Model No.: | 20 CBM Crude Oil Tank Truck |
Crude oil tank volume: | 20 CBM |
Overall dimensions(LxWxH): | 9,600×2,500×3,300mm |
Chassis Brand: | Dongfeng |
Drive Type: | 6×4 |
Wheelbase: | 4,350+1,300mm |
Engine Model: | C260 33 |
Engine Power: | 260HP |
Emission Standard: | Euro 2 |
Crude Oil Tank Material: | Carbon steel |
Categories: Carbon Steel Tank Truck, Crude Oil Tank Truck
Description
BRIEF
The 20 CBM crude oil tank truck produced by CSCTRUCK China Tank Truck represents a robust and efficient vehicle designed for transporting crude oil over various terrains. Built on a Dongfeng chassis with a 6×4 drive configuration, it ensures stability and reliability even in challenging conditions. Powering this truck is the C260 33 engine model, delivering 260 horsepower, which provides ample strength to handle substantial loads over long distances.
In terms of environmental standards, the crude oil tank truck complies with Euro 2 emission regulations, balancing operational efficiency with reduced environmental impact. The carbon steel crude oil tank integrated into the design ensures durability and safety during transportation, meeting stringent industry standards for oil handling.
CSCTRUCK China Tank Truck‘s emphasis on quality and performance is evident in the design and construction of this tank truck. It incorporates features tailored to the demands of the crude oil transportation industry, including robust materials, advanced engine technology, and a chassis optimized for heavy-duty use. With a capacity of 20 cubic meters, it strikes a balance between volume and maneuverability, ideal for both urban and rural transportation routes.
Overall, the 20 CBM crude oil tank truck by CSCTRUCK China Tank Truck represents a reliable solution for businesses involved in the oil logistics sector, combining power, efficiency, and adherence to regulatory standards to meet the diverse needs of the modern transportation market.
FEATURES
1. Chassis and Drive Type: The truck is built on a **Dongfeng chassis** with a **6×4 drive type**. This configuration provides robust traction and stability, especially useful for carrying heavy loads like crude oil.
2. Engine Specifications: It is equipped with a C260 33 engine model that delivers 260 horsepower (HP). This engine power ensures efficient performance and the ability to handle the demands of transporting large volumes of crude oil.
3. Emission Standard: The truck adheres to the **Euro 2 emission standard**. Although not the latest standard, it still ensures a moderate level of environmental compliance by controlling the amount of pollutants released.
4. Tank Material and Capacity: The crude oil tank is made of **carbon steel**, known for its durability and resistance to corrosion, which is essential for safely transporting crude oil. The tank has a capacity of **20 cubic meters (CBM)**, allowing for significant volumes of oil to be transported in a single trip.
5. Manufacturer and Origin: The truck is produced by **CSCTRUCK China Tank Truck**, a reputable manufacturer in China known for its specialized tank trucks. The combination of CSCTRUCK China Tank Truck‘s expertise and the use of reliable Dongfeng chassis components ensures a high-quality and dependable crude oil transport vehicle.
SPECIFICATION
Vehicle Description |
||
Overall dimensions(LxWxH) | 9,600*2,500*3,300mm | |
GVW | 25,000kg | |
Curb weight | 10,805kg | |
Chassis brand | DongFeng KL | |
Traction type | 6×4, left/right hand drive | |
Chassis Description |
||
Chassis model | DFL1250A8 | |
Cab | Sleeper cab, forward control type, low roof, new face, all welded, steel cab of tilt type, mechanical cab tilting, rear mechanical cab. | |
Wheelbase | 4,350+1,300mm | |
Tire specification | 11.00-20 | |
Tire quantity | 10+1units | |
Engine | Engine model | C260 33 |
Emission level | Euro 2 | |
Displacement/output | 8,300ml/191kW | |
Horsepower | 260HP | |
Brake system | Full air brake system split pneumatic circuit: Parking spring brake acting on rear aes, exhaust brake. | |
Axle | Front | 7T- Elliot type, I beam section |
Rear | 10T*2-Single Reduction | |
Gearbox | Type | RT-11509C DD |
Number of gears | 9 forward gears&1reverse, synchronized | |
Suspension | Front | 8 Leaf spring with shock absorber |
Rear | 9 Leaf spring | |
Fuel tanker | Type | Steel fuel tank with lockable cap |
Capacity | 350L | |
Up-part Description |
||
Tanker | Capacity | 20 CBM |
Material | Carbon steel | |
Thickness | 5mm | |
Standard configuration | Equipped with 4 set manhole. Equipped with a double discharge valve and valve box. Equipped with surge baffles, ladder, roof coaming, skid-resistant walkway, and toolbox. Equipped with electrostatic conducting tape and double-fire extinguishers. |
