The 20FT liquid ammonia ISO tank container, manufactured by CSCTRUCK China Tank Truck, is a specialized and robust solution for the safe and efficient transportation of liquid ammonia. With a capacity of 24 cubic meters(CBM), this ISO tank is designed to handle the demands of industrial logistics, ensuring secure and reliable storage and transport.

Engineered to withstand rigorous conditions, the tank features an inner pressure design of 2.2 megapascals (MPa), reflecting its ability to safely contain the high-pressure environment required for liquid ammonia. Its design temperature range spans from -40°C to +55°C, making it suitable for diverse climate conditions and varying operational environments.

Constructed from high-strength Q345R 16MnDR steel, the ISO tank container provides exceptional durability and resistance to corrosion and mechanical stress, enhancing its longevity and reliability. The sunshade mode of heat insulation incorporated into the design offers additional protection against external temperature fluctuations, contributing to the stability of the internal environment and ensuring optimal safety and performance.

The tank container supports a maximum loading height of 12,720kg and a gross weight of up to 30,480kg. This capacity facilitates the transport of substantial quantities of liquid ammonia, catering to the needs of large-scale industrial operations.

Overall, the 20FT liquid ammonia ISO tank container by CSCTRUCK China Tank Truck is a high-quality, dependable, and versatile solution, designed to meet stringent safety standards and operational requirements for the transportation of hazardous materials.

1. High Capacity and Pressure Rating: The tank has a 24 cubic meter (CBM) volume and is designed to withstand an inner pressure of up to 2.2 MPa, making it suitable for handling large quantities of liquid ammonia safely.

2. Wide Temperature Range: It is engineered to operate effectively within a temperature range of -40°C to +55°C, allowing it to transport liquid ammonia under various environmental conditions.

3. Durable Construction Material: The tank is constructed from Q345R 16MnDR steel, which provides high strength and durability, ensuring the tank can handle the demands of transporting hazardous liquids.

4. Heat Insulation and Sunshade Mode: Equipped with a sunshade mode of heat insulation, the tank is designed to minimize temperature fluctuations caused by external heat, enhancing the stability of the stored liquid ammonia.

5. Heavy-Duty Weight Capacity: The tank has a maximum loading height of 12,720 kg and a maximum gross weight of 30,480 kg, indicating its robust construction and ability to handle significant payloads.
