Model No.: | 5CBM Crude Oil Tank Truck |
Crude Oil Tank Volume: | 5 CBM |
Overall Dimensions(LxWxH): | 5,990*1,950*2,500mm |
Chassis Brand: | DONGFENG |
Drive Type: | 4×2 |
Engine Model: | CY4102-C3F |
Engine Power: | 95HP |
Emission Standard: | Euro 2 |
Crude Oil Tank Material: | Carbon steel |
Categories: Carbon Steel Tank Truck, Crude Oil Tank Truck
Description
BRIEF
The 5CBM crude oil tank truck, produced by CSCTRUCK China Tank Truck, is a robust and reliable vehicle designed for the efficient transportation of crude oil. This truck is built on a durable Dongfeng chassis, a well-known brand in the automotive industry, ensuring high performance and longevity. Featuring a 4×2 drive type, it offers adequate traction and stability for navigating various road conditions.
Under the hood, the crude oil tank truck is equipped with the CY4102-C3F engine model. This engine delivers a power output of 95 horsepower, providing a balanced combination of power and fuel efficiency. Despite its moderate power, the engine meets the Euro 2 emission standards, which reflects a commitment to environmentally conscious operations by reducing harmful emissions.
The truck’s tank is constructed from high-quality carbon steel, known for its strength and resistance to wear and corrosion. The 5CBM (cubic meters) capacity makes it suitable for medium-scale crude oil transportation, offering a practical balance between size and maneuverability. This makes the vehicle ideal for operations in regions where access to larger tanker trucks might be limited due to road infrastructure constraints.
Overall, the 5CBM crude oil tank truck produced by CSCTRUCK China Tank Truck combines reliable Dongfeng engineering with practical design features. Its Euro 2 compliant engine and durable carbon steel tank make it a valuable asset for companies needing efficient and environmentally friendly crude oil transportation solutions.
FEATURES
1. Manufacturer:Â
  – Produced by CSCTRUCK China Tank Truck, a well-known manufacturer in China specializing in various types of tank trucks.
2. Chassis:Â
  – The truck is built on a Dongfeng chassis, which is recognized for its durability and reliability in heavy-duty applications.
3. Drive Type:Â
  – It features a 4×2 drive type, meaning it has a 2-wheel drive with power transmitted to the rear wheels, suitable for typical road conditions and light off-road use.
4. Engine:Â
  – The truck is equipped with a CY4102-C3F engine model, providing robust performance for its class.
5. Engine Power:Â
  – The engine delivers 95 horsepower, ensuring adequate power for transporting crude oil over various distances.
6. Emission Standard:Â
  – Complies with the Euro 2 emission standard, which, while not the latest, provides a balance between performance and environmental considerations.
7. Tank Material:Â
  – The crude oil tank is constructed from carbon steel, known for its strength and resistance to corrosion, making it suitable for transporting oil.
8. Tank Capacity:Â
  – The crude oil tank truck has a tank capacity of 5 cubic meters(CBM), which is ideal for moderate volume transportation of crude oil.
SPECIFICATION
Vehicle Description |
||
Overall dimensions(LxWxH) | 5,990*1,950*2,500mm | |
GVW | 6,495kg | |
Curb weight | 3,420kg | |
Chassis brand | DONGFENG | |
Traction type | 4×2, left/right-hand drive | |
Chassis Description |
||
Chassis model | DONGFENG | |
Cab | FURUIKA, single-row | |
Wheelbase | 3,300mm | |
Tire specification | 7.00R16 | |
Tire quantity | 6+1 units | |
Engine | Engine model | CY4102-C3F |
Emission level | Euro 2 | |
Displacement/output | 3,856ml/70kw | |
Horsepower | 95HP | |
Gearbox | Model | 5MT |
Number of gears | 5 forward gears& 1 reverse | |
Brake system | Full air brake system | |
Axle | Front | 2T |
Rear | 4T | |
Suspension | Front | Leaf spring |
Rear | Leaf spring | |
Fuel tanker | Type | Steel fuel tank, with lockable cap |
Capacity | 100L | |
Up-part description |
||
Garbage bucket | Capacity | 5CBM |
Material | Carbon steel | |
Thickness | 4mm | |
Standard configuration | Equipped with 1 set manhole. Equipped with a double discharge valve and valve box. Equipped with surge baffles, ladder, roof coaming, skid-resistant walkway, and toolbox. Equipped with refueling dispenser, flow meter, and printer. Equipped with electrostatic conducting tape and double fire extinguishers. |
