Model No.:	12 Wheelers 23 CBM Fuel Tank Truck
Fuel Tank Volume:	23 CBM
Overall Dimensions(LxWxH):	11,975×2,550×3,450mm
Chassis Brand:	SHACMAN
Drive Type:	8×4
Engine Model:	WP9H350E62
Engine Power:	350HP
Emission Standard:	EURO 3
Fuel Tank Material:	Q235B Carbon Steel
Payload:	17,070kg

Truck Enquiry

Categories: Carbon Steel Tank Truck, Fuel Tank Truck

Description

BRIEF

The 12 wheelers 23 CBM fuel tank truck produced by CSCTRUCK China Tank Truck utilizes chassis with wheelbases of 1,800+4,575+1,400mm and 1,950+4,425+1,400mm, corresponding to vehicle lengths of 11,975mm, with front suspensions of 1,525 and rear suspensions of 2,675. It’s designated as an FL-type dangerous goods transport vehicle, with a maximum medium density of 800kg/m3. The fuel tank has a total capacity of 22.3 cubic meters, with an effective volume of 21.25 m3, and dimensions of 2,400×1,650×830 mm. Optionally, a tank with dimensions of 2,300×1,550×830 mm is available.

The chassis employs T700 material and bolted connections, with Q235B carbon steel for the rear guard device. Rear protective device section size is 120×50 mm, with a ground height of 450 mm. It’s equipped with EBS (model: CM-EBS), a driving recorder with satellite positioning, front disc brakes, radial tires, and a speed limit set at 79 km/h. Engine-fuel consumption combinations include WP9H336E62/38.4, WP9H350E62/38.4, and WP9H390E62/37.34.

Safety features comprise tire burst emergency protection and optional installations like a tank roof aisle table, climbing ladder, and rear toolbox. Lighting styles, license plates, hose boxes, cab, hood, wheel plate, pedal, and air storage cylinder are customizable. Additionally, post-treatment arrangement, rear suspension appearance, oil-immersion air filter, and white side protection are optional. Safety signs and an on-board ETC device can also be installed.

FEATURES

1. Versatile Chassis Configuration: The 12 wheelers 23 CBM fuel tank truck offers 2 chassis options with wheelbases of 1,800+4,575+1,400mm and 1,950+4,425+1,400mm, allowing for varying vehicle lengths of 11,975mm.

2. FL Type Designation: Designated as an FL-type dangerous goods transport vehicle, it meets stringent safety standards for the transportation of hazardous materials.

3. High-density Cargo Capacity: With a maximum medium density of 800 kg/m3, it can safely transport a wide range of goods.

4. Spacious Tank: The tank boasts a total capacity of 22.3 cubic meters, with an effective volume of 21.25 m3, providing ample storage space. Optional tank dimensions of 2,300×1,550x830mm are also available.

5. Robust Construction: The chassis utilizes T700 material and bolted connections, ensuring durability and stability, with Q235B carbon steel material for the rear guard device.

6. Advanced Safety Features: Equipped with EBS (model: CM-EBS), tire burst emergency protection, and a driving recorder with satellite positioning, ensuring enhanced safety during transit.

7. Engine Options: Engine-fuel consumption combinations include WP9H336E62/38.4, WP9H350E62/38.4, and WP9H390E62/37.34, providing power and efficiency for various transport needs.

8. Customizable Features: Lighting styles, license plates, hose boxes, cabs, hoods, wheel plates, pedals, and air storage cylinders are customizable, allowing for personalized aesthetics.

9. Optional Installations: Optional installations such as a tank roof aisle table, climbing ladder, rear toolbox, post-treatment arrangement, rear suspension appearance, oil-immersion air filter, and white side protection cater to specific preferences and requirements.

10. Convenience Features: Optional additions like safety signs and an onboard ETC device enhance convenience and compliance with regulations.

SPECIFICATION

Overall dimensions(LxWxH)	11,975×2,550×3,450(mm)	Rated load capacity	17,070, 17,005(Kg)
Gross Vehicle Weight	32,000(Kg)	ABS	Standard configuration
Curb weight(kg)	14,800(Kg)	Front/rear suspension	1,525/2,675(mm)
Approach/departure angle	14/10(°)	Front and rear Axle Load	6,500/6,500/19,000
Wheelbase	1,800+4,575+1,400, 1,950+4,425+1,400, 1,800+3,975+1,400, 1,950+3,825+1,400(mm)	Number of axles	4
Maximum speed	79(km/h)	Number of spring pieces	3/3/-/-,10/10/-/-,14/14/-/-, 3/3/2+-/2+-,10/10/2+-/2+-, 14/14/2+-/2+-
Number of tires	12	Tire Size	12.00R20 18PR,12R22.5 18PR,295/80R22.5 18PR
Volume	22.3m³	Medium	Raw petrol
Front track	2036/2036,2070/2070(mm)	Rear track	1,860/1,860(mm)
Engine
Engine model	Displacement(ML)	Power (kW)/horsepower (PS)	Fuel
WP9H350E62	8,800	257/349	Diesel
WP9H336E62	8,800	247/335	Diesel
WP9H390E62	8,800	287/390	Diesel
