Model No.: | 18 Ton 22 CBM Pneumatic Tank Truck |
Overall Dimensions(LxWxH): | 9,000×2,500×3,800mm |
Chassis Brand: | Dongfeng |
Drive Type: | 4×2 |
Wheelbase(mm): | 4,500 |
Max driving speed(km/h): | 90 |
Engine Power: | 154kW |
Max Horsepower: | 210HP |
Emission standard: | Euro 5 |
Loading Medium: | Bulk feed, grain, powder, etc. |
Bulk Tank Capacity: | 18tons |
Bulk Tank Volume: | 22 CBM |
Tanker Material: | Carbon steel, Thickness: 4mm |
Compartments: | 3 |
Categories: Carbon Steel Tank Truck, Pneumatic Tank Truck
Description
BRIEF
The pneumatic bulk feed tank truck, alternatively known as a feed truck, feed tank truck, bulk feed transport vehicle, bulk feed delivery truck, bulk feed transporter truck, and similar appellations, is a specialized transport vehicle crafted from high-quality, high-strength steel plates welded into forming tanks. It is further outfitted with either an electric or hydraulic auger unloading system, integrated into various truck models or secondary chassis.
Primarily utilized within diverse feed mills and large-scale breeding facilities, pneumatic bulk feed tank trucks excel in the handling of granular feed substances. Moreover, they possess the capability to transport certain non-corrosive granular materials, such as pharmaceutical mill powder and grains for storage turnover. Our company CSCTRUCK China Tank Truck‘s line of pneumatic bulk feed tank trucks boasts the capability to transport various feed types via separate bins, offering notable convenience benefits and versatile applications. Serving as an indispensable transportation asset for farms and feed mills alike, these carbon steel tank trucks fulfill crucial roles within agricultural operations.
FEATURES
1. Durable Construction: The 18-ton 22 CBM pneumatic tank truck manufactured by China Tank Truck boasts a robust build, featuring a 4mm thick carbon steel bulk tanker. This construction ensures durability and longevity, capable of withstanding the rigors of transporting various pneumatic materials.
2. Efficient Design: With a bulk tank capacity of 18 tons and a volume of 22 cubic meters, this tank truck offers ample space for transporting sizable loads of pneumatic materials. The three compartments further enhance efficiency by allowing for the simultaneous transportation of different types of materials without cross-contamination.
3. Powerful Performance: Equipped with a Dongfeng chassis and a 154kW engine delivering a maximum horsepower of 210HP, this tank truck ensures powerful performance. It enables smooth acceleration and efficient handling even when navigating challenging terrains or carrying heavy loads.
4. Environmentally Friendly: Adhering to Euro 5 emission standards, the tank truck minimizes its environmental footprint by significantly reducing harmful exhaust emissions. This eco-friendly feature aligns with modern regulatory requirements and underscores the manufacturer’s commitment to sustainability.
5. Safety and Comfort: Designed to accommodate up to three passengers, this tank truck prioritizes safety and comfort during transit. Additionally, with a maximum driving speed of 90km/h, drivers can maintain control and adherence to speed limits while ensuring timely deliveries. Advanced safety features and ergonomic design elements contribute to a secure and pleasant driving experience for operators and passengers alike.
SPECIFICATION
Specification of 18 Ton 22 CBM Pneumatic Tank Truck |
|||
Driving type | 4×2, Left-Hand Driving | ||
Chassis | Brand | Dongfeng | |
Gross weight(kg) | 18,000 | ||
Wheelbase(mm) | 4,500 | ||
Dimensions(LxWxH)(mm) | 9,000×2,500×3,800 | ||
Approach/departure angle(°) | 14/11 | ||
Front/rear overhang(mm) | 1,430/2,570 | ||
Axle loading(front/rear)(kg) | 6,500/11,500 | ||
Wheel track(front/rear)(mm) | 1,815/1,800 | ||
Max driving speed(km/h) | 90 | ||
Tire | Quantity | 6+1spare tire | |
Specification | 10.00R20 18PR | ||
Cab | 3 passengers allowed. With air conditioner. | ||
Engine | Brand | CSCTRUCK China Tank Truck | |
Fuel type | Diesel | ||
Displacement(ml) | 6,200 | ||
Max Power(kW) | 154 | ||
Max Horsepower(HP) | 210 | ||
Cylinder number | 6 | ||
Max torque (N.m) | 500 | ||
Intake form | Water cooled | ||
Emission standard | Euro 5 | ||
Gearbox | Manual, 6 forwards & 1 reverse | ||
Body |
|||
Loading Medium | Bulk feed, grain, powder, etc. | ||
Bulk Capacity | 18tons | ||
BulkVolume | 22 CBM | ||
Material | Carbon steel | ||
Thickness: 4mm | |||
Rust Resistance | Anticorrosive paint | ||
Compartments | Quantity: 3 | ||
Color | As your request | ||
Logo | As your request | ||
Driving form | Electrical driving | ||
Main Parts | Mobile conveyor | ||
Vertical conveyor | |||
Electric operation box | |||
Conveyor maintenance port | |||
Horizontal conveyor | |||
Discharging operation handle | |||
Ladder |
