| Model No.: | CSCWTST050 |
| Tank Capacity: | 50,000L |
| Overall Dimensions(LxWxH): | 10,500×2,550×3,800mm |
| Axle: | 3 Units of FUWA/BPW 13Ton axle |
| Suspension: | Mechanical suspension |
| Kingpin: | 1 unit of 3.5“(90/50mm) SAE standard |
| Landing gear: | 28Ton located Brand manual operation |
| Tank body: | High Tensile Steel. |
BRIEF
The 50 CBM water tank semi-trailer manufactured by CSCTRUCK China Tank Truck is a high-capacity transport solution designed for bulk water transportation. With a 50,000-liter (50 CBM) tank capacity, this trailer is built to efficiently handle large volumes of water for industrial, agricultural, and emergency applications.
The trailer is equipped with 3 units of 13-ton FUWA or BPW axles, ensuring robust load-bearing capability and reliable road performance. Its mechanical suspension system, complemented by 4-piece, 6-set thickened leaf springs, provides enhanced durability and stability, even on rough terrains.
At the front, the trailer features a 3.5-inch (90/50mm) SAE standard kingpin, ensuring secure and standardized coupling with the tractor unit. It also includes a 28-ton capacity manually operated landing gear from a well-known brand, allowing stable support when the trailer is detached.
The tank body is constructed from high-tensile steel, providing exceptional strength and corrosion resistance, ensuring long service life even in demanding environments. This design makes it ideal for transporting potable water, irrigation water, or other non-hazardous liquids over long distances.
With its heavy-duty components and durable construction, the 50 CBM water tank semi-trailer is a reliable and efficient solution for water transport operations. It offers high capacity, stability, and long-term durability.
FEATURES
- Large Tank Capacity – The 50,000-liter (50 CBM) high-tensile steel tank body is designed for efficient water transportation and storage.
- Heavy-Duty Axles – Equipped with three FUWA/BPW 13-ton axles, ensuring durability and load-bearing capacity for long-haul operations.
- Robust Suspension System – Features a mechanical suspension with 4-piece 6 sets thickened leaf springs, providing stability and shock absorption on rough terrains.
- Strong Coupling Mechanism – Utilizes 1 unit of 3.5-inch (90/50mm) SAE standard kingpin, ensuring a secure connection with the truck tractor.
- Reliable Landing Gear – Fitted with a 28-ton manually operated landing gear from a reputable brand, offering strong support when the trailer is detached.
SPECIFICATION
The Technical Specifications of the 50 CBM Water Tank Semi Trailer |
|
| Model | CSCWTST050 |
| G.V.W | 40,000kg |
| Overall Length | 10,500mm |
| Overall Width | 2,550mm |
| Overall Height | 3,800mm |
| Tank Volume | 50 CBM |
| Tank Material And Deploy |
High Tensile Steel, Standard Manhole, Loading Valve, Pneumatic Bottom Valve and Connect Oil Pipeline. |
Standard Specification |
|
| Main Frame | Heavy duty and extra durability designed, opting for high tensile steel |
| Axle | 3 Units of Self-brand 13Ton axle, Optional FUWA/BPW(brand) |
| Suspension | A couple of mechanical 3-axle suspension |
| Leaf Spring | 6 sets of reliable local brand, 4-piece thick leaf spring |
| King Pin | 1 unit of 3.5“(90/50mm) SAE standard bolted-in kingpin |
| Landing Gear | 28Ton located Brand manual operation, heavy duty landing gear |
| Tire &Â Rim | 12 units of 12.00R22.5 |
| Spare Wheel Carrier | 1 set of spare wheel carrier |
| Safety System | Double axle ABS, braking system, and air tank Manual Ladder on the tank top Standard LED light. |
| Accessory | 1 toolbox with a set standard trailer tool, 2 FIREX holders and FIREX. |
| Tank Mounted on Chassis Brand |
|---|
