| Model No.: | CSCSMLRT005 |
| Propane Tank Volume: | 5CBM |
| Overall Dimensions(LxWxH): | 5,900×2,045×2,600mm |
| Chassis Brand: | Dongfeng |
| Drive Type: | 4×2 |
| Wheelbase: | 3,300mm |
| Engine Model: | CY4102-C3F |
| Engine Power: | 95 HP |
| Emission Standard: | EURO III |
| Max Driving Speed: | 80 km/h |
| Tank Material: | Q345R high-tension steel |
BRIEF
The 5CBM small mobile LPG refilling truck produced by CSCTRUCK China Tank Truck is a specialized vehicle designed for the safe transport and refilling of liquefied petroleum gas (LPG). This compact yet robust truck is built on the dependable Dongfeng chassis, featuring a 4×2 drive type for optimal maneuverability in various terrains and urban environments.
Powering the vehicle is the CY4102-C3F engine model, which delivers a reliable 95 horsepower. Compliant with the EURO III emission standard, this engine strikes a balance between efficiency and reduced environmental impact. The propane tank truck boasts a top speed of 80 km/h, making it suitable for local and regional LPG distribution.
The key feature of this truck is its 5 cubic meters (CBM) propane tank, constructed from Q345R high-tension steel, known for its durability, strength, and resistance to pressure. This ensures safe storage and transport of the volatile LPG contents. The tank is designed to meet stringent safety standards, making it ideal for mobile refueling operations or small-scale LPG distribution.
Compact yet efficient, the 5CBM LPG refilling truck is tailored to businesses requiring a mobile solution for LPG distribution, especially in areas where larger trucks are impractical. Combining reliability, safety, and eco-friendly operation, this vehicle exemplifies CSCTRUCK China Tank Truck‘s expertise in specialized transport solutions.
FEATURES
- Propane Tank Capacity:
- Equipped with a 5CBM propane tank constructed from Q345R high-tension steel, ensuring durability and safety.
- Chassis and Drive Configuration:
- Built on a Dongfeng chassis with a 4×2 drive type, offering reliable performance for urban and rural LPG distribution.
- Engine Specifications:
- Powered by the CY4102-C3F engine delivering 95 HP and compliant with the EURO III emission standard, ensuring efficiency and reduced environmental impact.
- Performance:
- Designed for mobility with a maximum driving speed of 80 km/h, suitable for quick and efficient refilling operations.
- Application:
- Ideal for mobile LPG refilling services, offering a practical solution for distributing propane in areas without stationary LPG facilities.
SPECIFICATION
| Item No. | Parameters |
| Cabin | Single-row, left-hand drive |
| Overall Dimensions(LxWxH) | 5,900×2,045×2,600mm |
| Gross Vehicle Weight | 6,495kg |
| Curb Weight | 3,050kg |
| Payload | 3,445kg |
| Wheel Base | 3,300mm |
| Engine | Chaochai engine, 4 in-line cylinder |
| Engine horsepower | CY4102-C3F, 95 HP, EURO III |
| Displacement | 3,856ml(Diesel) |
| Max Driving Speed | 80km/h |
| Tire | 7.00-16,7pcs |
LPG tank |
|
| Volume: | 5CBM |
| Tank material: | Q345R |
| Tank diameter: | 1,600mm |
| Tank thickness: | 10mm |
| Tank length: | 3,059mm |
| Filling gas | Propane(LPG) |
| Design Pressure: | 1.61Mpa |
Filling parts |
|
| LPG Pump | 1 |
| Flow meter | 1 |
| Pipeline | 15m |
| Filling gun | Suitable for filling cylinders. You can change gun as per local condition. |
Accessory |
|
| Manhole | 1 |
| Safety Valve | 1 |
| Tool Box | 1 |
| Valve Box | 1 |
| Thermometer | 1 |
| Pressure Gauge | 1 |
| Emergency Valve | 1 |
| Fender | Steel |
| Fire Extinguisher | 2 |
| Anti-static Tape | 1 |
| Paint | As required |
Standard |
|
| Pressure vessels, Supervision Regulation on Safety Technology for Pressure Vessels. | |
| Tank Mounted on Chassis Brand |
|---|
