Model No.: | 12 Wheelers 30 CBM Chemical Tank Truck |
Chemical Tank Volume: | 30 CBM |
Overall Dimensions(LxWxH): | 11,800×2,496×3,800mm |
Chassis Brand: | HOWO |
Drive Type: | 8×4 |
Wheelbase: | 1,800+4,300+1,350mm |
Engine Model: | WP12.400 |
Engine Power: | 400HP |
Emission Standard: | Euro II |
Chemical Tank Material: | 304 stainless steel |
Max Speed: | 102 km/h |
Categories: Chemical Tank Truck, Stainless Steel Tank Truck
Description
BRIEF
The 12-wheel 30 CBM chemical tank truck produced by CSCTRUCK China Tank Truck is a high-capacity, specialized vehicle designed for the safe and efficient transport of chemicals. Built on a robust HOWO chassis, this tanker is configured with an 8×4 drive type, ensuring superior stability and maneuverability even when fully loaded. The truck is powered by a WP12.400 engine, boasting a substantial 400 horsepower, which provides the necessary power for long-haul journeys and demanding road conditions.
Adhering to the Euro II emission standard, the chemical tank truck minimizes its environmental impact, making it a more sustainable choice for chemical transportation. The tank itself is constructed from 304 stainless steel, renowned for its resistance to corrosion and chemical reactions, ensuring the integrity and safety of the transported substances. With a maximum driving speed of 102km/h, this vehicle balances performance and safety, making it suitable for various logistical needs.
The 30 CBM chemical tanker is specifically engineered to handle a range of chemicals, providing industries with a reliable solution for their transport requirements. Its design integrates advanced safety features to protect both the driver and the cargo, adhering to stringent international standards. CSCTRUCK China Tank Truck, a reputable manufacturer, ensures that each truck undergoes rigorous testing and quality control measures, guaranteeing durability and reliability.
In summary, the 12-wheel 30 CBM chemical tank truck is a powerful, efficient, and safe option for chemical transport, equipped with advanced features and built to meet high industry standards.
FEATURES
1. Large Capacity Chemical Tank: The truck is equipped with a 30 CBM(cubic meters) chemical tanker made of 304 stainless steel, providing substantial storage for transporting various chemicals safely and efficiently.
2. Robust HOWO Chassis: Built on the durable HOWO chassis, the truck ensures reliability and longevity, suitable for heavy-duty operations and long-distance transportation.
3. High-Power Engine: Featuring the WP12.400 engine model with 400HP, the truck offers powerful performance, enabling it to handle demanding transport tasks with ease.
4. Efficient Drive Type: The truck employs an 8×4 drive type configuration, ensuring optimal traction and stability on diverse road conditions, and enhancing safety and drivability.
5. Environmental Compliance and Speed: Despite adhering to the Euro II emission standard, the truck can reach a maximum driving speed of 102km/h, balancing environmental considerations with efficient operation.
SPECIFICATION
Cabin | Driving type: 8×4 LHD/RHD | |
HW76 Lengthen cab, single bunk, safety belts, left-hand driving, air conditioner. | ||
Overall Dimensions(LxWxH) | 11,800×2,496×3,800mm | |
Wheelbase | 1,800+4,300+1,350mm | |
GVW | 31,000kg | |
Front axle loading capacity | 2×7,000kg | |
Rear axle loading capacity | 2×16,000kg | |
Engine | Brand | SINOTRUK |
Model | WP12.400 | |
Type | 6-cylinder in line, 4-stroke, water-cooled, turbo-charged &Â inter-cooled, direct injection | |
Displacement | 12L | |
Horse Power(HP) | 400 | |
Emission standard | Euro II | |
Max Speed | 102km/h | |
Tire | 12.00-20, 12.00R20 | |
Transmission | HW19710 or HW19710 transmission, 10 forward & 2 reverse, with PTO. | |
Steering | ZF8098 | |
Oil Tank | 300L | |
Tank Volume | 30 CBM | |
Brake System | Service brake: Dual circuit compressed air brake. | |
Parking brake (emergency brake): Spring energy, compressed air operating on rear wheels. | ||
Auxiliary brake: Engine exhaust valve brake. | ||
Electrics | Operating voltage: 24V, negative ground. | |
Batteries: 2x12V, 165Ah | ||
Horn, headlamps, fog lights, brake lights, indicators, and reverse lights. | ||
Option | Vertical Muffler, ABS, Automatic Break Clearance Adjusting Arm, Traveling Data Recorder, Metal Pipeline, Engine Protective Board. |
