53 CBM LNG Transport Tanker Semi-Trailer

BRIEF

The 53 CBM LNG transport tanker semi-trailer produced by CSCTRUCK China Tank Truck is a high-performance cryogenic transport solution engineered for the safe and efficient delivery of liquefied natural gas (LNG). Designed to meet the demanding requirements of long-distance and large-volume LNG distribution, this semi-trailer combines advanced materials, robust construction, and optimized thermal insulation technology.

Constructed with high-quality 06Cr19Ni10 (S30408) stainless steel, the tank ensures excellent resistance to corrosion and extreme low-temperature conditions. With a total tank volume of 52.6 m³ and an additional 7.9 m³ mezzanine space, the trailer offers a substantial LNG carrying capacity, supporting a maximum allowable filling mass of 24,600 kg. The design accommodates LNG at cryogenic temperatures as low as -162°C, with a set temperature range extending from -196°C to 50°C, ensuring safe storage and transport under varying environmental conditions.

The 53 CBM LNG transport tanker semi-trailer has a total mass of 40,000 kg and a curb weight of 15,400 kg, providing a balanced structure for stability and payload efficiency. Its overall dimensions (13,000 × 2,500 × 3,920 mm) and optimized wheelbase configuration (7,166 + 1,310 + 1,310 mm) enhance maneuverability and load distribution during operation.

Engineered with a design pressure of 0.65 MPa (inner tank) and 0.2 MPa (outer tank), the tanker ensures structural integrity under working conditions. It has undergone rigorous testing, including a pressure test at 0.87 MPa and an air-tightness test at 0.65 MPa, guaranteeing safety and reliability.

Suitable for ambient temperatures ranging from -20°C to 50°C, this 53 CBM LNG transport tanker semi-trailer is ideal for diverse operational environments. It is widely used in energy transportation sectors, supporting clean fuel logistics with efficiency, safety, and durability.

FEATURES

1. High-Capacity LNG Transport
   With a total tank volume of 52.6 m³ plus an additional 7.9 m³ mezzanine space, the semi-trailer offers a large payload capacity, supporting up to 24,600 kg of LNG. This makes it ideal for long-distance, large-volume energy transportation.
2. Advanced Cryogenic Performance
   Designed to handle extreme temperatures, the tanker safely stores and transports LNG at cryogenic conditions as low as -162°C, with an operational temperature range from -196°C to 50°C, ensuring reliability in diverse climates.
3. Premium Stainless Steel Construction
   Built with 06Cr19Ni10 (S30408) stainless steel, the tank provides excellent resistance to corrosion and low-temperature brittleness, enhancing durability and extending service life.
4. Robust Safety and Pressure Design
   Featuring a design pressure of 0.65 MPa for the inner tank and 0.2 MPa for the outer tank, the trailer has passed stringent pressure (0.87 MPa) and air-tightness (0.65 MPa) tests, ensuring high safety standards during operation.
5. Optimized Structure and Stability
   With a total mass of 40,000 kg, a curb weight of 15,400 kg, and a well-engineered wheelbase configuration, the tanker delivers excellent load distribution, driving stability, and maneuverability for efficient transport operations.

SPECIFICATION
