| Model No.: | 3000 Liters Stainless Steel Industrial Gas Cylinder |
| Tank Volume: | 150L-3,000L optional |
| Applicable Medium: | SiH2CI2 SiHCI3 CIF3 HF WF3 BCI3, etc |
| Operating Temperature: | -40~65℃ |
| Tank Material: | S31603 |
| Maximum operating pressure: | 2.2/-0.103MPa @65℃ |
| Proof pressure: | 3.3MPa |
| Helium leak detection rate: | ≤1X10-9 pa.m³/s |
| Polishing grade: | EP, Ra≤0.07-0.25um |
| Valve type: | Manual and pneumatic right angle diaphragm valve |
| Valve interface type: | 1, DISS636/CGA636（Outlet connection） 2, 3/4-14NGT /W28 14T.P.I (Inter-connection) |
| Adapted valve: | Rotarex Kohda Neriki Ermeto |
Description
BRIEF
CSCTRUCK China Tank Truck manufactures high-quality 3000 liters stainless steel industrial gas cylinders designed for various industrial applications. These cylinders are part of a versatile range with optional tank volumes from 150 to 3,000 liters, allowing for customized solutions based on specific requirements.
The tanks are capable of containing a variety of hazardous and reactive gases, including SiH2Cl2, SiHCl3, CIF3, HF, WF3, and BCl3. They are constructed from S31603 stainless steel, known for their excellent corrosion resistance and durability, making them suitable for use in harsh environments.
The operating temperature range for these 3000 liters stainless steel industrial gas cylinders is -40 to 65℃, ensuring reliability in a wide array of conditions. They are designed to withstand a maximum operating pressure of 2.2/-0.103MPa at 65℃, with a proof pressure of 3.3MPa. The rigorous safety standards are further highlighted by the Helium leak detection rate of ≤1X10^-9 pa.m³/s, ensuring minimal leakage and maintaining gas purity.
The gas cylinders are equipped with manual and pneumatic right-angle diaphragm valves, providing secure and efficient gas flow control. The outlet connection valve interface type is DISS636/CGA636, ensuring compatibility with various industry-standard connections. Additionally, the valves are adapted from renowned brands like Rotarex, Kohda, Neriki, and Ermeto, ensuring high reliability and performance.
Overall, CSCTRUCK China Tank Truck‘s 3000 liters stainless steel industrial gas cylinders are robust, versatile, and safe, meeting stringent industrial standards for gas containment and transport.
FEATURES
1. Capacity and Variants:
– Tank Volume: Available in various capacities ranging from 150 liters to 3000 liters, offering flexibility to meet different industrial needs.
2. Construction and Material:
– Material: Made from S31603 stainless steel, ensuring high durability, corrosion resistance, and longevity under various operating conditions.
3. Tank Medium:
– Suitable for various gases and chemicals including:
– SiH2CI2 (Dichlorosilane)
– SiHCI3 (Trichlorosilane)
– CIF3 (Chlorine Trifluoride)
– HF (Hydrogen Fluoride)
– WF3 (Tungsten Hexafluoride)
– BCI3 (Boron Trichloride)
– This versatility makes the cylinder ideal for use in a wide range of industrial and chemical applications.
4. Operating Temperature:
– Temperature Range: Designed to operate efficiently within a temperature range of -40℃ to 65℃, suitable for diverse environmental conditions.
5. Pressure Specifications:
– Maximum Operating Pressure: The cylinder can handle pressures up to 2.2 MPa at 65℃.
– Proof Pressure: The tank is tested to withstand a proof pressure of 3.3 MPa, ensuring safety and reliability.
– Leak Detection: Equipped with a high-precision Helium leak detection rate of ≤1X10^-9 Pa.m³/s, ensuring the integrity and safety of the tank in handling sensitive and hazardous gases.
6. Valve and Connections:
– Valve Type: Features both manual and pneumatic right-angle diaphragm valves, providing options for different operational preferences and safety requirements.
– Valve Interface: Utilizes DISS636/CGA636 outlet connection types, compatible with industry-standard connections.
– Valve Compatibility: Adapted for use with Rotarex, Kohda, Neriki, and Ermeto valves, offering flexibility and compatibility with a range of existing systems and components.
SPECIFICATION
Technical specification for 3000 Liters Stainless Steel Industrial Gas Cylinder |
|
| Applicable medium | SiH2CI2 SiHCI3 CIF3 HF WF3 BCI3…For more media, please consult. |
| Volume selection | 150L-3,000L optional |
| Optional certificate | TS, UN, IMD, TPED, DOT (CCS、BV)
Certificate time: TS certificate, 4 months from the date of order placement; UN/IMDG, 4 months from the date of order placement; TPED, 6 months from the date of order placement; DOT, 9 months from the date of placing the order (actual order delivery should be based on the agreed delivery date in the contract, and multiple certificates should be calculated based on the final acquisition time) |
| Operating temperature | -40~65℃ |
| Material | S31603 |
| Manufacturing standards | ASME Ⅷ Div.1
ISO 18172-1 “International standard for refillable stainless steel welded gas cylinders” IMDG Coed “International Code for the Transport of Dangerous Goods” QYCDT001-2021 “Stainless Steel Welded Gas Cylinders” GB/T 32566 “Stainless Steel Welded Gas Cylinders” |
| Customs supervision | With customs lock (cross-border transportation option) |
| Bottle cap | Domestic transportation chooses light, while cross-border transportation chooses heavy |
| Maximum operating pressure | 2.2/-0.103MPa @65℃ |
| Proof pressure | 3.3MPa |
| Helium leak detection rate | ≤1X10-9 pa.m³/s |
| Water oxygen content | Dry and nitrogen-sealed EXW factory (without the valve, copper plug) |
| Polishing grade | EP, Ra≤0.07-0.25 um |
| Valve type | Manual and pneumatic right angle diaphragm valve |
| Valve interface type | 1, DISS636/CGA636(Outlet connection)
2, 3/4-14NGT /W28 14T.P.I(Inter-connection) |
| Adapted valve | Rotarex Kohda Neriki Ermeto |
