Model No.: | CSCMTST033 |
Milk Tank Volume: | 33 CBM |
Overall Dimensions(LxWxH): | 10,370×2,500×3,650mm |
Curb Weight(kg): | 7,800 |
Tank Body Material: | SUS304-2B food grade |
Number of Axles: | 3 |
Wheelbase(mm): | 4,750+1,310+1,310 |
Front Axle/Rear Axle(t): | 24 |
Operating Ambient Temperature(°C): | -20~45 |
Categories: Milk Tank Truck, Stainless Steel Tank Truck
Description
BRIEF
The 33 CBM milk tank semi-trailer produced by CSCTRUCK China Tank Truck is a specialized transport vehicle designed for the safe and hygienic transportation of milk. It features a 33 cubic meter (CBM) stainless steel SUS304-2B food-grade tank body, ensuring optimal hygiene and resistance to corrosion. The trailer’s curb weight is 7,800 kg, making it a robust yet efficient option for large-volume liquid transport.
This three-axle semi-trailer is engineered to operate in a wide range of ambient temperatures, from -20°C to 45°C, maintaining the quality of the milk during transit. The durable construction, paired with temperature resilience, makes it ideal for long-distance transportation in varying climates. CSCTRUCK China Tank Truck‘s milk tank trailer is built with precision and attention to detail, ensuring that dairy products remain uncontaminated and fresh, from production sites to processing facilities.
FEATURES
1. Milk Tank Volume: The semi-trailer is equipped with a 33 cubic meter (CBM) milk tank, allowing it to transport a significant amount of milk in a single trip.
2. Curb Weight: It has a curb weight of 7,800 kg, contributing to a balanced load distribution and overall stability.
3. Food-Grade Tank Material: The tank body is made from SUS304-2B stainless steel, which is a high-quality, food-grade material specifically designed to ensure the safe transportation of milk and prevent contamination.
4. Axles Configuration: This semi-trailer is built with 3 axles, providing enhanced load capacity and better maneuverability.
5. Operating Ambient Temperature: The tank is designed to operate efficiently in a wide temperature range of -20 to 45°C, ensuring milk is safely transported in various climate conditions.
SPECIFICATION
[General Technical Parameters ] |
|
Product Name
|
33 CBM Milk Tank Semi Trailer
|
Curb Weight(kg)
|
7,800
|
Boundary Dimension(mm)
|
10,370×2,500×3,650
|
Tank Size(mm)
|
9,960×2,500×2,060
|
Tank Volume(m³)
|
33
|
Tank Body Material
|
SUS304-2B food grade
|
Operating Ambient Temperature(°C)
|
-20~45
|
Milk Outlet Diameter(mm)
|
51
|
Inner Tank Thickness(mm)
|
δ3.0
|
Outer Tank Thickness(mm)
|
δ1.0
|
Heat Insulating Materials
|
70mm Polyurethane Spraying
+10mm Rubber and Plastic Insulation Cotton. |
Heat Retention Performance
|
The use of polyurethane spray foam, the heat preservation performance for 24 hours does not exceed 2 °C.
|
Cleaning Method
|
CIP automatic cleaning, each warehouse is equipped with cleaning balls, to meet the requirements of 360° cleaning.
|
Compartment
|
As Required
|
[Chassis Technical Parameters] |
|
Front Axle/Rear Axle(t)
|
24
|
Number of Axes
|
3
|
Wheelbase(mm)
|
4,750+1,310+1,310
|
Number of Tires
|
12
|
Tyre Specification
|
12R22.5
|
