Model No.: | 4×4 12000 Liters Crude Oil Tank Truck |
Crude oil tank volume: | 12,000 Liters |
Overall dimensions(LxWxH): | 8,500×2,460×3,150mm |
Chassis Brand: | HOWO |
Drive Type: | 4×4 |
Wheelbase: | 4,500mm |
Engine Brand: | Cummins |
Engine Power: | 300HP |
Emission Standard: | Euro 2 |
Crude Oil Tank Material: | Carbon steel Q235B |
Categories: Carbon Steel Tank Truck, Crude Oil Tank Truck
Description
BRIEF
The 4×4 12,000 liters crude oil tank truck produced by CSCTRUCK China Tank Truck is a robust and efficient vehicle designed for the safe and effective transportation of crude oil. Built on a durable HOWO chassis, this truck is powered by a reliable Cummins engine, delivering 300 horsepower. The engine adheres to the Euro 2 emission standard, ensuring it meets specific environmental regulations despite being an older standard.
The truck features a sizable 12,000-liter tank made from carbon steel Q235B, a material known for its strength and durability, making it well-suited for transporting heavy loads of crude oil. The 4×4 configuration of the truck provides excellent traction and stability, allowing it to easily navigate various terrains, which is crucial for operations in diverse environments.
With a maximum driving speed of 90 km/h, the crude oil tank truck produced by CSCTRUCK China Tank Truck balances speed and safety, ensuring timely deliveries without compromising on safety standards. The integration of the HOWO chassis and Cummins engine underscores the truck’s capability and reliability, essential traits for industrial and commercial applications.
Overall, this crude oil tank truck produced by CSCTRUCK China Tank Truck represents a combination of advanced engineering and practical design, making it a valuable asset for companies involved in the transportation of crude oil. Its significant tank capacity, robust construction, and dependable engine performance highlight its suitability for demanding tasks, ensuring efficient and secure operations in the field.
FEATURES
1. Robust Chassis and Engine:
– Chassis: Built on the reliable HOWO chassis, known for its durability and performance.
– Engine: Powered by a Cummins engine, a renowned brand in the industry, ensuring reliable and efficient performance with 300HP engine power.
2. Large Tank Capacity:
– The truck features a 12,000-liter carbon steel Q235B crude oil tank, providing ample capacity for transporting large volumes of crude oil.
3. Emission Standard Compliance:
– Complies with Euro 2 emission standards, balancing performance with environmental considerations.
4. Off-Road Capability:
– The 4×4 drive configuration enhances the truck’s off-road capabilities, making it suitable for various terrains and challenging conditions.
5. Speed and Efficiency:
– Capable of reaching a maximum driving speed of 90 km/h, ensuring timely delivery of crude oil even over longer distances.
SPECIFICATION
Basic parameters of the vehicle | Model | 4×4 12000 Liters Crude Oil Tank Truck |
Tank Capacity | 12000L | |
Drive Type | 4×4, LHD | |
Cab | Kingrun one and a half-row cab | |
Seats | 3 | |
Overall Length | 8,500mm | |
Overall width | 2,460mm | |
Overall height | 3,150mm | |
G.V.W | 16,000kg | |
Curb weight | 7,500kg | |
Wheelbase | 4,500mm | |
Top Speed | 90km/h | |
Engine | Type | 300HP |
Emission level | Euro2 or Euro 3 or Euro 5 or Euro 6 | |
Maximum power | 240kW | |
Number of cylinders | 6 | |
Displacement (lit) | 6.7 | |
System | Cummins, diesel, in-line four-cylinder, naturally aspirated | |
Transmission | Number of gears | 6-Gear Gearbox |
Tire | Number | 6+1 |
Size | 9.00R20 Steel wire tire | |
axle | Front | 4.5T |
Rear | 9T | |
Battery | Voltage (V) | 24V |
Battery capacity (A.h) | 90Ah | |
Fuel tank | Type | All steel |
Capacity | 126L |
Standard Equipment |
|
Volume of Tank | 12,000L |
Material of tank and thickness | High-quality carbon steel Q235B |
Other | Tank body 4.5mm, head 5mm, single tank with pump, Pump in and Pump out, European standard tank port, with subsea valve. |
Manhole | Aluminum alloy Europe standard Manhole. |
Oil pump | Model: 60YHCB-30, The flow is 28m³/h, working height is 6m. |
Breath valve | 1 |
Subsea valve | 3-inch Aluminum alloy emergency shut-off valve with automatic closing device. |
Unloading Valve | Right of middle parts of the tank. |
The guardrail of the top tank | Manual guardrail. |
Horsebox | PVC soft pipe box with both sides. |
Unloading Pipe | L=3500, 2.5 inches steel wire pipe. |
Ladder | Rear ladder |
Kitbox | 1 or 2 |
Spare tyre | 1 |
Fender | Carbon Steel |
Side guardrail | Carbon Steel |
Rear bumper | Carbon Steel |
Fire extinguisher | 2kg fire extinguisher with 2 |
Anti-static device | One electrostatic conductive drag belt and one electrostatic conductive terminal block |
Optional Equipment |
|
Filling Machine | Optional install Zhengxing big flow refueller with 15 meters reel and gun. |
Flow meter | Optional install |
Lower loading and unloading | Optional install |
Oil and gas recovery | Optional install |
Anti overflow | Optional install |
Liquid Level Gauge | Optional install |
