| Model No.: | CSCOTTT025 |
| Fuel Tank Volume: | 25,000 liters |
| Overall Dimensions(LxWxH): | 11,990×2,500×3,400mm |
| Chassis Brand: | HOWO |
| Drive Type: | 8×4 |
| Wheelbase: | 1,800+3,775+1,400mm |
| Max. driving speed(km/h): | 95 |
| Engine Model: | MC07.34-50 |
| Engine Power: | 340HP |
| Emission Standard: | Euro 5 |
| Tank material: | Q235 carbon steel |
BRIEF
The 25,000-liter oil tanker transport truck by CSCTRUCK China Tank Truck is a robust and efficient solution for bulk fuel transportation. Built on the reliable HOWO chassis with an 8×4 drive configuration, it ensures stability and performance even under demanding conditions. This truck is powered by a powerful MC07.34-50 engine, delivering 340 horsepower, compliant with Euro 5 emission standards, making it both environmentally friendly and fuel-efficient.
Designed for speed and reliability, the tank truck achieves a maximum driving speed of 95 km/h, making it ideal for long-distance operations. The fuel tank, constructed from durable Q235 carbon steel, boasts a capacity of 25,000 liters, ensuring high-volume fuel delivery with minimal trips, and enhancing operational efficiency.
The Q235 carbon steel material provides excellent strength and corrosion resistance, crucial for transporting hazardous materials like oil and fuel. Its robust design meets international safety and performance standards, ensuring reliability and durability in various conditions.
This oil tanker is tailored for industries requiring efficient fuel logistics and is manufactured by CSCTRUCK China Tank Truck, a renowned name in specialized heavy-duty vehicles. Its combination of a high-performance engine, sturdy chassis, and spacious, durable tank makes it an ideal choice for businesses prioritizing safety, efficiency, and compliance with environmental standards.
FEATURES
- Large Fuel Tank Capacity: It is equipped with a 25,000-liter carbon steel (Q235) fuel tank, making it suitable for transporting large volumes of oil or fuel.
- Powerful Engine: Powered by the MC07.34-50 engine, delivering 340 horsepower (HP) and complying with Euro 5 emission standards for reduced environmental impact.
- Sturdy Chassis: Built on the reliable HOWO chassis, known for its durability and strength, ensuring stable and secure operations.
- 8×4 Drive Configuration: The 8×4 drive type provides excellent traction and load distribution, making it ideal for heavy-duty transport over diverse terrains.
- High Speed: A maximum driving speed of 95 km/h, ensuring efficient delivery times without compromising safety.
SPECIFICATION
| Condition | NEW | ||
| Chassis | Brand | HOWOÂ | |
| Curb weight(kg) | 11,450 kg | ||
| Wheelbase(mm) | 1,800+3,775+1,400 mm | ||
| Dimensions(mm)(LxWxH) | 11,990X2,500X3,400 mm | ||
| Front/Rear Axle loading(kg) | 6,500/7,000/18,500 kg | ||
| Wheel track (front/rear) (mm) | 2,015/2,035 mm | ||
| Front/Rear overhang(mm) | 1,430/2,465 mm | ||
| Approach/Departure angle(°) | 19/19 | ||
| Max. driving speed(km/h) | 95 km/h | ||
| Clutch | Reinforced diaphragm clutch | ||
| Brakes | Service brake: Dual circuit compressed air brake                                  Parking brake: (Emergency brake): Spring energy, compressed air operating on rear wheels Auxiliary brake: Engine exhaust valve brake |
||
| Steering Gear | Power steering, hydraulic steering with power assistance | ||
| Tire | Quantity | 10 pcs with 1 spare tire | |
| Specifications | 12R22.5 | ||
| Transmission | Manual type, 6 Forwards and 1 reverse | ||
| Cab | It can accommodate 3 people. With Air Conditioner. | ||
| Engine | Brand | Sinotruk | |
| Model | MC07.34-50 | ||
| Fuel type | Diesel | ||
| Displacement(ml) | 6,870 ml | ||
| Power(kW) | 248kW | ||
| Horsepower(HP) | 340HP | ||
| Cylinder number | 4 | ||
| Emission standard | Euro 5 | ||
| Fuel Tank | |||
| Fuel tank | Capacity(CBM/liters) | 25 CBM/25,000 liters | |
| Tank material | Q235 carbon steel. | ||
| Thickness(mm) | 6mm of the tank and 7mm of the end plate. | ||
| Compartment No. | 2 | ||
| Baffle | 1 No,4 mm carbon steel. | ||
| Manhole cover | 2 manhole covers ∮500mm 2 sets with 2 breather valves. | ||
| Bottom Valve | 2 sets of API Pneumatic Bottom Valves. | ||
| Discharging valve | 2 set ∮ discharging valves. | ||
| Handrail | 2 sides. | ||
| Ladder | At the rear of the tank. | ||
| Painting | Color and design as customer’s requirement. | ||
