Filter

Model No.:	CSCFTL025
Fuel Tank Volume:	25 CBM
Overall Dimensions(LxWxH):	11,990×2,500×3,750mm
Chassis Brand:	FAW
Drive Type:	8×4
Wheelbase:	1,800+4,265+1,350mm
Engine Model:	SC10E350Q4
Engine Power:	350HP
Emission Standard:	Euro 3
Tank Material:	Carbon steel Q235A
Loading capacity:	3,065kg
Max. driving speed:	95km/h

Truck Enquiry

Categories: Carbon Steel Tank Truck, Fuel Tank Truck

Description

BRIEF

The 12-wheeler 25 CBM fuel tank lorry by CSCTRUCK China Tank Truck is a robust and efficient solution for large-scale fuel transportation. Built on the reliable FAW chassis with an 8×4 drive configuration, this heavy-duty tanker is designed for challenging terrains and heavy payloads.

The tanker truck features a 25 cubic meter (CBM) fuel tank made of carbon steel Q235A, known for its strength and durability, ensuring the safe transportation of flammable liquids. Its loading capacity of 3,065 kg makes it an ideal choice for long-distance fuel delivery operations.

Powered by the SC10E350Q4 engine, this tanker boasts 350 horsepower, providing ample power for hauling heavy loads. The Euro 3 emission standard ensures compliance with environmental regulations, striking a balance between performance and reduced emissions. With a top speed of 95 km/h, it offers efficiency and reliability on highways and city roads alike.

The 12-wheeler is engineered for functionality and endurance, making it suitable for both urban fuel distribution and rural logistics. CSCTRUCK China Tank Truck‘s commitment to quality and advanced engineering is evident in this fuel tank lorry, making it a dependable choice for fuel transportation businesses. Whether for industrial, commercial, or municipal fuel supply, this tanker delivers on performance, safety, and cost-efficiency.

FEATURES

Large Fuel Tank Volume: Equipped with a 25 CBM fuel tank, capable of carrying substantial quantities of fuel for large-scale distribution.
Robust Chassis and Drive Configuration: Built on a durable FAW chassis with an 8×4 drive type, ensuring stability and performance across various terrains.
Powerful Engine: Features the SC10E350Q4 engine with 350 HP power output, meeting the Euro 3 emission standard for moderate environmental compliance.
High-Quality Tank Material: Constructed with carbon steel Q235A, offering excellent strength and durability for fuel containment.
Efficient Performance: Supports a maximum speed of 95 km/h with a 3,065 kg loading capacity, ensuring reliable and efficient transportation.

SPECIFICATION

Technical Specification
Overall dimensions(L×W×H)	11,990×2,500×3,750mm
Emission standard	Euro 3
Cab	Single row, 3 passengers allowed in cab
G. V. W.	31,000(kg)
Curb weight	3,300(kg)
Loading capacity	3,065(kg)
Fuel type	Diesel
Engine & Chassis Specification
Chassis	CQ1315HTGG466V
Engine	SC10E350Q4
Max. speed	95(km/h)
Power	350(hp)
Displacement	10,420(ml)
Axle base	1,800+4,265+1,350(mm)
F/R wheel-base	2,006, 2,006/1,850, 1,850(mm)
F/R overhang	1,435/2,780(mm)
Axle load	6,500/6,500/18,000(kg)
Tyre	Standard equipped 11.00-20 18PRranhou tyre
Tank Specification
Tank dimensions(LxWxH)	9,000×2,500×1,800(mm)
Tank volume	25(CBM)
Tank material	Carbon steel Q235A, optional stainless steel&aluminum alloy
Tank thickness	5(mm), optional 6(mm)
Optional Choice
Accessories	Choosing Range
Standard equipment	Single gravity flowing wareroom, no pump, 2 aluminum alloy openings, warerooms, liquid level indicators, pumps, watches, spools, measurement guns, manholes, AIP valves, oil-gas recovery systems, and so on are optional.
		Tank material	Standard-equipped carbon steel as the tank material and the carbon steel can be replaced by stainless steel aluminum alloy, or colored steel.
