| Model No.: | CSCWTST045 |
| Tank Capacity: | 45,000L |
| Overall Dimensions(LxWxH): | 11,700×2,500×3,750mm |
| Compartment: | 3 |
| Bottom valve: | 3 sets |
| Manhole: | 500mm manhole cover |
| Discharge valve: | 4″ disc valve |
| Discharge pipe: | 4″ seamless steel tube |
| Axle: | Fuwa brand 13 ton axle, 3 sets |
| Suspension: | Mechanical suspension |
| Leaf spring: | 90mmx13mmx10pcs |
| Landing gear: | 28 ton landing gear |
| Tank Material: | SS304 stainless steel |
BRIEF
The 45,000-liter water tank semi-trailer produced by CSCTRUCK China Tank Truck is a high-capacity, durable transport solution for bulk water hauling. Designed for efficiency and reliability, this semi-trailer is constructed with a stainless steel SS304 tank, ensuring corrosion resistance and long-term durability.
The tank capacity is 45,000 liters, divided into 3 compartments, allowing for controlled distribution and better weight management. Each compartment is equipped with a bottom valve to facilitate easy discharge. The tank features a 500mm manhole cover for maintenance access and a 4-inch disc valve for efficient flow control. Additionally, the 4-inch seamless steel tube ensures a smooth, uninterrupted transfer of water.
For structural support, the water tank semi-trailer is built on three Fuwa brand 13-ton axles with mechanical suspension, providing stability and load-bearing capability. The 90mm x 13mm x 10-piece leaf spring suspension system further enhances shock absorption and weight distribution. The trailer is equipped with a 28-ton landing gear, ensuring robust support when detached from the tractor unit.
This water tank semi-trailer is engineered for heavy-duty applications, making it suitable for industries requiring bulk water transportation, such as agriculture, construction, and municipal water supply. The use of high-quality materials and reliable components ensures efficient operation and a long service life, making it a dependable choice for demanding water transport needs.
FEATURES
- High-Capacity Stainless Steel Tank – The 45,000-liter tank is constructed from SS304 stainless steel, ensuring durability, corrosion resistance, and suitability for transporting water or other liquids.
- Efficient Multi-Compartment Design – The tank is divided into 3 compartments, allowing for better load distribution, stability, and the ability to transport different liquid types simultaneously.
- Robust Suspension & Axles – Equipped with three Fuwa 13-ton axles, mechanical suspension, and 90mm x 13mm x 10pcs leaf springs, ensuring strong load-bearing capacity and reliable performance on various terrains.
- Secure & Reliable Valve System – Features three bottom valves, a 4-inch disc valve, and 4-inch seamless steel tubing, ensuring efficient loading, unloading, and flow control.
- Heavy-Duty Support & Stability – Fitted with a 28-ton landing gear, providing strong support when detached from the tractor, enhancing stability during loading and unloading operations.
SPECIFICATION
| Main parameters | Overall dimensions (LxWxH) | 11,700 x 2,500 x 3,750mm |
| Loading capacity | 45,000 liters | |
| Tank thickness | SS304 stainless steel, Tank body 5mm; End plate 6mm |
|
| Compartment | 3 or as required | |
| Bottom valve | 3 sets | |
| Manhole | 500mm manhole cover, 3Â sets with breath valve | |
| Discharge valve | 4″ disc valve | |
| Discharge pipe | 4′ seamless steel tube | |
| Chassis | Main beam | The height of the main beam is 500mm Upper plate is 14mm Middle plate is 8mm Down plate is 16mm |
| Side beam | 16I side beam | |
| Axle | Fuwa brand 13 ton axle | |
| Axle quantity | 3 pcs | |
| Suspension | Mechanical suspension | |
| Leaf spring | 90mm x 13mm x10pcs | |
| Tire | Triangle brand 12r22.5Â tubeless tyre | |
| Tire quantity | 12 pcs | |
| Landing gear | 28 ton landing gear | |
| Traction pin | 2 inch or 3.5 inch | |
| Accessories | Brake | RE6 reply valve |
| Tool box | 1 unit | |
| Spare wheel carrier | 2 units | |
| Lamp | LED type, 24v voltage, 7ways (7 wire harness) receptacle | |
| Optional | Air suspension W/O lifting | |
| Water tank | ||
| Fire extinguisher | ||
| Discharge Hose + Hose brackets carrier | ||
| Side protection bumper. | ||
| Tank Mounted on Chassis Brand |
|---|
