
|
Product name
|
6 Wheelers 10 CBM Chemical Tank Truck
|
||
Total mass(Kg)
|
18,000
|
Tank volume (m3)
|
10
|
Rated mass (kg)
|
10,065
|
Outline dimension (mm)
|
8,415×2,500×3,200(mm)
|
Curb weight (kg)
|
7,805
|
Goods Chamber Size (mm)
|
|
Number of passengers (person)
|
2,3
|
Maximum load mass of the saddle (kg)
|
|
Approach angle/departure angle of (°)
|
16/12
|
Front suspension / rear suspension (mm)
|
1,430/2,285,1,400/2,315
|
Axle weight (kg)
|
6,500/11,500
|
Top vehicle speed (km/h)
|
80
|
[Chassis Technical Parameters] |
|||
Chassis model
|
DFH1180EX9
|
Chassis name
|
Truck chassis
|
Brand name
|
Dongfeng
|
Manufacturing enterprise
|
CSCTRUCK China Tank Truck |
Number of axles
|
2
|
Number of tires
|
6
|
Wheelbase (mm)
|
5,800
|
||
Tire size
|
295/80R22.5 18PR
|
||
Number of steel plate spring sheets
|
3/-
|
Front gauge (mm)
|
1,980
|
Fuel types
|
Diesel oil
|
Rear track (mm)
|
1,820
|
Emission basis standard
|
EURO 2 | ||
Engine type
|
Engine production enterprise
|
Engine displacement
|
Engine power
|
B6.2NS6B210
|
Dongfeng Cummins
|
6,200ml
|
154kW
|
