| Model No.: | CSCPTLDT024 |
| Propane Tank Volume: | 24000 liters |
| Overall Dimensions(LxWxH): | 10,720×2,480×3,420mm |
| Chassis Brand: | Dongfeng |
| Drive Type: | 6×4 |
| Wheelbase: | 5,350+1,300mm |
| Engine Model: | Cummins ISD270 50 |
| Engine Power: | 270 HP |
| Emission Standard: | Euro V |
| Max Driving Speed: | 90 km/h |
| Tank Material: | Q345R high-tension steel |
BRIEF
The 24,000-liter propane tank LPG delivery truck, produced by CSCTRUCK China Tank Truck, is a robust and efficient solution for large-scale propane transportation. Built on a reliable Dongfeng 6×4 chassis, this vehicle is engineered to deliver both durability and performance. Its Cummins ISD270 50 engine, producing 270 horsepower, ensures consistent power output while meeting Euro V emission standards for reduced environmental impact.
The tank, constructed from Q345R high-tension steel, offers exceptional strength and resilience, making it ideal for transporting liquefied petroleum gas (LPG). Its capacity of 24,000 liters accommodates significant payloads, making it a preferred choice for industrial and commercial propane distribution.
The propane tank truck’s maximum driving speed of 90 km/h balances efficiency and safety. The 6×4 drive configuration enhances stability and traction, especially on challenging terrains, ensuring reliable delivery in various conditions.
CSCTRUCK China Tank Truck’s focus on quality and compliance ensures that the vehicle meets international safety and operational standards. Its design caters to the growing demand for efficient and environmentally responsible fuel transportation.
Whether for urban distribution or long-haul deliveries, this LPG delivery truck combines advanced engineering, robust materials, and eco-friendly performance. Its capacity, power, and durability make it a key player in the global fuel logistics industry.
FEATURES
- Large Tank Capacity: The truck has a 24,000-liter propane tank, allowing for substantial LPG storage and delivery.
- Durable Construction: The tank is made from Q345R high-tension steel, ensuring strength, durability, and safety during transport.
- Reliable Chassis and Drivetrain: Built on a Dongfeng chassis with a 6×4 drive type, providing stability and traction for heavy-duty operations.
- Powerful and Efficient Engine: Powered by the Cummins ISD270 50 engine, delivering 270 HP and complying with Euro V emission standards, ensuring eco-friendliness and optimal performance.
- Adequate Speed for Delivery Operations: Capable of reaching a maximum driving speed of 90 km/h, balancing efficiency and safety for LPG delivery tasks.
SPECIFICATION
| Item No. | Parameters | ||
| Overall Dimensions(LxWxH) | 10,720×2,480×3,420 mm | Wheel Base | 5,350+1,300 mm |
| Gross Vehicle Weight | 24,420 kg | Curb Weight | 14,420 kg |
| Cabin | Left-Hand Driving, 3 Passengers Allowed, with Air Conditioner | ||
| Engine | Dongfeng Cummins ISD270 50 Diesel Engine, Four Stroke, 6 Cylinder in line, intercooler, Turbo Charging | ||
| Engine horsepower | 270 HP, Euro V | ||
| Displacement | 6.7 L(Diesel) | ||
| Max Driving Speed | 90 km/h | ||
| Gear Box | Fast Brand, 8 Forward Gear & 1 Reverse Gear | ||
| Front/ Rear Axle | 1x 7Ton, 2x10Ton, Dongfeng Brand | ||
| Tire | 11.00R20Â Â (10 pieces with one extra) | ||
| ABS | With ABS | ||
| Tank Capacity | 24,000 Liters | ||
| Filling Weight | 10,600 kg | ||
| Filling Content | Liquefied Petroleum Gas (Propane) | ||
| Tank Material | Q345R high tension steel, 10mm Thick Tank Body. | ||
| Liquid Line & Vapor Line | 2″ Diameter with Flange Connection | ||
| Standard Equipment | 1 Safety Valve, 1 Ball Foat Type Level Gauge, 1 Pressure Gauge, 1 Thermometer, 2 Emergency Shut-off Valves, 1 Tool Box, Anti-static Grounding Tape, with 1 valve box. | ||
| Specification | Designed Pressure: 1.61Mpa / 16.1 Bar Hydraulic Test Pressure: 2.21 Mpa / 22.1 Bar Air Tightness Pressure: 1.61Mpa / 16.1Bar Medium Density: 500-590 kg/m3 Working Temperature: Under 50ºC Corrosion Allowance: 1mm |
||
| Filling System | 1. Hydraulic Drive 2″ Truck Pump, Corken Brand Flow rate: 155-287L/min, Max Differential Pressure: 8.6 bar 2. LPG Flow Meter to Record Filling Volume, 2″ Flow rate: 38-380L/Min, 3. Discharging Hose, 2″ Stainless Steel, Flange Type. |
||
| Tank Mounted on Chassis Brand |
|---|
