12 Wheelers 30000 Liters Water Truck (2)

12 Wheelers 30000 Liters Water Truck (3)

12 Wheelers 30000 Liters Water Truck (4)

12 Wheelers 30000 Liters Water Truck (5)

12 Wheelers 30000 Liters Water Truck (6)

Model No.:	CSCWT030
Water Tank Volume:	30,000 Liters
Overall Dimensions(LxWxH):	11,500×2,500×3,500mm
Chassis Brand:	DongFeng
Drive Type:	8×4
Wheelbase:	1,800+4,600+1,350mm
Payload:	40,000kg
Max. driving speed(km/h):	90
Engine Model:	WP10340E22/WP10380E22
Engine Power:	340/380HP
Emission standard:	Euro 2
Water Tank Material:	Q235

Truck Enquiry

Categories: Carbon Steel Tank Truck, Water Tank Truck

Description

BRIEF

The 12-wheeler water tanker is a high-capacity vehicle for large-scale water transport and delivery. Manufactured by CSCTRUCK China Tank Truck, this robust tanker boasts a 30,000-liter water tank constructed from Q235 carbon steel, ensuring durability and resistance to wear. It is ideal for firefighting support, municipal water supply, irrigation, and industrial use.

Built on a DongFeng chassis with an 8×4 drive configuration, the truck is engineered for optimal performance on both paved roads and challenging terrains. With a gross vehicle weight (GVW) of 40,000 kg and a payload capacity of 30,000 liters, it ensures efficiency in every operation.

The water truck is powered by either the WP10340E22 or WP10380E22 engine models, delivering 340HP or 380HP respectively. These engines, compliant with the Euro 2 emission standard, strike a balance between power output and environmental considerations. The vehicle can achieve a maximum speed of 90 km/h, enabling timely delivery over long distances.

Key features of this tanker include its durable tank structure, reliable performance under heavy loads, and adherence to international standards. The design prioritizes operational safety and ease of maintenance, making it suitable for demanding water transport needs.

The 12-wheeler water tanker truck is a dependable choice for large-scale water distribution, offering a combination of high capacity, strong performance, and robust engineering.

FEATURES

High-Capacity Water Tank: The truck features a 30,000-liter Q235 steel water tank, suitable for large-scale water transport or firefighting applications.
Robust Chassis and Drivetrain: Built on a DongFeng chassis with an 8×4 drive type, it offers excellent stability and off-road capabilities.
Powerful Engine Options: Equipped with either the WP10340E22 or WP10380E22 engine models, delivering 340HP or 380HP, compliant with the Euro 2 emission standard.
Impressive Payload and Speed: The truck can handle a 40,000 kg payload and achieves a maximum speed of 90 km/h, ensuring efficiency in operations.
Durable Build and Design: The use of Q235 carbon steel for the tank ensures durability, and the design is optimized for demanding industrial and commercial water transportation needs.

SPECIFICATION

Cabin	Driving type 8×4 LHD/Rhd.
Cabin	DongFeng with one bed and air conditioner, 70° hydraulically tillable to the front as attached photo for ref.
Vehicle Main Dimensions	Overall dimensions(LxWxH)mm	11,500×2,500×3,500
	Wheelbase(mm)	1,800+4,600+1,350
	Wheel track(front/rear)(mm)	2,020/1,830
Weight in KGS	Tare Weight	15,000
	Payload	40,000
	Front axle loading capacity	2×7,000
	Rear axle loading capacity	2×16,000
Max. driving speed(km/h)		90
Engine	Brand	Dongfeng
	Model	WP10340E22/WP10380E22
	Type	4-stroke direct injection, 6-cylinder in-line with water cooling, turbocharged and intercooled.
	Horse Power(HP)	340/380HP
	Emission standard	Euro 2
Gearbox	10-speed forward and 2 reverse gear.
Clutch	Reinforced diaphragm clutch, diameter 430mm.
Steering	ZF8098, power steering, hydraulic steering with power assistance.
Oil tank	400 liters
Tire	12R22.5 tubeless tire 13 PCS including one spare tire.
Tank specifications	Volume: 30,000 liters.
Tank Material	Q235. End plate thickness:6mm, tanker body thickness: 5mm2.
