| Model No.: | CSCLTDT036 |
| LPG tank volume: | 36 CBM |
| Overall Dimensions(LxWxH): | 11,700×2,500×3,690mm |
| Chassis Brand: | HOWO |
| Drive Type: | 8X4 |
| Payload: | 17,000kg(17Ton) |
| Engine Model: | WD615.47 |
| Engine Power: | 371HP |
| Emission Standard: | EURO III |
| Max Driving Speed: | 95 km/h |
| LPG tank material: | Q370R |
BRIEF
The 36 CBM LPG tank delivery truck by CSCTRUCK China Tank Truck is a robust and efficient solution for the transportation of liquefied petroleum gas (LPG). Built on a HOWO 8×4 chassis, this truck is designed for durability and high performance, meeting the demanding requirements of LPG distribution. It boasts a Q370R steel LPG tank with a capacity of 36 cubic meters, ensuring safe and secure containment of the gas.
Equipped with a WD615.47 engine model, the tank truck delivers an impressive 371 horsepower, providing the necessary power for heavy-duty operations. The EURO III emissions standard compliance reflects an eco-friendly design, balancing performance with environmental considerations. Its maximum driving speed of 95 km/h allows for efficient transport over long distances.
The LPG tank delivery truck supports a payload capacity of 17,000 kg(17 tons), making it suitable for large-scale deliveries. The 8×4 drive type ensures enhanced traction and stability, even in challenging terrains, while the sturdy HOWO chassis adds to the overall reliability and longevity of the vehicle.
Ideal for industrial and commercial applications, this CSCTRUCK China Tank Truck model offers a blend of advanced engineering and practicality. With its high-capacity tank, powerful engine, and compliance with international standards, it is a trusted choice for LPG delivery services worldwide.
FEATURES
- Large LPG Tank Capacity: Equipped with a 36 CBM (cubic meters) Q370R LPG tank, offering robust storage and efficient transportation for liquefied petroleum gas.
- Powerful Engine: Powered by the WD615.47 engine model, delivering 371 horsepower (HP) and meeting the EURO III emissions standard, ensuring reliable performance and environmental compliance.
- High Payload Capability: Designed to carry a substantial load with a 17,000 kg (17-ton) payload capacity.
- Sturdy Chassis and Drive System: Built on a HOWO 8×4 chassis, providing enhanced stability and traction, ideal for heavy-duty operations and challenging terrains.
- Efficient Performance: Achieves a maximum driving speed of 95 km/h, balancing speed and safety for optimal operational efficiency.
SPECIFICATION
| Item No. | Parameters |
| Overall Dimensions(LxWxH) | 11,700×2,500×3,690mm |
| Driving Model | Left-hand drive |
| Gross Vehicle Weight | 31,000kg |
| Curb Weight | 15,895kg |
| Payload | 17,000kg(17Ton) |
| Drive Type | 8×4 |
| Front/rear Tread | 2,022/1,830mm |
| Approach/Departure Angle | 16/12Â degree |
| Front Axle | 7,000kg*2 |
| Rear Axle | 16,000kg*2 |
| Engine | WD615.47, 4-stroke direct injection, 6-cylinder in-line with water cooling, turbo-charging, and inner cooling |
| Engine horsepower | 371HP, EURO III |
| Displacement | 9,760ml (Diesel) |
| Max Driving Speed | 95Â km/h |
| Gearbox | HW19710CL |
| Cabin | Standard HW76 cabin, 2~3 Passenger allowed, with Air Conditioner |
| Tire | 12R22.5Â (11Â pieces) |
| LPG tank | |
| Volume: | 35.5 CBM |
| Tank material: | Q370R |
| Tank diameter: | 2,350mm |
| Tank thickness: | 11mm |
| End plate | 8mm |
| Tank length: | 8,960mm |
| Gas phase | DN50 |
| Liquid Phase | DN80 |
| Filling gas | Propane(LPG) |
| Design Pressure: | 1.61Mpa |
| Accessory | |
| Level Gauge | Manual rotation type, at the rear of the tank |
| Safety Valve | 1, DN80 |
| Tool and Valve Box | 1 |
| Thermometer | 1 |
| Pressure Gauge | 1 |
| Emergency Valve | 1 |
| Fender | Steel |
| Fire Extinguisher | 2 |
| Exhaust shaft | At the front of the truck for safety |
| Tank Mounted on Chassis Brand |
|---|
