Model No.: | 12 Wheelers 30 CBM Fuel Tank Truck |
Fuel Tanker Volume: | 30 CBM |
Overall Dimensions(LxWxH): | 11,800×2,500×3,400mm |
Chassis Brand: | Dongfeng |
Drive Type: | 8×4 |
Wheelbase: | 2,050+4,000+1,350mm |
Engine Brand: | CUMMINS, YUCHAI, CHAOCHAI |
Engine Model: | ISL9.5-315E51A-50 30/33/40 optional |
Engine Power: | 315HP |
Emission Standard: | Euro 2/3/4/5 |
Fuel Tanker Material: | Carbon steel, Aluminum alloy, Stainless steel |
Max. speed: | 80km/h |
Description
BRIEF
The 12-wheelers 30 CBM fuel tank truck manufactured by CSCTRUCK China Tank Truck, a leading name in China‘s tank truck industry, epitomizes cutting-edge technology and superior performance. With a colossal 30 CBM fuel tank capacity, this vehicle stands as a formidable asset in the transportation of fuel and other liquid commodities. Its robust Dongfeng chassis and 8×4 drive type ensure unparalleled stability and maneuverability, even in challenging terrains.
This powerhouse offers versatility with a range of engine options including CUMMINS, YUCHAI, and CHAOCHAI, allowing customers to tailor the fuel tank truck to their specific needs. Boasting a formidable 315HP engine power, it delivers exceptional torque and acceleration, making it a reliable choice for long-haul journeys.
Crafted with precision, the tank material options include carbon steel, aluminum alloy, and stainless steel, ensuring compatibility with various transported liquids while maintaining structural integrity. Its optional aluminum alloy, stainless steel, or carbon steel fuel tanker further enhances durability and corrosion resistance, guaranteeing longevity even in harsh operating conditions.
The 12-wheelers 30 CBM fuel tank truck doesn’t just prioritize performance; it also ensures safety and efficiency. With a maximum speed of 80km/h, it adheres to road regulations while maximizing productivity. Whether navigating urban streets or traversing rugged landscapes, this vehicle is a dependable companion for businesses reliant on efficient liquid transportation. In summary, it’s a testament to CSCTRUCK China Tank Truck‘s commitment to innovation, reliability, and customer satisfaction in the tank truck industry.
FEATURES
1. Tank Capacity: The fuel tank has a substantial capacity of 30 cubic meters, providing ample storage for transporting fuel efficiently.
2. Chassis: Built on a sturdy Dongfeng chassis, renowned for its reliability and durability, ensuring stability and safety during transportation.
3. Drive Type: The fuel tank truck features an 8×4 drive type configuration, offering enhanced traction and control, particularly useful for heavy-duty applications.
4. Engine Options: Customers can choose from a range of engine options, including CUMMINS, YUCHAI, or CHAOCHAI engines, catering to diverse performance preferences and operational needs.
5. Engine Power: With a robust engine power of 315 horsepower (HP), the fuel tank truck delivers impressive performance, ensuring efficient fuel transportation even in challenging terrains.
6. Tank Material Options: The fuel tanker is available in multiple material options, including carbon steel, aluminum alloy, or stainless steel, allowing customers to select based on their specific requirements such as durability, weight, and compatibility with the transported fuel.
7. Maximum Speed: Capable of reaching a maximum speed of 80 kilometers per hour (km/h), the fuel tank truck offers swift transportation, contributing to timely deliveries and efficient logistics operations.
SPECIFICATION
Product Details |
|
Chassis brand | DONGFENG |
Drive form | LHD or RHD optional |
Emission standard | Euro 2/3/4/5 optional |
Drive model | 8×4 |
Drive form | LHD or RHD optional |
Fuel type | Diesel |
Cab type | One and a half cabin, with a sleeper(Flat top cab or high top cab) |
Overall dimension | 11,800×2,500×3,400mm |
Tanker dimension | 9,000×2,200×1,500mm |
Tanker capacity | 30 CBM |
Tanker material | Carbon steel, Aluminum alloy, Stainless steel, material optional |
Engine brand | CUMMINS,YUCHAI,CHAOCHAI |
Engine model | ISL9.5-315E51A-50 30/33/40 optional |
Horsepower | 315HP |
Displacement | 9,460ml |
Emission standard | Euro 2/3/4/5 |
Tare weight | 15,130kg |
Rated payload | 15,740kg |
Wheelbase | 2,050 +4,000 +1,350mm |
Max speed | 80km/h |
Tyre type | 295/80R22.5 18PR steel wire tire |
Tire number | 12(with a spare tire) |
Transport medium | Gasoline, diesel, kerosene. |
Braking system | Air brake |
Electrical system | 24 voltage,7 wire harnesses, LED lights. |
Painting | With shot blasting and 4 layers of paint, color is optional. |
Packing | Nude, polish with wax before shipment. |
Remark | The above-mentioned data is for your reference only. The detailed specification will be subject to our final confirmation. |
